DISPLAY
I/O DISPLAY
I/O DISPLAY 1
I/O DISPLAY 2
ADJUST
PRINT PATTERN
NOZZLE 1
NOZZLE 2
NOZZLE 3
OPTICAL AXIS
LF TUNING
HEAD ADJ.
MANUAL HEAD ADJ
ADJ. SETTING
RESET SETTINGS
NOZZLE CHK POS.
YES
NO
GAP CALIB.
YES
NO
SENSOR CALIB
YES
NO
CHANGE TYPE
0
1
REPLACE
CUTTER
YES
NO
FUNCTION
CR MOVE
PANEL LED/LCD
PANEL KEY
PLATEN FAN
AIR FLOW FAN R
AIR FLOW FAN L
INK VALVE
COUNTER
F-7-2
DETAIL
BASIC
A A-1 A-x
F F-1
SAVE SETTINGS
YES
NO
YES
NO
