Chapter 1
[9]
[Menu mode]
" key" Opens the menu one level above.
" key" Opens the menu one level lower.
" key" Displays the previous action or setting.
" key" Displays the next action or setting.
[Offline mode]
" key" Feeds roll media manually in the direction opposite to the direction in which paper is
ejected.
" key" Feeds roll media manually.
[10] OK key
Sets or runs a selected action or value when the printer is in menu mode.
[11] eject key
Executing menu and ejects paper.
[12] Stop key
Quits a processing job.
[13] Power key
Switches the power to the printer on and off.
[14] Information key
Displays a printer submenu. Information about the inks and paper displays each time this key is
pressed.
Hold this key for 3 seconds to clean the printhead.

1.6.2 Printer state transitions

The different states of the printer and their transitions caused by pressing the relevant keys are shown below.
1-14
Keys
INITIALIZING
ONLINE
MAIN MENU
OFFLINE
Key operations
and print commands
SLEEP
1 Sec.
SHUTDOWN
F-1-13
PRINTING
PAUSE
SUB MENU
Auto
Online Key
Menu Key
Infomation Key
Power Key
0013-5388
