Display Description
N-INK USE XX: Ink color
EXC(XX) Cumulative count of refill ink replacement
N-INK USE Total count of replacement of each color of ink
EXC(TTL)
- MEDIA x (x: 1 to 7): Counters related to media
Cumulative print areas are displayed for media 1-7 beginning with the media with the maximum cumulative
print area.
Display Description
NAME Media type
TTL Cumulative print area of all media feed trays (metric)
TTL Cumulative print area of all media feed trays (inch)
ROLL Cumulative print area of roll media (metric)
ROLL Cumulative print area of roll media (inch)
CUT SHEET Cumulative print area of cut sheet (metric)
CUT SHEET Cumulative print area of cut sheet (inch)
- MEDIA OTHER: Counters related to media
Cumulative print areas are displayed beginning with the media with the eighth-large cumulative print area.
Display Description
NAME Media type
TTL Cumulative print area of all media feed trays (metric)
TTL Cumulative print area of all media feed trays (inch)
ROLL Cumulative print area of roll media (metric)
ROLL Cumulative print area of roll media (inch)
CUT SHEET Cumulative print area of cut sheet (metric)
CUT SHEET Cumulative print area of cut sheet (inch)
- MEDIASIZE1 ROLL: Counters related to roll media printing
Display Description
Cumulative print area of paper equal to or larger than 17 inches but
P-SQ 17-36 smaller than 36 inches (physical size)
T-7-18
T-7-19
T-7-20
Chapter 7
Unit
ml
ml
Unit
-
m2
Sq.f
m2
Sq.f
m2
Sq.f
Unit
-
m2
Sq.f
m2
Sq.f
m2
Sq.f
Unit
m2/Sq.f
7-15
