Page 1 Service Manual Phaser ™ Color Printer Warning The following servicing instructions are for use by qualified service personnel only. To avoid personal injury, do not perform any servicing other than that contained in operating instructions unless you are qualified to do so. This printing Febuary 1996 070-9100-01...
Page 2 Tektronix, Inc., Wilsonville, Oregon. Printed in the United States of America. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Tektronix, Inc. This instrument, in whole or in part, may be protected by one or more U.S. or foreign patents or patent applications.
Page 3: Users Safety Summary
Users safety summary Terms in manual: CAUTION Conditions that can result in damage to the product. WARNING Conditions that can result in personal injury or loss of life. Power source: Do not apply more than 250 volts RMS between the supply conductors or between either supply conductor and ground.
Page 4 Service safety summary For qualiﬁed service personnel only: Refer also to the preceding Users Safety Summary. Do not service alone: Do not perform internal service or adjustment of this product unless another person capable of rendering ﬁrst aid or resuscitation is present. Use care when servicing with power on: Dangerous voltages may exist at several points in this product.
Page 5: Table Of Contents
Connecting the printer to a workstation 2-11 Direct connection to a workstation 2-11 Networked connection to a workstation 2-11 Installing a SCSI hard disk drive on a Phaser 340 2-12 Connecting the optional CopyStation to the printer 2-13 Turning on the printer 2-14...
Page 6 Installing a printer driver for Microsoft Windows 95 2-23 Installing the Tektronix driver for Windows 3.1 2-25 If you have other Tektronix printer drivers already installed 2-25 Configuring the Tektronix Windows printer driver 2-26 Updating the standard Microsoft Windows PostScript driver 2-28...
Page 7 If you need help 4-6 Customer Support Hotline 4-6 Service support 4-6 Electronic Bulletin Board Service 4-7 Using the automated fax systems 4-7 Tektronix Color Printer Information Server 4-10 Accessing the printer’s web page 4-10 Theory of Operation Overview 5-1 Functional block diagram 5-2...
Page 8 Color is uneven 6-14 Not printing 6-14 Printing too light or too dark 6-14 Image is offset or cut off 6-14 Wrinkling 6-14 Oil streaks on top of print 6-14 Error codes and messages 6-15 viii Phaser 340 Color Printer...
Page 9 PC-based diagnostics 6-27 Requirements 6-27 Starting the diagnostics 6-28 Selecting tests 6-31 Running tests 6-33 Saving and restoring test selections 6-38 Saving and restoring other settings 6-38 The diagnostic pull-down menus summary 6-39 Test Command (Alt-T) 6-39 View Menu 6-39 Run Command 6-39 Next Command 6-39 Stop Command 6-39...
Page 10 Printhead 8-37 Cap/wipe/purge assembly 8-41 Upper and lower stripper finger assemblies 8-43 Rollers 8-44 Exit roller 8-44 Lower feed roller and feed roller magnetic clutch 8-46 Pick roller 8-47 Head tilt cam gear 8-49 Replacement 8-50 Phaser 340 Color Printer...
Page 11 Circuit boards 8-53 I/O board 1 8-53 I/O board 2 and I/O board 3 8-54 I/O board 4 8-55 Power control board 8-56 Interconnect board 8-58 Main board 8-60 RAM SIMM 8-61 Code ROM SIMM 8-62 Network card 8-63 Enabling TCP/IP with the authorization code 8-64 Checks and Adjustments Required tools summary 9-1 Front panel menu 9-2...
Page 12 Figures Figure 1-1 The Phaser 340 printer (shown with optional Lower Paper Tray Assembly) 1-1 Figure 1-2 Internal features of the print engine 1-4 Figure 1-3 Circuit boards of the print engine (right front view) 1-5 Figure 1-4 Circuit boards of the print engine (left-rear view) 1-6 Figure 1-5 The printer’s I...
Page 13 Figure 6-11 Test result of a Motor Motion test 6-37 Figure 6-12 The Thermal Test 6-37 Figure 7-1 Phaser 340 cleaning page 7-3 Figure 8-1 Removing the Lower Paper Tray Assembly 8-3 Figure 8-2 Removing the printer panels and covers 8-5...
Page 14 Removing the main board 8-60 Figure 8-37 Installing the RAM SIMM on the main board 8-61 Figure 8-38 Installing the code ROM SIMM on the main board 8-62 Figure 8-39 Installing the network card in the printer 8-63 Phaser 340 Color Printer...
Page 15 Figure 9-1 Main menu roadmap (printers serial-numbered B0xxxxx thru BBxxxxx) 9-2 Figure 9-2 Main menu roadmap (printers serial-numbered B0xxxxx thru BBxxxxx - continued) 9-3 Figure 9-3 Main menu roadmap (printers serial-numbered BCxxxxx and up) 9-4 Figure 9-4 Main menu roadmap (printers serial-numbered BCxxxxx and up - continued) 9-5 Figure 9-5 Setting paper-feed belt tension 9-8 Figure 9-6...
Page 16 Power problems 6-41 Table 6-6 Front panel indicators and their meanings 6-41 Table 6-7 Macintosh printing problems 6-41 Table 6-8 PC DOS printing problems 6-43 Table 6-9 Windows printing problems 6-44 Table 6-10 Workstation printing problems 6-45 Phaser 340 Color Printer...
Page 17: General Information
FRU list. To ensure complete understanding of the product, we recommend participation in Phaser 340 service training, if available. 9100-01 Figure 1-1 The Phaser 340 printer (shown with optional Lower Paper Tray Assembly) Service Manual...
Page 18: Phaser 340 Overview
These printers also have a updated front panel menu structure with new menu items. The Phaser 340 prints at an addressability of 300 dots per inch (dpi) and features 17 built-in fonts and 8 Mbytes of RAM, which can be upgraded to 12 Mbytes.
Page 19: Solid Inks
300 x 300 dpi printing and features 1.5 Mbytes of virtual memory. With a 4 Mbyte upgrade (12 Mbytes total) the printer’s virtual memory is increased to 3 Mbytes. A 16-Mbyte RAM SIMM can be installed in the Phaser 340, but it will only recognize 4 Mbytes of the SIMM.
Page 20: Print Engine Assemblies
Print engine assemblies Ink load assembly Cap/wipe/purge assembly Power supply Drum Transfix roller Printhead Process motor X-axis drive X-axis motor Y-axis motor Maintenance Paper tray pre-heater Drum heater 9100-02 Figure 1-2 Internal features of the print engine Phaser 340 Color Printer...
Page 21: Figure 1-3 Circuit Boards Of The Print Engine (Right Front View)
General Information Ten circuit board support the printer’s electronics. Four board, called I/O board 1 through I/O board 4 supports the front panel, solenoids and sensors. The main board contains the printer’s two CPU processors, a 29K processor which executes the PostScript image processing and a 68K processor which controls the print engine.
Page 22: Figure 1-4 Circuit Boards Of The Print Engine (Left-Rear View)
Printhead drive board e t ® a r t r v ic r a ll D is D IP Main board I/O Board 1 Interconnect board 9100-38 Figure 1-4 Circuit boards of the print engine (left-rear view) Phaser 340 Color Printer...
Page 23: Figure 1-5 The Printer's I 2 C Bus
General Information An internal data bus, called the I C bus, connects all I/O boards to the main board. Through this single bus, the main board can “poll” the I/O boards for the state of the printer’s sensors as well as actuate the printer’s solenoids. This data bus greatly simpliﬁes the wiring that would otherwise be required for monitoring dozens of sensors and actuating solenoids.
Page 24: Figure 1-6 Printhead Maintenance System Of The Print Engine
Air valve E th e r n e t® a r t r v ic r a ll Vacuum D is D IP accumulator Air pump 9100-03 Figure 1-6 Printhead maintenance system of the print engine Phaser 340 Color Printer...
Page 25: Figure 1-7 Left-Side Sensors And Switches On The Print Engine
General Information Sensors in the printer provide information to the main board to determine the state of the printer. The printer monitors the positions of some of the movable assemblies, such as the drum, as well as the temperature of many other assemblies, such as the printhead, paper preheater and the drum.
Page 26: Figure 1-8 Right-Side Sensors And Switches On The Print Engine
Paper width I/O Board 4 sensors Maintenance tray blade position sensor Right Paper-empty sensor maintenance Paper-pick tray sensor Tray type sensors sensor I/O Board 2 9100-73 Figure 1-8 Right-side sensors and switches on the print engine 1-10 Phaser 340 Color Printer...
Page 27: Figure 1-9 Solenoids On The Print Engine
General Information Head tilt solenoid Maintenance tray camshaft solenoid Paper pick solenoid Air valve Transfer cam solenoid 9100-05 Figure 1-9 Solenoids on the print engine Service Manual 1-11...
Page 28: The Main Board
The printer’s IP address, unique to each printer, is stored in a socketed ROM IC. NV RAM PostScript Printer ID ROM Print engine Network card RAM SIMM 9100-06 Figure 1-10 Features of the main board 1-12 Phaser 340 Color Printer...
Page 29: Combination Sensors And Their Meanings
General Information Combination sensors and their meanings Combinations of sensors are used by the printer to determine the type of standard media tray installed in the printer. Media tray type sensing The combinations of the three tray sensors “tell” the print engine what type of standard media tray is installed.
Page 30: Rear Panel
The following ﬁgure illustrates the rear panel of the printer. 29K processor 68K processor health light health light PHASER 340 Ethernet® Service Reset Feeder SCSI Disk Parallel Service port 9100-07 Figure 1-11 Printer rear panel with the optional Ethernet card 1-14 Phaser 340 Color Printer...
Page 31: Front Panel
General Information Front panel These front panel features are found on the printer: A two-line, 24-character LCD Four push buttons Two LEDs LCD. The LCD serves two purposes: displaying current image processor and print engine status information and displaying an interactive menu. Status information includes image processor status such as Ready , Receiving data and Printing .
Page 32: Specifications
The printer should not be tilted more than 15 from horizontal for more than 1 minute while the printer is idle or the ink is hot (in liquid state) or if the maintenance tray is installed. 1-16 Phaser 340 Color Printer...
Page 33 Addressability Selectable 300 x 300 or 600 x 300 dots-per-inch (horizontal and vertical). Only Phaser 340 Plus conﬁguration can print at 600 x 300 dpi. Engine printing speed The time it takes from loading to ejecting: 300 dots per inch: on A- or A4-size: ≈15 seconds per print...
Page 34: Table 1-5 Electrical Specifications
+40 V -5%, +12% -40 V ± 10% +54 V ± 10% RF emissions Both 115 and 220 VAC-conﬁgured instruments pass these standards: FCC Part 15 Class B EN55022 (CISPR 22) Class B VCCI (CISPR 22) Class B 1-18 Phaser 340 Color Printer...
Page 35 General Information Table 1-6 Environmental speciﬁcations Characteristic Speciﬁcation Temperature ° ° Operating to 35 C (59 to 95 ° ° Storage and shipping to 60 C (-22 to 140 Humidity Operating 10 to 80% relative humidity, non-condensing Non-operating 10 to 95% relative humidity, non-condensing Altitude °...
Page 36: Regulatory Specifications
General Information Regulatory speciﬁcations The Phaser 340 is in conformance with the following regulatory standards: FCC Part 15 Class B (for 115 VAC equipment) EN55022 (CISPR 22) Class B VCCI (CISPR 22) Class B The packaged product meets National Safe Transit Committee Test...
Page 37: Installing The Printer And Drivers
Drivers This chapter discusses installing the printer and its drivers as a part of the S0 installation option. Tektronix Service Option S0 consists of three main functions detailed in this and the next two chapters of this manual: Chapter 2 “Installing the Printer and Drivers.” The ﬁrst portion of installation instructions, this chapter, consists of ﬁve basic processes:...
Page 38: Pre-Install Questions For Customers
Printer Name _____________________ Printer IP address__________________ Net Mask _________________________ Broadcast address _________________ Gateway__________________________ What software application packages will be used with the printer? (Some applications require special printing utility ﬁles.) _____________________________________________ Phaser 340 Color Printer...
Page 39 Customers must provide the particular interface cable or network adapter they need to use with the printer. Customers can purchase the following from the Tektronix Graphics Supplies Order Desk by calling 1-800-835-6100. Parallel cable, DB25-pin plug to Centronics 1284C 012-1468-00 Serial, 9-pin to 9-pin, 3 m (10 ft.), null modem...
Page 40 2 Mbytes RAM, 2 Mbytes of hard disk space DOS systems DOS 3.1 or later An application that supports color PostScript or HP-GL Windows systems Windows 3.1 Windows 95 OS/2 Windows for Workgroups 3.11 Windows NT and Daytona Phaser 340 Color Printer...
Page 41 750 kbyte hard disk space for ﬁles Based on the results of the pre-install interview with the customer, you may wish to access the Tektronix Highly Automated Library (HAL) during business hours, at 1-800-835-6100 (ask to be transferred to HAL) for articles that may help with installing the printer into a customer's network.
Page 42: Unpacking
User manual Installation instructions Printer drivers and utilities reference manual Phaser printing utilities and driver diskettes Optional Lower Paper Tray Assembly (with paper tray) Phaser Share network utilities user manual (optional) Phaser Share utilities diskette (optional) Phaser 340 Color Printer...
Page 43: Figure 2-1 The Printer Packaging
Installing the Printer and Drivers 9100-09 Figure 2-1 The printer packaging Service Manual...
Page 44: Setting Up The Printer
Installing the Printer and Drivers Setting up the printer Installing the printer is explained in detail in the Phaser 340 Color Printer User Manual . The following is a brief list of the steps you follow to unpack and set up the printer.
Page 45 Installing the Printer and Drivers Install the printer’s maintenance tray and paper tray. Note that when a new maintenance tray is installed, the printer requires a 15-minute wait before it will print. Installing RAM SIMMs . The standard conﬁguration of the printer includes 8 Mbytes of RAM.
Page 46: Cabling The Printer
If the network has multiple zones, the network router assigns the printer a default zone name. The printer’s conﬁguration page lists the zone name. The Chapter 9 topic, “Printing the conﬁguration page” on page 9-7, explains printing this page. 2-10 Phaser 340 Color Printer...
Page 47: Connecting The Printer To A Pc
Installing the Printer and Drivers Connecting the printer to a PC Direct connection to a PC Turn off the printer. Turn off the host computer. Attach the parallel interface cable to the host computer; attach the other end to the printer. Turn on the printer ﬁrst and then the computer.
Page 48: Installing A Scsi Hard Disk Drive On A Phaser 340
Smart Card SCSI 9100-10 Figure 2-3 Connecting a SCSI hard disk drive to a Phaser 340 Turn on the disk drive ﬁrst, and then the printer. Refer to the Phaser 340 Driver and Utilities Printing Reference for details on formatting a SCSI disk, controlling Sys/Start job ﬁles, and using the LaserWriter Utility to load fonts onto the disk drive.
Page 49: Connecting The Optional Copystation To The Printer
Parallel Only Smart Card 9100-11 Figure 2-4 Connecting a CopyStation to a Phaser 340 Note The CopyStation uses two SCSI address; they are preset to 5 and 6. Make sure that any connected SCSI hard drive does not use these addresses.
Page 50: Turning On The Printer
Turning on the printer Startup page When you turn on a Phaser 340 printer, it executes a series of self-tests to determine if there are any problems with the PostScript interface. After running self-tests and reaching the “Ready” state, the printer prints a startup page (if the startup page has been enabled).
Page 51: Service Manual
Tektronix version number of the not applicable version number PostScript ﬁrmware running on the printer’s 29K processor. Print engine FW Tektronix version number of the engine not applicable version number ﬁrmware running on the printer’s 68K processor. Read from ROM and stored in NVRAM.
Page 52 ASCII, Raw, TBCP Encoding parallel port is expecting. Parallel port Indicates the mode of the port Compatibility Nibble mode (bi-directional or not). Parallel port The device used for standard output Serial back channel and standard error. 2-16 Phaser 340 Color Printer...
Page 53 Integer 1 through 65535 printer on a network. NetWare port Indicates the type of interpreters in use Auto Select Disabled, <interpreter> interpreter at the port (Phaser 340 only). Print server Name of the printer server. TEK01B009, user-deﬁned name hardware- dependent Conﬁguration...
Page 54 LPR Receive Buffer size used by the printer. 0 to 512. 0 means the buffer Window Size size will be based on the total memory in the printer. 2-18 Phaser 340 Color Printer...
Page 55 Simple Network Management Protocol (SNMP) utilities. System name Printer name Phaser 340 String of 0 to 255 characters System contact Name and phone number or address String of 0 to 255 characters of person responsible for the printer.
Page 56 If true, data parity should be checked. False True Disk Address SCSI address of disk for the SCSI disk-dependant 0 to 6 communication channel. Printer address SCSI address of printer when it is the initiator. 2-20 Phaser 340 Color Printer...
Page 57: Driver And Communication Setup
Turn off any anti-virus software running on the Macintosh before installing the Tektronix software. A Phaser 340 printer uses the Adobe PostScript Level 2 language. To take advantage of the Level 2 features, Tektronix developed the Tektronix Phaser driver which appears in the Chooser, along with the LaserWriter 7.0.x driver.
Page 58: Phaser 340 Gx Driver
Phaser 340 Drivers and Utilities Printing User Reference manual for details. Click on the Phaser 340 in the list of printers on the right side of the Chooser. Click the Create button to create a desktop printer. An icon of the printer appears on the desktop with the same name as the printer selected in the Chooser.
Page 59: Installing A Printer Driver For Microsoft Windows 95
Windows 95 and may cause printing problems in the new operating system. Start Windows 95. Insert the Phaser 340 CD-ROM in the computer’s CD-ROM drive, or insert the Printer Software for Windows diskette in the host computer’s disk drive.
Page 60 Windows diskette. Type in the name of the drive that the CD-ROM or diskette is in, and click OK. A list of Tektronix printers should appear. Select the printer in the list, then click Next. Select Tektronix Phaser 340 if you have the standard conﬁguration of the printer.
Page 61: Installing The Tektronix Driver For Windows 3.1
2-26. If you have other Tektronix printer drivers already installed If you still have an earlier version of the Tektronix Windows driver, you can use the INSTALL.EXE program on that “old” driver diskette to remove the older driver software.
Page 62: Configuring The Tektronix Windows Printer Driver
If you have the TekColor PS Previewer still installed, refer to the topic “Removing the TekColor PS Previewer software” in the Phaser 340 Drivers and Utilities Printing Reference to delete the ﬁles. When you are ﬁnished removing the old driver ﬁles, restart Windows.
Page 63 This option is only available to applications that use this Tektronix driver with Tektronix PostScript Level 2 printers. When this box is checked, the Compress Bitmaps option is unavailable (grayed-out).
Page 64: Updating The Standard Microsoft Windows Postscript Driver
Updating the standard Microsoft Windows PostScript driver If a customer prefers to use the standard Microsoft Windows PostScript printer driver instead of the Tektronix driver for Windows, follow these instructions. This update procedure provides printer page size information for applications within Windows using the standard driver.
Page 65: Installing The Printer Driver For Os/2 Version 2
LPT2PRIN. Scroll through the printer drivers listed to locate the proper Tektronix printer driver name. If it is listed, select it, otherwise, point the cursor to any other driver listed and click the right mouse button. Click Install from the menu options.
Page 66 Select Options and make sure that it is set to Phaser 340; if not, repeat the previous steps. While in this screen, set Job and Wait to 0, if they aren't already. Select the Output Tab; ensure that the proper port is selected.
Page 67: Configuring The Printer's Serial Port For A Pc
Installing the Printer and Drivers Conﬁguring the printer's serial port for a PC Use the front panel menu to modify the printer’s serial port settings. By scrolling to the Serial Settings menu item, you conﬁgure the printer's serial port. You may set these parameters: Data rate Data bits Stop bits, parity...
Page 68: Configuring A Novell Netware Server For The Printer
Ethernet address. If the printer is not displayed, refer to the Novell NetWare conﬁguration topic in the Phaser Share User Manual. Select a ﬁle server to be conﬁgured. Select a queue to service the printer or create a new queue. 2-32 Phaser 340 Color Printer...
Page 69: Configuring Tcp/Ip
Installing the Printer and Drivers Save the conﬁguration ﬁle. Following this, you can select another ﬁle server and create more queues for the printer to service. You can have a total of 32 queues. After all ﬁle servers have been conﬁgured, save the conﬁguration ﬁle and restart the print server.
Page 70 AppSocket, the printer language(s) supported by the printer (if the customer site uses AppSocket). syslog, a system’s log collect printer information for the network administrator. SNMP (Simple Network Management Protocol), allows the system administrator to query and control the printer’s status remotely. 2-34 Phaser 340 Color Printer...
Page 71 Installing the Printer and Drivers Service Manual 2-35...
Page 73: Verifying The Printer And Host Connections
Displayed on the right side of the dialog box are a list of printers that the selected driver will print to. Select the newly installed printer Phaser 340 . (If, for example, a Phaser 340 is already on the network with the name Phaser 340 , then the newly installed printer will be named Phaser 3401 .)
Page 74: Printing The Directory From A Macintosh
Close the Chooser by clicking on the small box in the upper-left corner of the dialog box; the Phaser 340 is now your chosen printer. You have now veriﬁed that the printer is on the network and is communicating with the Macintosh.
Page 75: Verifying That An Application Communicates To The Printer
Contact the Customer Support Hotline at 1-800-835-6100. Refer to the appropriate reference manual for your printer: the Phaser 340 Drivers and Utilities Printing Reference . Each provides information on using the printer with speciﬁc applications.
Page 76: Verifying Printing From A Pc
Type in a line of text such as THIS IS A TEST . Click the File menu item and select Printer Setup... from the menu list. Select Phaser 340 from the displayed list of available printer drivers. Click OK .
Page 77: Windows 3.1 Driver Verification
Type in a line of text such as THIS IS A TEST . Click the File menu item and select Printer Setup... from the menu list. Select Phaser 340, whichever applies) from the displayed list of available printer drivers. Click OK.
Page 78: Os/2 Connection Verification
(Point to any printer object, click the right mouse button, click on Select Default, and click on Phaser 340.) This is a simple way to be sure that all printers are set up correctly. Phaser 340 Color Printer...
Page 79: Novell Netware Verification
ﬁles created and sent for printing from other workstations on the network. The printer, in turn, ﬁnds all ﬁle servers with Phaser 340 queues and extracts its print ﬁles from them. You must determine if a computer can communicate a print ﬁle to the ﬁle server.
Page 80: Using The Error Handler Utility
This loads the error handling utility into the printer's memory where it remains until the printer is turned off. Send a ﬁle to the printer as explained in the previous procedure. If an error occurs, the printer will print a page listing the error. Phaser 340 Color Printer...
Page 81: Verifying Printing From A Workstation
Verifying printing from a workstation Verifying and printing using the TCP/IP protocols The Phaser 340 accepts ﬁles from networked UNIX and VMS workstations using TCP/IP communications. The printer supports BSD UNIX 4.3, AT&T's UNIX System V with BSD 4.3 lpr extensions, and DEC VMS with Tektronix PhaserSym software.
Page 82: Using The Error Handler Utility
Verifying the Printer and Host Connections To print to the Phaser 340 in the VMS environment, you must have the symbiont PhaserSym running on the host. To print to the printer from the host, you must ﬁrst have the printer’s queue established. This is site-dependent and requires the aid of the site’s network administrator.
Page 83: Key Operator Training
Chapter Key Operator Training This chapter covers the last portion of the Tektronix Service Option S0 installation: Training the printer's key operator. The steps you follow here place an emphasis on encouraging the key operator to read and use the printer's user manual to operate, clean, and care for the printer.
Page 84: Printer Controls And Indicators
Network connections: Explain the different types of Phaser Share cards that provide printer connectivity. Show where these connections are explained in the user manual and where to ﬁnd more information about expanding their printing system with other network options, cables, and accessories. Phaser 340 Color Printer...
Page 85: Loading Consumables
Ink sticks: Demonstrate how to load an ink stick. Emphasize to customers to use only Phaser 340 ink sticks. Also emphasize that they should not use ink sticks that have large pieces missing and not to load any small broken pieces.
Page 86: Cleaning
Show the location of the paper feed rollers inside the printer and inside the front cover. Show the location of the exit cover release button inside the front cover and the surfaces that will require cleaning inside the exit cover. Phaser 340 Color Printer...
Page 87: Clearing Paper Jams
ﬁlm must be loaded and waits for the customer to do so. Show where this is explained in the user manual and where to ﬁnd the Tektronix order number for the transparency tray. Using TekColor color corrections: Explain that different color correction modes are available and where to ﬁnd more information in the user manual.
Page 88: Warranty Information
Customer Support Hotline If customers encounter problems while using their printer that cannot be resolved using the user manual, they can call Tektronix’ Customer Support Hotline for help. The Hotline can answer technical question regarding using the printer, ranging from printing from application software to technical speciﬁcations.
Page 89: Electronic Bulletin Board Service
Tektronix drivers and software. To access the BBS 24 hours a day, 7 days a week, call (503) 685-4504. Use 9600 baud, 8 bits, 1 stop bit, and no parity.
Page 90 EuroHAL answers and asks which language customers want to use. For English Press 1 For French Press 2 For German Press 3 The ﬁrst time customers use EuroHAL, they should order a catalog; this lists all the documents that are available and is continually updated. Phaser 340 Color Printer...
Page 91 Key Operator Training EuroHAL asks customers for their fax machine number. If calling from outside the UK, customers must add their country code ﬁrst, as shown in the following table. Press # Customers area code and when Country Country code fax number ﬁnished Austria...
Page 92: Tektronix Color Printer Information Server
With PhaserLink, a customer can view and set printer and networking parameters. A homepage built into the printer links the printer to other homepages such as the Tektronix World Wide Web home page.
Page 93: Theory Of Operation
Chapter Theory of Operation Overview This chapter covers the theory of operation of each subsystem within the printer: Functional block diagram Drum/transﬁx assembly Maintenance tray Printhead Ink loader Cap/wipe/purge assembly Power supply Main board Print process in operation Printhead maintenance cycle Service Manual...
Page 94: Functional Block Diagram
The printer is made of seven major blocks: Drum/transﬁx assembly Drum maintenance tray Printhead Ink loader Cap/wipe/purge assembly Power supply Main board Power supply Ink loader Printhead Drum/transfix assembly Maintenance tray Main board Cap/wipe/purge assembly 9100-12 Figure 5-1 Overview of the printer Phaser 340 Color Printer...
Page 95: Drum/Transfix Assembly
Theory of Operation Drum/transﬁx assembly The drum/transﬁx assembly forms the key portion of the printer where imaging takes place. The main features of the drum/transﬁx assembly are its drum and transﬁx roller. In operation, the image to be printed on paper is ﬁrst “printed” on the rapidly rotating drum.
Page 96 A closed-loop servo drive system is inherently dangerous. Since the motor speeds up if it senses the drum drive system slowing down, ﬁngers caught in the drum belts and gears can be severely injured. Phaser 340 Color Printer...
Page 97: Maintenance Tray
Theory of Operation Maintenance tray The maintenance tray performs two functions. It’s primary function is to apply a thin coating of releasing agent, a silicon oil, 5 millionths of an inch thick to the surface of the drum prior to printing. The releasing agent keeps the ink from sticking to the drum’s surface and facilitates its transfer to the sheet of paper or transparency ﬁlm.
Page 98 The sensors are mounted on the maintenance tray guides on the inside of the printer frame. Phaser 340 Color Printer...
Page 99: Printhead
Theory of Operation Printhead The printhead is the heart of the printer. The printhead spans nearly the length of the drum. Using its 352 ink-jet nozzles (88 jets for each primary color), with just a horizontal motion of slightly less than 5 mm (0.2 inches), the printhead can print the entire image on the rotating drum.
Page 100: Figure 5-6 The Ink-Jet Array Nozzle Arrangement And Cross-Section
The illustration below shows a cross-section of the ink-jet array and the jet nozzle arrangement. Ink inlet Manifolds Piezoelectric crystals Color nozzles 28 pixels Black nozzles 24 pixels 24 pixels 12 pixels 2 pixels 9100-17 Figure 5-6 The ink-jet array nozzle arrangement and cross-section Phaser 340 Color Printer...
Page 101: Figure 5-7 X-Axis Printhead Movement During Printing
Theory of Operation X-axis or lateral movement of the printhead is accomplished by a short-pull pulley system. Through a stiff, yet ﬂexible band, the x-axis motor pushes on the end of a lever arm which, in turn, pulls the x-axis shaft. The printhead, mounted to the x-axis shaft, slews laterally across the surface of the drum.
Page 102: Figure 5-8 The Printhead Tilting Mechanism
Printhead print position Drum Printhead Tilt cam gear X-axis shaft follower pin Cam groove Printhead maintenance position Maximum tilt back Wipe Print positon Cap/purge Cam gear marks 9100-19 Figure 5-8 The printhead tilting mechanism 5-10 Phaser 340 Color Printer...
Page 103: Ink Loader
Theory of Operation Ink loader The ink loader consists of four parallel channels with an ink melting element at the end of each of the four channels. Ink sticks, one color loaded in each channel, are pressed by coil-spring pressure into the melting elements. As ink is required by the printhead, the appropriate color’s melting element is activated and the end of the ink stick is melted.
Page 104: Cap/Wipe/Purge Assembly
When servicing the printer be careful of the cap/wipe/purge assembly as it passes the printhead. If a damaged wiper blade of cap/wipe/purge assembly catches on the printhead it could ﬂip hot liquid ink upward into your face. 5-12 Phaser 340 Color Printer...
Page 105: Figure 5-11 The Cap/Wipe/Purge Assembly And Vacuum System
Theory of Operation Vacuum for the purge cycle is obtained from a vacuum pump and a vacuum accumulator. A small vacuum pump, running for about 75 to 90 seconds, creates a strong vacuum in the vacuum accumulator. Then an air valve is energized for a fraction of a second, exposing the printhead faceplate to the strong, accumulated vacuum to suck debris and bubbles out of the printhead nozzles.
Page 106: Power Supply
Even with the power switch in the OFF position, AC line voltages are present on the power supply, heaters and heater wiring. There are no ﬁeld adjustments necessary on the power supply. 5-14 Phaser 340 Color Printer...
Page 107: Figure 5-12 Power Supply Block Diagram
Theory of Operation Caution Do not plug a printer set for 115 V AC into 220 V AC power; it will at least blow fuse F1, at worse it will damage the power supply. +40V +54V section -40V Power +12V Printer supply -12V...
Page 108: Main Board
DMC. The DMC writes to a particular I/O board, for example, for that board’s sensor states and then reads that board’s data buffer for the requested sensor data. Similarly, it writes to a particular I/O board to activate its solenoids. 5-16 Phaser 340 Color Printer...
Page 109: Figure 5-13 Main Board Block Diagram
Theory of Operation Communication between the two processors is accomplished through an inter-processor controller (IPC) which is basically a byte-wide, bi-directional buffer. Data from one processor, presented to the buffer, ﬂags the other processor to read the data and return data, if necessary. Front panel Main board I/O 1 board...
Page 110: Print Process In Operation
The head tilt solenoid must be energized to allow the head tilt cam gear (with a slight spring assist) to advance forward enough to engage its drive gear and tilt the printhead back. 5-18 Phaser 340 Color Printer...
Page 111: Figure 5-14 Tilting The Printhead
Theory of Operation Caution When servicing the printer, before turning on the printer, you should always make sure that the head tilt cam gear is latched by the head tilt solenoid and that the head tilt cam gear is disengaged (via its missing teeth) to the drive gear.
Page 112: Drum Preparation
This keeps them from accumulating any oil on their ﬁngertips which would stain the edge of the print as it is stripped off of the drum. 5-20 Phaser 340 Color Printer...
Page 113: Figure 5-15 Drum Preparation For Printing
Theory of Operation Process motor Camshaft home position flag Three-position clutch Drum maintenance tray camshaft Process Home drive belt Maintenance One way clutch tray camshaft Three position compound gear Maintenance tray solenoid clutch camshaft solenoid Three-position Drum clutch Wick and blade up Cam pushes wick and blade against drum...
Page 114: Printing
(A set of jets is one of the 88 vertical arrangements of cyan, magenta, yellow and black jets.) With no interlacing, the test print reveals the deﬁciencies of a single jet compared to the rest. 5-22 Phaser 340 Color Printer...
Page 115: Figure 5-16 Printing The Latent (Pre-Transfer) Image On The Drum
Theory of Operation 300 dpi printing: 1216 columns of pixel dots, created by the even-numbered jets, interlaced with 1216 columns of pixel dots created by the odd-numbered jets. Each jet is responsible for 28 columns of dots. 600 x 300 dpi printing: 2432 columns of pixel dots, created by the even-numbered jets, interlaced with 2432 columns...
Page 116 (14 if both end jets are needed) for the printhead to reposition the end jets so they can ﬁll-in the missing pixel columns that cannot otherwise be interlaced. 5-24 Phaser 340 Color Printer...
Page 117: Figure 5-17 Printing The Latent (Pre-Transfer) Image On The Drum (Later Printers)
Theory of Operation For transparency printing, the image is printed in the same manner. However, the image is printed twice on the drum, the second image positioned precisely over the ﬁrst image before being transferred to the sheet of transparency ﬁlm; this increases image density.
Page 118: Paper Pick
At this point, the process motor is stopped to wait for more ink deposition on the drum. 5-26 Phaser 340 Color Printer...
Page 119 Theory of Operation When ink deposition is about 95% complete, the process motor is activated to bring the sheet of paper through the paper pre-heater and to the transﬁx position. The paper preheater heats the paper to improve ink transfer. The leading edge of the sheet of paper trips the paper preheater exit sensor as it passes out of the paper preheater.
Page 120: Transfixing, Stripping And Exiting
After about 1.8 seconds, the complete image has been transferred to the paper and the transﬁx roller is lifted off of the drum. 5-28 Phaser 340 Color Printer...
Page 121 Theory of Operation The rotating drum, driving the exit rollers, pushes the remainder of the sheet of paper into the exit tray. The trailing edge of the paper is detected by the exit sensor, ending the print cycle. Exit roller Exit sensor Transfix roller on eccentric shaft...
Page 122: Printer Self-Maintenance
These actions are used in different combinations for three different types of cleaning cycles: quick wipe short cleaning long cleaning The long cleaning is described here. The short cleaning and the quick wipe are basically subsets of the long cleaning cycle. 5-30 Phaser 340 Color Printer...
Page 123 Theory of Operation Preparation. Following printer power-up from a cold start or in response to a front panel menu selection, the print engine begins a printhead long cleaning cycle. The ﬁrst step is to stop any ink melting operation. Next, the main board starts the heaters in the cap/wipe/purge assembly.
Page 124: Figure 5-20 The Printhead Maintenance Cycle
“ﬂush” page is printed. The ﬂush page allows each jet to eject ink that may be slightly contaminated with another ink. Cap/wipe/purge assembly Printhead faceplate Vacuum valve Purge accumulator Vacuum pump Wipe Wiper blade Flush 9100-29 Figure 5-20 The printhead maintenance cycle 5-32 Phaser 340 Color Printer...
Page 125: Paper Preheater Cleaning
Theory of Operation Paper preheater cleaning This is a customer-initiated cleaning procedure, selected through the front panel cleaning menu Clean: Ink Smears. The purpose of this cleaning item is to clean ink out of the paper pre-heater that may have been deposited there. Ink can be deposited in the paper pre-heater if a sheet of paper with ink on it was rerun through the printer in an attempt at two-sided printing, which is not allowed.
Page 126: Transfix Roller Oiling
The printer then attempts to reprint the print that jammed. The chase page is processed the same as a regular print except the drum is not oiled and no image is printed on the drum (since an image is already printed on the drum). 5-34 Phaser 340 Color Printer...
Page 127: System Power-Up Sequence
Chapter Troubleshooting This chapter discusses troubleshooting the printer. Troubleshooting is discussed with two approaches: A step-by-step veriﬁcation procedure that systematically conﬁrms that particular components of a printer are properly functioning until a problem is found. A symptom/cause scheme that lists particular printer failures and error codes and their possible causes.
Page 128 NVRAM and are used to determine when abnormal events occur, such as double-picks or jams that stall the motors. The printhead is tilted back to the locked position. The front panel displays a warm up message. Phaser 340 Color Printer...
Page 129: Print Engine Troubleshooting
Troubleshooting The heaters are enabled and the drum begins to rotate. The cap/wipe/purge assembly is positioned to the purge position. 10. The printhead tilts forward and a purge cycle begins. 11. A ﬂush page is printed. 12. The front panel displays a message that the printer is initializing and then ready.
Page 130: Table 6-2 68K Processor Power Up Self-Test Error Codes
DMC ASIC: Write/read registers DMC ASIC: ROM validation DMC ASIC: Validate RAM blocks DMC ASIC: Timer registers and IRQ DMC ASIC: IRQ validation using test mode DMC ASIC: ADC conversion IPC validation (joint test with 29K processor Phaser 340 Color Printer...
Page 131: Verifying Print Engine Operation By Using Its Test Print
Troubleshooting Verifying print engine operation by using its test print If not already on, turn on the printer. If the printer does not begin initializing, go to the topic, “Verifying power supply operation” below. Once the Power light is on (not blinking) and the front panel displays Ready , press the Menu button and scroll to the Startup page .
Page 132 Troubleshooting Plug in the printer and turn it on. Using the Tektronix DMM 252/254 set for Hz (also, press the blue button), measure the AC sense test point. If the power supply can sense the AC input voltage, you should measure ~8.2 kHz for 115 VAC, or ~16.4 kHz for 220 VAC.
Page 133: Figure 6-1 Measuring The Dc Voltages (Test Points) And Fuses
Troubleshooting If the +5 VDC, ± 12 VDC, ± 40 VDC and +54 VDC voltages measure correctly proceed to the next topic. -12 V +60 V +5.0 V Sense -40 V +12 V +40 V adjust (other side) Sense Adjust (other side) PAPER RES #1...
Page 134: Inspecting The Power Supply Fuses
Refer to the Chapter 8 topic, “Power supply” on page 8-12. Note The power supply must have a minimum load to operate. The main board provides this loading with four large ballast resistors. Phaser 340 Color Printer...
Page 135: Testing For A Shorted Motor
Troubleshooting Testing for a shorted motor Reinstall the power supply if removed in the previous procedure. Disconnect the process motor, the Y-axis motor, X-axis motor and the cap/wipe/ purge assembly motor. Turn on the printer again to see if it does not overload now that the motors are disconnected from the power supply.
Page 136: Media Jams And The Paper Path
Ensure that the media ﬁts properly in the tray. With the left edge of the stack of paper ﬂush against the tray rail, there should be a small gap between the opposite edge of the stack of paper and the opposite side rail. 6-10 Phaser 340 Color Printer...
Page 137: Print Transfer Jams
Troubleshooting Check that the pick roller is being rotated. If it is not, go to the topic “Checking the process motor and drive train” on page 6-11. Otherwise, go to Step 5. In its starting position, the pick roller’s ﬂat side should face down;...
Page 138: Media Skews Passing Through The Paper Path
Streaks or lines in the print parallel to the short axis of printing Check the y-axis belt tension. If the y-axis drive is not smoothly and consistently rotating the drum, horizontal bands or lines appear in the print. Replace the Y-axis motor. Replace the power control board. 6-12 Phaser 340 Color Printer...
Page 139: Streaks Or Lines In The Print Parallel To The Long Axis Of Printing
Troubleshooting Streaks or lines in the print parallel to the long axis of printing Possible missing weak jet. Print the Service Test Print 2 “Weak Jet” to determine if a jet is not performing. Perform a printhead cleaning cycle to try to clean a clogged jet. If necessary, turn off the printer and allow the printhead to cool for 3 hours.
Page 140: Color Is Uneven
Replace the drum/transﬁx assembly. Oil streaks on top of print Clean the stripper ﬁngers. Run chase pages through the printer to clean the drum. PC diagnostics can help initiate chase pages. Replace the maintenance tray. 6-14 Phaser 340 Color Printer...
Page 141: Error Codes And Messages
Troubleshooting Error codes and messages Error codes indicate the following: the failing system (XX,yyy.zz) the failing subsystem (xx,YYY.zz) the actual problem (xx,yyy.ZZ). the print engine copy count (xx,yyy.zz:123) the error occurred on. Codes from 24,000 through 24,999 are engine failures reported by the PostScript controller.
Page 142: Table
5,003.42 (0x2b03): YA_POS_FAIL Y axis position failure: the drum is not where it should be. Besides the possible mechanical problems, this can be caused by software latency errors, if too many interrupts occur during drum positioning. 6-16 Phaser 340 Color Printer...
Page 143 Troubleshooting Table 6-4 Front panel and fault history log error codes and messages (cont'd.) Error code Meaning 6,000: X axis 6,000.41 (0x3400): X axis motor over/under current. Indicates that motor coil(s) are open, or XA_FAULT_MCURRENT shorted, or the x-axis motor fuse has opened. 6,001.42 (0x3401): X-axis home position not found.
Page 144 Check for open connection or open thermistor in power supply. 14,005.45:TCC_WRONG_ The installed cap/wipe/purge assembly is the wrong type for this printer. TYPE_CAP Verify and install the correct assembly or ﬁrmware for this printer. 6-18 Phaser 340 Color Printer...
Page 145 Troubleshooting Table 6-4 Front panel and fault history log error codes and messages (cont'd.) Error code Meaning 15,000: Drum thermals 15,001.42 (0x7c01): The drum thermistor appears to be open. Replace the drum temperature TCD_THERMISTOR_OPEN sensor. 15,002.43 (0x7c02): The drum thermistor appears to be shorted. Replace the drum TCD_THERMISTOR_SHORT temperature sensor.
Page 146 Jam -- Media at auxiliary tray, unexpected event paper pick sensor FALSE. 22,042.34 Jam -- Media at auxiliary tray, unexpected event paper A-width sensor FALSE, A4-width sensor FALSE. 22,043.35 Jam -- Media at auxiliary tray, unexpected event paper A-width sensor TRUE,A4-width sensor FALSE 6-20 Phaser 340 Color Printer...
Page 147 Troubleshooting Table 6-4 Front panel and fault history log error codes and messages (cont'd.) Error code Meaning 22,044.36 Jam -- Media at auxiliary tray, unexpected event paper A-width sensor FALSE, A4-width sensor TRUE 22,045.37 Jam -- Media at auxiliary tray, unexpected event paper A-width sensor TRUE, A4-width sensor TRUE 22,046.38 Jam -- Media at auxiliary tray, unexpected event paper preheat entry...
Page 148 Jam -- Media at exit cover, unexpected event paper A-width sensor FALSE, A4-width sensor TRUE. 22,109.38 Jam -- Media at exit cover, unexpected event paper A-width sensor TRUE, A4-width sensor TRUE. 22,110.30, Jam -- Media at exit cover, unexpected event paper preheat entry sensor TRUE. 6-22 Phaser 340 Color Printer...
Page 149 Troubleshooting Table 6-4 Front panel and fault history log error codes and messages (cont'd.) Error code Meaning 22,111.31 Jam -- Media at exit cover, unexpected event paper preheat entry sensor FALSE. 22,112.32 Jam -- Media at exit cover, unexpected event paper preheat exit sensor TRUE.
Page 150 Jam -- Media at hand-feed, unexpected event paper preheat exit sensor TRUE. 22,177.34 Jam -- Media at hand-feed, unexpected event paper preheat exit sensor FALSE. 22,178.35 Jam -- Media at hand-feed, unexpected event paper exit sensor TRUE. 6-24 Phaser 340 Color Printer...
Page 151 Troubleshooting Table 6-4 Front panel and fault history log error codes and messages (cont'd.) Error code Meaning 22,179.36 Jam -- Media at hand-feed, unexpected event paper exit sensor FALSE. 22,180.37 Jam -- Media at hand-feed, unexpected event paper hand-feed sensor TRUE.
Page 152 Engine is stuck while warming up -- it's too cold to warm up. 24,021.11 Engine is stuck while cooling down. 24,022.12 Engine is stuck while in cool state. 24,023.13 Engine is stuck while in printhead adjust state. 24.024.14 Engine is stuck while ﬂushing the printhead. 6-26 Phaser 340 Color Printer...
Page 153: Pc-Based Diagnostics
Troubleshooting PC-based diagnostics The PC-based diagnostics allows you to interactively test and check the operations and functionality of the printer. The diagnostics are provided on a 3-1/2 inch ﬂoppy diskette. All of the diagnostic tests are started from the PC. Some of the tests are stored on-board the main board in ROM and are merely started by the PC-based diagnostics;...
Page 154: Starting The Diagnostics
Turn on both the printer and your computer. In the case of a Apple PowerBook, select AppleTalk Inactive from the ﬁle PowerBook control strip menu. Figure 6-2 Turning off AppleTalk 6-28 Phaser 340 Color Printer...
Page 155 Troubleshooting Conﬁgure SoftPC’s PC Serial Ports. Set COM1 to the Modem Port. Flow control does not need to be checked. In the same pull down menu, set PC Memory to Expanded Memory of 0 MB and an Extended Memory of 1 MB. Figure 6-3 Conﬁguring SoftPC’s Serial Port To install the diagnostics from the diskette onto your computer: type: A:INSTALL<return>.
Page 156: Figure 6-4 Pc-Based Diagnostics Screen Display
“n of N” indicates the test progress. Third is the “view” ﬁeld. This indicates which “channel” is being viewed in the tty screen. It has one of 3 values: “29K” when viewing 29K tests, “68K” when viewing 68K tests. 6-30 Phaser 340 Color Printer...
Page 157: Selecting Tests
Troubleshooting In the very bottom-right-most corner is a tiny ﬁeld which indicates the status of the communication link between the PC and the printer’s 29K processor. It says “ok” when the link is working and “NO” when communication is lost. Selecting tests Press Alt-T (Option T —...
Page 158: Figure 6-5 The Diagnostics Global Help Screen
F1 – Brings up a more complete description about the currently highlighted test. Esc and Enter (Return) – either key causes the replaces the selection screen with the current tty window. Any currently selected test remain selected. 6-32 Phaser 340 Color Printer...
Page 159: Running Tests
Troubleshooting Running tests A print engine test is performed by the printer’s 68K processor. The test is downloaded from the diagnostics to the 68K processor. When a downloadable test is selected, it takes a few moments to download the test. While the test is downloading, the message bar indicates this fact and the completion indicator shows how much of the ﬁle has been loaded.
Page 160: Figure 6-7 The Individual Test Within A Selected Test Suite
Once you select a test suite, the individual tests of that suite are displayed. Figure 6-7 The Individual test within a selected test suite Press the space bar to select or deselect a test. You can select as many tests as you like. 6-34 Phaser 340 Color Printer...
Page 161: Figure 6-8 Running A Test
Troubleshooting Once selected, press Ctrl-R to start the test(s). Depending on the test, a screen may be displayed to modify how the tests run. Figure 6-8 Running a test The solenoid test, shown above, allows you to selectively actuate a printer solenoid as well as the drum fan.
Page 162: Figure 6-9 An Individual Test Help Screen
Figure 6-9 An Individual Test help screen The Sensor Test shows you the real-time state of the printer’s sensors. You can manually interrupt the sensors to determine if they operate correctly. Figure 6-10 Sensor Test summary 6-36 Phaser 340 Color Printer...
Page 163: Figure 6-11 Test Result Of A Motor Motion Test
Troubleshooting The Motor Tests let you know if a motor motion occurred within its expected time frame. A simple graphic of a vertical bar “|” between two brackets [...|..] shows that the test result occurred within its expected timeframe. If the “|”...
Page 164: Saving And Restoring Test Selections
Any user-conﬁgurable setting that the program knows about is saved in a conﬁguration ﬁle called DIAGS.INI and persists from session to session. Presently there is a short list of conﬁgurable items, but any program setting you makes need only be done once. 6-38 Phaser 340 Color Printer...
Page 165: The Diagnostic Pull-Down Menus Summary
Troubleshooting The diagnostic pull-down menus summary All of the functionality in the user interface is accessible from the menu bar. Some of the functions are additionally available via “accelerator” key (Alt- key) synonyms. The following discusses the pull-down menu left to right. Test Command (Alt-T) Opens the test selection window.
Page 166: File Menu (Alt-F)
About – gives the program version and other statistics about its operation. Usage overview – gives the user an overview of the system and explains running the ﬁrst test. F1 – describes an individually highlighted test. 6-40 Phaser 340 Color Printer...
Page 167: Problems And Solutions
Check the media selection switches on the right side of the paper tray. Macintosh printing problems Table 6-7 Macintosh printing problems Make sure that the correct Phaser 340 icon was selected in Image never prints. Printer acts as if it is the Chooser. Try printing the job again.
Page 168 In the print dialog box, make sure the Color/Grayscale option black-and-white. has been selected. Make sure that the Phaser 340 icon was selected in the Chooser. Try printing the job again. Check the version of your LaserWriter driver to ensure that it is version 6.0.7 or higher.
Page 169: Pc Dos Printing Problems
PostScript mode. Use the utility located on the Tektronix diskettes to change language emulation. Refer to the Phaser 340 Drivers and Utilities Printing Reference for complete instructions. Download TEKEHAND.PS ﬁle located on the Tektronix Utilities diskette.
Page 170: Windows Printing Problems
(CMY), blue is often printed as purple. To adjust blue from within Microsoft Windows: Within the Tektronix PostScript Windows driver you have an option, Vivid Color, that alters to blue colors that are appearing purple. To Access this option, select:...
Page 171: Workstation Printing Problems
Troubleshooting Workstation printing problems Table 6-10 Workstation printing problems Image never prints. For serial or parallel printing. Ensure that the print ﬁle ends Printer acts as if it is with a “CTRL-D” character. CTRL-D indicates the end-of-ﬁle, receiving data, but which the printer responds to by closing host-to-printer nothing comes out of the communications and then processing and printing the ﬁle.
Page 173: Cleaning And Maintenance
Chapter Cleaning and Maintenance A Phaser 340 printer requires periodic cleaning to keep it in peak operating condition. Some cleaning procedures, such as purging the ink-jets or feeding clean paper through the paper path, are done automatically when necessary. Other procedures, such as scrubbing the paper-feed rollers with an alcohol-soaked foam swab, must be done by customers.
Page 174: Cleaning
Appropriate cleaning procedures, as listed in the following tables, should be performed when speciﬁc print-quality or paper transport problems occur. All cleaning procedures are detailed in Chapter 4 of the Phaser 340 User Manual . Light stripes or missing colors...
Page 175: Cleaning Page
® 340 Cleaning Page This page prints to maintain optimal print quality. 9101-69 Figure 7-1 Phaser 340 cleaning page Vacuum Vacuum dust from the top cover, metal dust cover and plastic dust cover under the stripper ﬁngers. Drum temperature sensor With a dry swap, clean any buildup around the drum temperature sensor.
Page 176: Maintenance
ﬂuid is low. When a front panel message indicates the maintenance tray is “out of oil,” the maintenance tray must be replaced before continued printing is possible. Refer to Chapter 4, “Caring for Your Printer,” in the Phaser 340 User Manua l for instructions on replacing the maintenance tray.
Page 177: Lubrication
Cleaning and Maintenance Lubrication Tools and supplies required Light oil Grease 006-7997-00 In general, all of the printer's bearings and motors are lifetime factory-lubricated. However, over time and under certain extreme operating conditions, oil and grease may dry out, causing squeaks and rumbling noises in the printer.
Page 178: Inspection
Clutches: There are four clutches: the paper-pick roller clutch, the feed roller clutch, compound gear clutch and the maintenance tray cam clutch. Symptoms of a malfunctioning clutch are the printer not picking paper from the tray or other paper jams. In such cases, replace the clutch. Phaser 340 Color Printer...
Page 179: Required Tools
Printhead removal tool 003-1503-00 Printhead reservoir plug set 003-1504-00 Tweezers 003-0236-00 Hex wrench kit 003-1344-00 Grease 006-7997-00 Antistatic mat 006-7056-00 Flat-blade screwdriver Needle-nose pliers Volt-ohm-meter such as a Tektronix DM252/4 Multimeter Magnifying lens such as Micronta (Radio Shack) Cat# 63-851 Service Manual...
Page 180: Lower Paper Tray Assembly
The Lower Paper Tray Assembly, sometimes referred to as the second feeder, is serviced and replaced as a unit. Turn off the printer. Unplug the Lower Paper Tray Assembly cable from the rear of the printer. Lift the printer off of the Lower Paper Tray Assembly. Phaser 340 Color Printer...
Page 181: Figure 8-1 Removing The Lower Paper Tray Assembly
Field Replaceable Unit Disassembly/Assembly Reverse these steps to reinstall the Lower Paper Tray Assembly making sure that the printer is fully seated over the Lower Paper Tray Assembly's guide pins. 9100-34 Figure 8-1 Removing the Lower Paper Tray Assembly Service Manual...
Page 182: Cabinet Panels And Covers
Slide the front panel forward slightly to clear the pawls. Disconnect the front panel display wiring harness. Remove the front panel. Front cover: With a ﬂat blade screwdriver, press the release lever for each of the two front cover pivots. Remove the front cover. Phaser 340 Color Printer...
Page 183: Figure 8-2 Removing The Printer Panels And Covers
Field Replaceable Unit Disassembly/Assembly Stripper cover: Gently lift on each end of the stripper cover to unclip it from the exit roller. Ink load door Unclip arms Vacuum this area before removing Stripper Top panel cover Rear panel Left side panel Position spring cross- arm to rear of...
Page 184: Ink Loader
Lift and remove the ink loader. Reverse these steps to install the ink loader. Refer to Appendix C “Wiring Diagrams” for illustrations showing how to properly route the ink loader’s wiring harness. Phaser 340 Color Printer...
Page 185: Figure 8-3 Removing The Ink Loader
Field Replaceable Unit Disassembly/Assembly Caution Do not stand the ink loader on end so it heating elements face up. In this position a residual amount of liquid ink may ﬂow down the felt-lined ink stick chutes and damage the felt. Ink loader Disconnect wiring harnesses...
Page 186: Metal Dust Cover
Grasp and gently remove the ink dust cover. Metal dust cover Remove plastic grommet 9100-95 Figure 8-4 Removing the metal dust cover For reassembly, note how small hooks on the metal dust cover latch onto holes in the drum/transﬁx assembly frame. Phaser 340 Color Printer...
Page 187: Fans
Field Replaceable Unit Disassembly/Assembly Fans Rear fan Tools required Magnetic screwdriver T-20 TORX tip T-15 TORX tip Turn off the printer and remove the power cord. Remove the top, left-side and right-side covers as explained in the earlier topic, “Cabinet panels and covers” on page 8-4. Remove the ink loader as detailed earlier in the topic, “Ink loader”...
Page 188: Drum Fan
Remove the ink loader as detailed earlier in the topic, “Ink loader” on page 8-6. Disconnect the wiring harnesses leading to the drum fan. Remove the three screws securing the drum fan in place. Remove the fan. 8-10 Phaser 340 Color Printer...
Page 189: Figure 8-6 Removing The Drum Fan
Field Replaceable Unit Disassembly/Assembly Drum fan wiring harness Drum 9100-39 Figure 8-6 Removing the drum fan Reverse these steps to install the fan. Refer to Appendix C “Wiring Diagrams” for an illustration showing how to dress the drum fan wiring on I/O board 3 to secure the wiring in place. Service Manual 8-11...
Page 190: Power Supply
Remove the ink loader as described in the earlier topic, “Ink loader” on page 8-6. Remove the printhead as described in the later topic, “Printhead” on page 8-37. Disconnect the power supply’s wiring harnesses from the power control board and the interconnect board. 8-12 Phaser 340 Color Printer...
Page 191: Figure 8-7 Removing The Power Supply
Field Replaceable Unit Disassembly/Assembly Remove the six screws securing the power supply in place. Remove the power supply. Compression washer Power supply Disconnect heater wiring harness 9100-37 Figure 8-7 Removing the power supply Reverse these steps to install the power supply. Be sure that the sheet metal alignment guides in the back and bottom of the power supply align with the notches cut out in the power supply circuit board.
Page 192: Vacuum System
Disconnect the vacuum hose leading to the accumulator. Remove the three nuts securing the pump assembly to the frame of the print engine. Vacuum Wiring harness hose Vacuum pump 9100-40 Figure 8-8 Removing the vacuum pump 8-14 Phaser 340 Color Printer...
Page 193: Accumulator
Field Replaceable Unit Disassembly/Assembly Accumulator Tools required Magnetic screwdriver T-20 TORX tip T-15 TORX tip Turn off the printer and remove the power cord. Remove the top, left-side and right-side covers as explained in the earlier topic, “Cabinet panels and covers” on page 8-4. Remove the ink loader as detailed earlier in the topic, “Ink loader”...
Page 194: Solenoid Valve
Disconnect the wiring harnesses leading to the solenoid valve from I/O board 3. Disconnect the vacuum hoses leading to the solenoid valve. Remove the two screws securing the solenoid valve in place. Remove the solenoid valve. 8-16 Phaser 340 Color Printer...
Page 195: Figure 8-10 Removing The Solenoid Valve
Field Replaceable Unit Disassembly/Assembly Disconnect wiring harness Solenoid valve Remove screws Disconnect vacuum hoses 9100-42 Figure 8-10 Removing the solenoid valve Reverse these steps to reinstall the solenoid valve. Route its wiring harness between the solenoid valve and the power supply; refer to Appendix C “Wiring Diagrams.”...
Page 196: Y-Axis Belt Drive Assembly
Remove the three tension set screws securing the Y-axis belt drive assembly to the engine frame. Remove the assembly with its two belts. Reverse these steps to reassemble the Y-axis belt drive assembly. 8-18 Phaser 340 Color Printer...
Page 197: Figure 8-11 Removing The Y-Axis Belt Drive Assembly
Field Replaceable Unit Disassembly/Assembly Note Tension the drive belts using the Chapter 9 procedure, “Y-axis belts tension adjustment” on page 9-9. Ring gear Remove Y-axis drive tension assembly set screws 9100-43 Figure 8-11 Removing the Y-axis belt drive assembly Service Manual 8-19...
Page 198: Heaters
Remove the screw (below the transﬁx gear’s shaft) securing the left side of the paper preheater to the engine frame. Remove the paper preheater drive belt from the left end of the paper preheater’s feed roller. 8-20 Phaser 340 Color Printer...
Page 199: Figure 8-12 Removing The Paper Preheater
Field Replaceable Unit Disassembly/Assembly Right-side: Remove the Y-axis belt drive assembly as explained in the previous procedure, “Y-axis belt drive assembly” on page 8-18. Remove the E-ring and bushing at the right end of the paper preheater’s feed roller. (It’s not necessary to remove the E-ring, gear and bushing on the left end of the preheater’s feed roller.) Remove the two blue nose-guides from the inside of the printer frame;...
Page 200: Drum Heater
Pulling on the left end of the drum heater, slide the drum heater out of the print engine. Caution Do not touch the glass heating element inside the drum heater. 8-22 Phaser 340 Color Printer...
Page 201: Figure 8-13 Removing The Drum Heater
Field Replaceable Unit Disassembly/Assembly Reverse the steps to reinstall the drum heater. Caution When reconnecting the drum heater’s wiring harness, be careful not to confuse it with the paper preheater’s wiring harness. Push retaining pins at each end to free the drum heater Paper preheater alignment guide Drum...
Page 202: Drum Position Sensor Assembly
Disconnect the home-position sensor wiring harness from I/O board 1 leading to the drum position assembly. Disconnect the drum position encoder sensor at the drum position assembly. Remove the clear plastic dust cover from the drum position assembly. 8-24 Phaser 340 Color Printer...
Page 203 Field Replaceable Unit Disassembly/Assembly Precisely mark the end of the drum shaft relative to the drum home ﬂag on the drum position sensor assembly as shown in the illustration; use a straight edge to ensure accuracy; this is not necessary if you are also replacing the drum (as part of the drum/transﬁx assembly).
Page 204: Figure 8-15 Removing The Drum Position Sensor Assembly
ﬂag to the alignment mark you drew on the shaft. Use the encoder wheel gap tool to properly space the encoder wheel to the drum position sensor as explained in the Chapter 9 procedure, “Drum position encoder gap” on page 9-15. 8-26 Phaser 340 Color Printer...
Page 205: Drum/Transfix Assembly
Field Replaceable Unit Disassembly/Assembly Drum/transﬁx assembly Tools required Magnetic screwdriver T-20 TORX tip 3/32-inch hex key T-15 TORX tip Turn off the printer and remove the power cord. Remove the top, front panel, right-side and left-side covers as explained in the earlier topic, “Cabinet panels and covers” on page 8-4.
Page 206 Note that one screw is removed with a hex key. Disconnect wiring harness Hex key screw Remove transfix gear Remove transfix gear position sensor 9100-47 Figure 8-16 Removing the drum/transﬁx assembly (left side) 8-28 Phaser 340 Color Printer...
Page 207: Figure 8-17 Removing The Drum/Transfix Assembly (Right Side)
Field Replaceable Unit Disassembly/Assembly 11. Right side. Remove the drum fan and drum gear. Remove the Y-axis belt drive assembly and its belts. If necessary, refer to the previous procedure, “Y-axis belt drive assembly” on page 8-18. Disconnect the wiring leading to I/O board 3. Remove the three screws securing the board in place and remove the board.
Page 208 Pull out the drum heater and set it on the front door. It is not necessary to unplug the drum heater wiring. Carefully, lift and remove the drum/transﬁx assembly. Protect the drum surface. 8-30 Phaser 340 Color Printer...
Page 209 Field Replaceable Unit Disassembly/Assembly Ground Drum wires heater Paper preheater Remove left and right Push feed roller nose guides shaft to the left 9100-103 Figure 8-18 Removing the drum/transﬁx assembly (front) Reverse these steps to reinstall the drum/transﬁx assembly. Upon reassembly, install the hex-keyed screws ﬁrst;...
Page 210: Motors
8-6 to access the power control board underneath. Remove the Y-axis belt drive assembly as explained in the previous procedure, “Y-axis belt drive assembly” on page 8-18. Remove the paper preheater as explained in the previous procedure, “Paper preheater” on page 8-20. 8-32 Phaser 340 Color Printer...
Page 211: Figure 8-19 Removing The Process Motor Or The Y-Axis Motor
Field Replaceable Unit Disassembly/Assembly Remove the four screws securing either motor to the drum/transﬁx assembly. Remove the motor. Unclip the cable ties retaining the motor’s wiring harness. Disconnect the wiring harness from the ink loader. Process motor Process unit Y-axis motor 9100-49 Figure 8-19 Removing the process motor or the Y-axis motor...
Page 212: Cap/Wipe/Purge Drive Motor
Remove the plate securing the cap/wipe/purge assembly drive gear. Remove the gear off of its shaft. Disconnect the motor’s wiring harness and free the motor from the cap/wipe/purge drive belt. 8-34 Phaser 340 Color Printer...
Page 213: Figure 8-20 Removing The Cap/Wipe/Purge Drive Motor
Field Replaceable Unit Disassembly/Assembly Reverse these steps to reinstall the motor. Leave the two screws that secure the motor to the printer’s side frame loose until you attach the right-side cap/wipe/purge belt tension spring, then tighten the screws. Following reassembly, perform the Chapter 9 adjustment procedure “Cap/wipe/purge assembly belt adjustments”...
Page 214: X-Axis Drive Assembly
Reverse this procedure to reinstall the X-axis drive assembly. During installation insert 3/32" hex wrench in the end of the screw and tilt the screw to slip the assembly over the end of the shaft 9100-50 Figure 8-21 Removing the X-axis drive assembly 8-36 Phaser 340 Color Printer...
Page 215: Printhead
Field Replaceable Unit Disassembly/Assembly Printhead Tools required Torque magnetic screwdriver T-15 TORX tip Flat blade screw driver T-20 TORX extended shank Printhead removal tool POSIDRIV #2 tip Silicon reservoir plugs 9/64-inch hex driver tip The printhead removal tool, sometimes referred to as the hot head tool, allows you to handle to printhead while it is hot and protects the printhead faceplate.
Page 216: Figure 8-22 Plugging The Reservoir Holes
Also, make sure that cap/wipe/purge assembly is in its home position (full down). Rotate the cap/wipe/purge drive gear to force the cap/wipe/purge assembly to its lowest position. 8-38 Phaser 340 Color Printer...
Page 217: Figure 8-23 Removing The Printhead
Field Replaceable Unit Disassembly/Assembly Rotate the removal tool’s plastic leg into its up position. Slide the removal tool’s standoff locks inward. Carefully, lower the printhead removal tool onto the printhead. Rotate the process motor to tilt the printhead forward about 2.5 cm (1 inch).
Page 218 Inspect both ends of the data ribbon cable to ensure they are properly seated. Refer to the Chapter 9 topic “Printhead-to-drum spacing adjustment” on page 9-11 to set the correct gap between the “hot” printhead and the drum. 8-40 Phaser 340 Color Printer...
Page 219: Cap/Wipe/Purge Assembly
Field Replaceable Unit Disassembly/Assembly Cap/wipe/purge assembly Tools required Magnetic screwdriver T-15 TORX tip Needle-nose pliers T-10 TORX tip 3/32 hex key Warning Even when the printer is turned off, AC line voltages may be present at the printer heaters while the printer is plugged into AC power.
Page 220: Figure 8-24 Removing The Cap/Wipe/Purge Assembly
Secure the wiring to the metal vacuum tube with a twist-tie or tie-wrap. Refer to Appendix C “Wiring Diagrams” for details on dressing the cap/wipe/purge wiring. Cap wipe/purge assembly Vacuum inlet Pin screw Pin screws 9100-53 Figure 8-24 Removing the cap/wipe/purge assembly 8-42 Phaser 340 Color Printer...
Page 221: Upper And Lower Stripper Finger Assemblies
Field Replaceable Unit Disassembly/Assembly Upper and lower stripper ﬁnger assemblies Tools required Magnetic screwdriver T-20 TORX tip 0.05-inch hex key T-15 TORX tip 3/32-inch hex key Turn off the printer and remove the power cord. Remove the top, front panel, right-side and left-side covers as explained in the earlier topic, “Cabinet panels and covers”...
Page 222: Rollers
“Cabinet panels and covers” on page 8-4. Unclip the stripper cover. Disconnect the cables from I/O board 3 and then remove it. Remove the right E-ring securing the exit gear assembly and then remove the exit gear assembly. 8-44 Phaser 340 Color Printer...
Page 223: Figure 8-26 Removing The Exit Roller
Field Replaceable Unit Disassembly/Assembly Remove the left E-ring securing the end of exit roller shaft. Remove the bushings and spring and exit roller gear train from the shaft. Remove the exit roller. Paper guide Stripper cover E-ring Bushing Bushing Spring Bushing Gear train E-ring...
Page 224: Lower Feed Roller And Feed Roller Magnetic Clutch
Remove the feed roller drive belt and feed roller pulley. Remove the feed roller bushings. Remove the feed roller. E-ring Bushing Feed roller Feed roller drive belt Bushing I/O board 1 Feed roller pulley E-ring Feed roller clutch 9100-56 Figure 8-27 Removing the feed roller 8-46 Phaser 340 Color Printer...
Page 225: Pick Roller
Field Replaceable Unit Disassembly/Assembly Pick roller Tools required Magnetic screwdriver T-20 TORX tip T-15 TORX tip Turn off the printer and remove the power cord. Remove the paper tray. Remove the right-side and left-side covers as explained in the earlier topic, “Cabinet panels and covers”...
Page 226: Figure 8-28 Removing The Pick Roller
After reinstalling I/O board 1, before turning on the printer, you should always make sure that the head tilt cam gear is latched by the head tilt solenoid and that the head tilt cam gear is disengaged (via its missing teeth) to the drive gear. 8-48 Phaser 340 Color Printer...
Page 227: Head Tilt Cam Gear
Field Replaceable Unit Disassembly/Assembly Head tilt cam gear Turn off the printer and remove the power cord. Open the top cover. Remove the top cover and left-side covers. Disconnect the wiring harnesses leading to I/O board 1. Remove I/O board 1 as detailed in the procedure “I/O board 1” on page 8-53.
Page 228: Replacement
Position the new tilt cam gear as speciﬁed in Step 11 and install it. Rotate the tilt cam gear until it no longer engages with its drive gear. Install the cam follower pin. 8-50 Phaser 340 Color Printer...
Page 229: Figure 8-31 Adjusting The Cam Follower Pin
Field Replaceable Unit Disassembly/Assembly Adjust the cam follower pin: Align the center of the cam follower pin to the centerline of the head tilt cam gear’s groove. Slowly rotate the head tilt cam gear clockwise. As the follower pin enters the narrow portion of the gear’s groove (printhead in the print position), ensure that the pin enters the narrow groove without striking the groove walls.
Page 230 (via its missing teeth) to the drive gear. Reinstall the printer covers. Power-up the printer and make a test print. 8-52 Phaser 340 Color Printer...
Page 231: Circuit Boards
Field Replaceable Unit Disassembly/Assembly Circuit boards I/O board 1 Tools required Magnetic screwdriver T-20 TORX tip T-15 TORX tip Turn off the printer and remove the power cord. Remove the left-side cover as explained in the earlier topic, “Cabinet panels and covers” on page 8-4. Disconnect the wiring harnesses leading to I/O board 1.
Page 232: I/O Board 2 And I/O Board 3
Disconnect the wiring harnesses leading to I/O board 2. Remove the ﬁve screws securing I/O board 2 to the engine frame. Remove the board. I/O board 3: Disconnect the wiring harness from I/O board 2. Disconnect the remaining wiring harnesses. 8-54 Phaser 340 Color Printer...
Page 233: I/O Board 4
Field Replaceable Unit Disassembly/Assembly Remove the three screws securing I/O board 3 to the engine frame. Remove the board. I/O board 3 Remove screws Remove I/O board 2 screws 9100-62 Figure 8-33 Removing I/O board 2 and I/O board 3 Note Refer to Appendix C “Wiring Diagrams”...
Page 234: Power Control Board
Remove the 12 screws securing the rear plate to the engine frame. Lift the plate and attached fan out of the way. Disconnect the wiring harnesses leading to the power control board. Remove the two vacuum accumulator securing screws. Remove the vacuum accumulator. 8-56 Phaser 340 Color Printer...
Page 235: Figure 8-34 Removing The Power Control Board
Field Replaceable Unit Disassembly/Assembly Remove the three screws securing the power control board to the engine frame. Lift and remove the power control board. Power control board e t ® a r t r v ic r a ll Remove D is D IP screws...
Page 236: Interconnect Board
Remove the printhead as explained in the earlier topic, “Printhead” on page 8-37. Remove the main board as explained in the later topic, “Main board” on page 8-60. Disconnect the wiring harnesses leading to the interconnect board. Remove the drum maintenance cartridge. 8-58 Phaser 340 Color Printer...
Page 237: Figure 8-35 Removing The Interconnect Board
Field Replaceable Unit Disassembly/Assembly Remove the seven screws securing the interconnect board to the engine frame. Lift and remove the interconnect board. Interconnect board Remove screws 9100-60 Figure 8-35 Removing the interconnect board Service Manual 8-59...
Page 238: Main Board
ROM SIMM and the RAM SIMM. NV RAM chip rv ic ra ll D is rv ic e t® e rn E th Printer ID a rt chip Main board 9100-63 Figure 8-36 Removing the main board 8-60 Phaser 340 Color Printer...
Page 239: Ram Simm
RAM SIMM The Phaser 340 Plus accepts either a 4 MByte and or a 16 Mbyte RAM SIMM. The base Phaser 340 accepts either a 4 MByte and or a 16 Mbyte RAM SIMM but only recognizes 4 Mbytes. Power down the printer. Leave the power cord plugged in to provide a ground path for static discharges.
Page 240: Code Rom Simm
Figure 8-38 Installing the code ROM SIMM on the main board Reinstall the card cage top and the rear cabinet panels. Reconnect the host interface cables. Turn on the printer and make a test print. 8-62 Phaser 340 Color Printer...
Page 241: Network Card
Field Replaceable Unit Disassembly/Assembly Network card Power down the printer. Leave the power cord plugged in to provide a ground path for static discharges. Remove the interface cable. Loosen the two securing screws holding the Phaser Share network card and remove it. Slide in the replacement network card and tighten the two thumb screws.
Page 242: Enabling Tcp/Ip With The Authorization Code
Customer Support. A staff member of the Customer Support Hotline can generate an authorization code for an Ethernet-capable printer anytime once purchase of the TCP/IP option has been conﬁrmed, even long after the Ethernet card was installed. 8-64 Phaser 340 Color Printer...
Page 243: Checks And Adjustments
Extension tip 003-1388-00 T10 TORX tip 003-0814-00 T15 TORX tip 003-0966-00 T20 TORX tip 003-0866-00 T25 TORX tip 003-1462-01 Phaser 340 tool kit 650-3300-00 Torque-limiting screwdriver 003-0827-00 Printhead-to-drum gap tool 003-1499-00 Encoder disk spacer tool 003-1489-00 Y-axis belt tensioner 003-1500-00 9/64”...
Page 244: Front Panel Menu
Default tray: upper Demonstration pages Default tray: lower Default tray: auto Cleaning page source Cleaning page source: tray Cleaning page source: manual Energy Star timeout Timeout: XX hrs. Figure 9-1 Main menu roadmap (printers serial-numbered B0xxxxx thru BBxxxxx) Phaser 340 Color Printer...
Page 245: Figure 9-2 Main Menu Roadmap (Printers Serial-Numbered B0Xxxxx Thru Bbxxxxx - Continued)
Checks and Adjustments To access the Service Support Menu , scroll to the main menu item Service Support and then press the Menu and Exit button together. Pressing Menu alone allows you to access the printer copy counts, fault history and the printer’s altitude setting. The following illustrations show the menu structure for Version 1 and Version 2 printers.
Page 246: Figure 9-3 Main Menu Roadmap (Printers Serial-Numbered Bcxxxxx And Up)
Cleaning page source: lowerl Parity: space Energy Star timeout Parity: none Timeout: XXX hrs. Flow control Flow control: XON/XOFF Flow control: DTR LocalTalk LocalTalk: enabled LocalTalk: disabled Figure 9-3 Main menu roadmap (printers serial-numbered BCxxxxx and up) Phaser 340 Color Printer...
Page 247: Bypass Mode (Version 2 Printers)
Checks and Adjustments Option P3 installed Option P2 or P4 installed Service support Language Printer defaults Serial settings Network settings "menu & exit" Default tray Data rate Language: English TCP/IP "menu" Engine copy count Cooldown for Power Off Default tray: upper Language: Español TCP/IP: enabled Data rate: XXXXX...
Page 248: Cool Down Mode (Version 2 Printers)
Scroll to the menu item Test Prints and press the Menu button to access it list of test prints. Scroll to the desired test print and press the Print button. Refer to Appendix B Test Patterns ; it discusses each test print and what printing defect it reveals. Phaser 340 Color Printer...
Page 249 Checks and Adjustments Printing the conﬁguration page While the printer is idle, press the Menu button to enter the printer’s menu. Scroll to the Help pages menu item. Press the Print button to print the conﬁguration page. The conﬁguration page shows a great deal of information regarding the data and set-up values stored in NVRAM.
Page 250: Adjustments
Do not over-tension the belt. Paper feed belt tensioner Press here to check belt deflection 9100-71 Figure 9-5 Setting paper-feed belt tension Reinstall the left side panel. Phaser 340 Color Printer...
Page 251: Y-Axis Belts Tension Adjustment
Checks and Adjustments Y-axis belts tension adjustment Perform this procedure after loosening or removing the y-axis belt drive assembly. Ensure that the three screws that secure the Y-axis drive assembly are 1/4 turn loose. Attach the Y-axis belt tension tool (in its unloaded or folded out position) to the keyholes in the side frame of the printer just below and in front of the Y-axis drive assembly.
Page 252: Figure 9-6 Setting The Y-Axis Belt Tension
Reassemble the printer and make a test print. Tighten screws after setting tension Attach tension tool to keyholes Y-axis belt assembly Pull lever arm to set tension 9100-68 Figure 9-6 Setting the Y-axis belt tension 9-10 Phaser 340 Color Printer...
Page 253: Printhead-To-Drum Spacing Adjustment
Checks and Adjustments Printhead-to-drum spacing adjustment Tool required Printhead-to-drum gap tool Small (3/16 in.) flat-blade screwdriver 9/64 in. hex tip Magnetic screwdriver T-20 TORX tip PC diagnostic software This procedure assures that the printhead is the proper distance from the drum. Make this adjustment after removing or replacing the printhead.
Page 254: Figure 9-8 Spacing The Printhead To The Drum
Repeat the gap adjustment in Step 7 for the other end of the printhead. Snug the four locking screws using an X-pattern. Then tighten the four screws, using the same X-pattern, to 20 in./lbs. Recheck the gap on both end of the printhead. 9-12 Phaser 340 Color Printer...
Page 255: Cap/Wipe/Purge Assembly Belt Adjustments
Checks and Adjustments 10. Reinstall the dust cover and top cover. Cap/wipe/purge assembly belt adjustments The tension of the cap/wipe/purge assembly belts is factory-set. Do not adjust them. The belts are kevlar-reinforced; they will not stretch over their lifetime. The belts are also factory-adjusted for parallel tracking (alignment). As long as the belts, cap/wipe/purge assembly motor, or the belt clips (which hold the cap/wipe/purge assembly) are not disturbed, no adjustment is needed.
Page 256: Figure 9-9 Aligning (Timing) The Cap/Wipe/Purge Assembly Drive Belts
Check for equal gaps left-side drive shaft gear. here. No more than 0.045 inch. Left-side drive shaft gear Slots in the Cap/wipe/purge chassis frame assembly drive motor 9100-80 Figure 9-9 Aligning (timing) the cap/wipe/purge assembly drive belts 9-14 Phaser 340 Color Printer...
Page 257: Drum Position Encoder Gap
Checks and Adjustments Drum position encoder gap This procedure ensures that the drum position sensor assembly’s encoder wheel rotates freely inside the gap of the drum position sensor without the encoder wheel’s disk touching the sensor. If the disk touches the sensor, it can abrade the disk and result in erroneous drum position readings.
Page 258: Figure 9-10 Setting The Drum Position Encoder Gap
Checks and Adjustments Gap tool Groove Retaining spring Drum position sensor assembly 9100-67 Figure 9-10 Setting the drum position encoder gap Remove the gap tool. Reassemble the printer and make a test print. 9-16 Phaser 340 Color Printer...
Page 259: Vacuum Check
Checks and Adjustments Vacuum check Tools required Magnetic screwdriver Vacuum gauge T-20 TORX tip T-15 TORX tip PC diagnostics Use this check to verify the actions of the vacuum pump and the solenoid valve. In addition, you can determine if the cap/wipe/purge assembly is sealing properly against the printhead faceplate.
Page 260: Figure 9-12 Selecting The Vacuum Check Test
Check the cap/wipe/purge assembly is properly positioned by performing the “Cap/wipe/purge assembly belt adjustments” on page 9-13. 9-18 Phaser 340 Color Printer...
Page 261: Adjusting For Best Print Quality
Checks and Adjustments Adjusting for best print quality Ensure that the printer is in proper mechanical adjustment. If necessary, perform the following adjustments: a. “Y-axis belts tension adjustment” on page 9-9. b. “Printhead-to-drum spacing adjustment” on page 9-11. c. “Cap/wipe/purge assembly belt adjustments” on page 9-13. At the front panel, select 300 x 300 dots-per-inch mode.
Page 262: Figure 9-14 Printhead Weak Jet Adjustment
Once 300x 300 dpi printing is OK, exit the PC diagnostics, restart the printer and change the front panel printing resolution to 600 x 300 (if the printer supports it). Repeat this process from Step 3. 9-20 Phaser 340 Color Printer...
Page 263: Resetting Nvram
Checks and Adjustments Resetting NVRAM Resetting NVRAM returns all the image processor's NVRAM-stored parameters to their factory defaults except the print count (for images processed through the image processor) and the Adobe ﬁrmware serial number. If you do not wish to reset the NVRAM-stored parameters of an installed Phaser Share card, then remove the card before performing this procedure.
Page 264: Viewing Nvram Contents
Checks and Adjustments Viewing NVRAM contents You can use the PC diagnostics’ NVRAM Test menu to select a test item that lets you view the contents of NVRAM. Figure 9-16 Viewing NVRAM contents 9-22 Phaser 340 Color Printer...
Page 265: Field Replaceable Units List
Appendix Field Replaceable Units List This appendix provides a list of ﬁeld replaceable units for the Phaser 340 Color Printer. Changes to Tektronix products are made to accommodate improved components as they become available. It is important when ordering parts to...
Page 266 Cover, Stripper Access 200-4225-01 Cover, Top 200-4187-01 Cover Side, Right 200-4274-00 Cover Side, Left 200-4189-00 Cover, Back 367-0454-00 Handle, Release Lever 214-4639-00 Pivot Hinge, Front Cover 200-4220-00 Cap, Head Restraint 334-8366-25 Logo Marker, Z340/Z340P 334-8366-29 Logo Marker, Z340J Phaser 340 Color Printer...
Page 267: Figure A-1 The Printer Exterior Frus
Field Replaceable Units List 9100-75 Figure A-1 The printer exterior FRUs Service Manual...
Page 268 Fuse, 6.3A, DIN, F1, F2, F3, F5 650-3261-00 Motor, Stepper, Cap/Wipe/Purge Assembly, includes items 23 and 24 Belt, Cap/Wipe/Purge Drive - part of 650-3268-00 belt kit Drive Gear - part of 650-3296-00 kit 650-3266-00 Solenoid Valve Assembly. Phaser 340 Color Printer...
Page 269 Field Replaceable Units List Table A-2 FRU interior parts list Figure Part number Serial number Quantity Name and description A-2 parts Effective Discontinued 343-1580-00 Restraint, Printhead Shipping Assembly 174-3402-00 Cable, Power Supply 650-3363-00 Circuit Board, I/O 3 650-3262-00 Exit Gear Assembly 119-4893-00 Fan, Drum Cooling 650-3259-00...
Page 270 Spring, Exit Disengage Spring, Belt Tensioner, Left Spring, Paper Tray Flag Spring, Drum Maintenance, Pivot Spring, Actuator Return, Jam Access Spring, Motor Mount, Right 650-3299-00 Shaft Roller Kit Roller, Exit Roller, Lower Transport Cam, Drum Maintenance Phaser 340 Color Printer...
Page 271: Figure A-2 The Printer Interior Frus
Figure A-2 The printer interior FRUs 9100-76 Service Manual...
Page 272 Gear, Compound, Paper Path Assembly 401-0709-01 Clutch, Paper Pick 401-0710-00 Clutch, Drum Maintenance Cam Shaft Belt, Paper Path Transport - part of 650-3268-00 Belt Kit 401-0733-01 B0 xxxxx BB xxxxx Head Tilt Cam Gear 401-0751-00 BC xxxxx Phaser 340 Color Printer...
Page 273: Figure A-3 The Printer Interior Frus (Left Side
FRU Replaceable Parts List Table A-4 supplies and accessories (cont'd.) Part number Serial number Quantity Name and description Effective Discontinued Supply 016-1307-00 Black Ink Stix (3 per box) Supply 016-1308-00 Cyan Ink Stix (3 per box) Supply 016-1309-00 Magenta Ink Stix (3 per box) Supply 016-1310-00 Yellow Ink Stix (3 per box)
Page 274 Tray, Paper. (A) US letter, For LPTA Supply 436-0289-00 Tray, Paper, (A4) Metric, For LPTA 436-0277-00 Lower Tray Assembly w/ Letter Tray 436-0287-00 Lower Tray Assembly w/ A4 Tray 9100-124 Figure A-4 Lower Paper Tray Assembly FRUs A-10 Phaser 340 Color Printer...
Page 275: Test Patterns
Appendix Test Patterns This appendix illustrates the service test prints produced by the printer. It shows a number of defective prints and the reason for the defects. Chapter 6 Troubleshooting discusses solutions to the problems shown in this appendix. The test prints 8 push the printer to the extremes of its performance to reveal possible shortcomings.
Page 276 Test Patterns Printers serial numbered B0 xxxxx to BB xxxxx . Service Test Print 2 - Weak jet. This print shows which jets are not outputting enough, if any, ink compared to its neighboring jets. Note that the yellow jets bands have a small amount of cyan ink added to them, which tints them green, to make them more visible.
Page 277 Test Patterns Printers serial numbered B0 xxxx x to BB xxxxx . Service Test Print 4 - Reverse text. This print in 10 point Times-Roman ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz1234567890 300 dpi indicates if the printhead is outputting 8 point Times-Roman ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz1234567890!@#$%^&* properly-sized drops of ink and that the drum 6 point Times-Roman ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz1234567890!@#$%^&* 5 point Times-Roman ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz1234567890!@#$%^&* temperature is not too high.
Page 278 Test Patterns Printers serial numbered B0 xxxxx to BB xxxxx . Service Test Print 6 - Black vertical lines. This print is made up of alternating vertical black and white lines. It reveals variations in the ink drop spread caused by thermal variations or transﬁx roller pressure variations or uneven oiling of the drum.
Page 279 Test Patterns Printers serial numbered B0 xxxxx to BB xxxxx . Service Test Print 7 - Horizontal lines. This print consists of horizontal lines of alternating color. If the Misconverged printhead is not square to the drum, then variations secondary colors may appear in this print.
Page 280 The ink loader, without the top cover installed to secure it in place, may rest too low and interfere with the printhead’s motion. In this case the ink loader should rest on extrusions on the printer’s side frames 9100-113 Phaser 340 Color Printer...
Page 281 Test Patterns Printers serial numbered BC xxxxx and up. Service Test Print 2 - Weak jet. This print shows which jets are not outputting enough, if any, ink compared to its neighboring jets. Note that the 1 2 3 4 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 yellow jets bands have a small amount of cyan ink added to them, which tints them green, to make...
Page 282 Likewise, some defects do not show until projected. Causes: The ink drops from the jets are traveling in incorrect trajectories. The printhead is incorrectly mounted or its printhead-to-drum spacing is incorrect. 9100-117 Phaser 340 Color Printer...
Page 283 Test Patterns Printers serial numbered BC xxxxx and up. Service Test Print 6 - Black dither pattern. This print is made up of a 66% black ﬁll. It reveals variations in the ink drop spread caused by thermal variations or transﬁx roller pressure variations or drum oiling variations.
Page 284 Check the drum temperature sensor for debris build-up on the sensor or the sensor is in improper contact with the drum. Refer to Test Print 4. The transﬁx pressure is incorrect. Replace the drum/transﬁx assembly. 9100-119 B-10 Phaser 340 Color Printer...
Page 285: Figure C-1 Print Engine Wiring Diagram
Appendix Wiring Diagrams Ink Melt Aux. Parallel SCSI Power Supply Heater Paper Optional Lower Tray Ink Melt Paper Tray Assembly Network JP71 Heater Card Postscript Ink Melt Heater Printer ID ROM Ink Melt PE ROM Heater Triac Heater Rear Fan Control +5V, +12V, -12V Main Board...
Page 286: Figure C-2 Wire Dressing Around The X-Axis Drive
Figure C-2 Wire dressing around the x-axis drive Figure C-3 Wire dressing the vacuum hose and drum fan Phaser 340 Color Printer...
Page 287: Figure C-4 Wire Dressing Behind The Printhead
Wiring Diagrams Figure C-4 Wire dressing behind the printhead Figure C-5 Routing ink loader sensor wiring harness Phaser 340 Service Manual...
Page 288: Figure C-6 Routing Wiring On The Left Side Of The Printer
Wiring Diagrams Figure C-6 Routing wiring on the left side of the printer Phaser 340 Color Printer...
Page 289 Index Numerics 29K processor power-up error codes 6-3 dark prints, light prints 6-14 68K processor power-up error codes 6-4 desktop printer icon 2-22 drum/transﬁx assembly, theory 5-3 accessing printer’s web page 4-10 adjusting for best print quality 9-19 electrical speciﬁcations 1-18 Adobe PostScript Level 2 1-2 electronic bulletin board 4-7 AppleTalk 2-22...
Page 290 5-5 Phaser 340 drivers memory consideration 1-3 installing driver 2-21 Microsoft Windows installing GX driver 2-22 standard PostScript printer driver 2-28 Phaser 340, description 1-2 Phaser copyStation 2-13 PhaserLink 4-10 physical dimensions 1-16 power problems 6-41 power supply theory 5-14...
Page 291 1-16 clearances 1-16 printer dimensions 1-16 electrical 1-18 printer drivers environmental 1-19 icon not appearing 2-22 functional 1-17 Phaser 340 2-21 2-22 physical 1-16 Printer Information Server 4-10 Standard Windows PostScript driver printer page description ﬁle 3-3 updating 2-28 printhead...
Page 292 4-10 weight of paper, allowed 6-10 white portion of print is colored 6-13 Windows 3.1 driver veriﬁcation 3-5 VMS, printing 3-10 Windows 3.1, Tektronix driver 2-25 Windows printer driver conﬁguring 2-26 installing 2-25 wire dressing C-2 wiring diagram, printer C-1...

Tektronix Phaser 340 Service Manual

Figure 1-1 the Phaser 340 Printer (Shown with Optional Lower Paper Tray Assembly)

1 General Information

Figure 1-2 Internal Features of the Print Engine

Figure 1-3 Circuit Boards of the Print Engine (Right Front View)

Figure 1-4 Circuit Boards of the Print Engine (Left-Rear View)

Figure 1-5 the Printer's I 2 C Bus

Figure 1-6 Printhead Maintenance System of the Print Engine

Figure 1-7 Left-Side Sensors and Switches on the Print Engine

Figure 1-8 Right-Side Sensors and Switches on the Print Engine

Figure 1-9 Solenoids on the Print Engine

Figure 1-10 Features of the Main Board

Table 1-2 Physical Dimensions

Table 1-3 Printer Clearances

Table 1-5 Electrical Specifications

2 Installing the Printer and Drivers

Verifying the Printer and Host Connections

4 Key Operator Training

5 Theory of Operation

Figure 5-1 Overview of the Printer

Figure 5-5 the Printhead

Figure 5-6 the Ink-Jet Array Nozzle Arrangement and Cross-Section

Figure 5-7 X-Axis Printhead Movement During Printing

Figure 5-8 the Printhead Tilting Mechanism

Figure 5-9 the Ink Loader

6 Troubleshooting

Table 6-1 29K Processor Power up Self-Test Error Codes

Table 6-2 68K Processor Power up Self-Test Error Codes

Table 6-4 Front Panel and Fault History Log Error Codes and Messages

Table

Figure 6-2 Turning off Appletalk

Figure 6-5 the Diagnostics Global Help Screen

Figure 6-6 the Test Suite List

Figure 6-4 PC-Based Diagnostics Screen Display

Figure 6-7 the Individual Test Within a Selected Test Suite

Figure 6-10 Sensor Test Summary

Table 6-6 Front Panel Indicators and Their Meanings

Figure 6-12 the Thermal Test

Figure 6-11 Test Result of a Motor Motion Test

Table 6-10 Workstation Printing Problems

7 Cleaning and Maintenance

Figure 7-1 Phaser 340 Cleaning Page

8 Field Replaceable Unit Disassembly/Assembly

Figure 8-1 Removing the Lower Paper Tray Assembly

Figure 8-2 Removing the Printer Panels and Covers

Figure 8-3 Removing the Ink Loader

Figure 8-21 Removing the X-Axis Drive Assembly

Quick Links

Related Manuals for Tektronix Phaser 340

Summary of Contents for Tektronix Phaser 340
