Instructions Phaser® 340 16-Mbyte RAM SIMM Installation — (4685F16) Only proprietary Tektronix RAM SIMMs will operate correctly in Tektronix Color printers. Static electricity precautions Leave the printer plugged into its power outlet; this preserves a ground path for static discharges.
Page 2
16-Mbyte RAM SIMM Installation — (4685F16) Installation Power down the printer. Leave the power cord plugged in to provide a ground path for static discharges. Remove the interface cables. Loosen the two rear panel securing screws. Slide out the main board. NV RAM chip rv ic...
Page 3
Reinstall the main board into the printer. Reconnect the host interface cables. Turn on the printer and print the startup page; it indicates the amount of RAM installed in the printer. Refer to the Phaser 340 User Manual for details on printing the startup page.
