Repacking the Color Printer
and Its Accessories
Overview
It is very important that you follow the correct repacking procedure before shipping the color printer.
Complete repacking is required. Failure to properly repack the printer can damage the printer's internal
components. You are responsible for any shipping damage to the printer that results from improper or
inadequate packaging.
Repacking for shipment consists of five basic tasks. Each of these tasks is explained below. If you have
questions regarding any of the repacking procedures, call the Tektronix Customer Support Hotline at
1-800-835-6100 , or contact Tektronix online at www.tek.com/Color_Printers/support/ .
1. Turn off the printer using the On/Off switch.
2. Wait 30 minutes before moving the printer to allow the ink to solidify.
3. Remove the maintenance tray, seal it in a plastic bag, and store the tray on a flat
surface. A used maintenance tray leaks drum fluid if tipped.
4. Lock the printhead transit restraint on the right side of the printer.
5. Repack the printer and its accessories using Tektronix-approved packing materials.
Turning off the printer
Use the rear-panel On/Off switch to turn off the printer. Doing so places the printhead in the proper
position for locking (described below), which is necessary for safe shipment. Do not turn off the printer by
pulling the power cord.
Caution
To avoid damaging the printer's internal components, always turn the printer
power off using the On/Off switch. Failure to do so may result in damage to the
!
printer's internal components during shipment.
Waiting for 30 minutes
1. After turning off the printer, let it cool down for at least 30 minutes before you move
it so that the melted ink inside the printer has time to solidify.
2. Disconnect the power cord and other cables from the printer.
3. Remove the media tray from the printer.
4. If present, disconnect the Lower Paper Tray Assembly cable from the printer.
©
Copyright
1997 by Tektronix, Inc. All rights reserved.
063-2434-03
Advertisement
Related Manuals for Tektronix Phaser 360
Summary of Contents for Tektronix Phaser 360
-
Page 1: Turning Off The Printer
