3Com VCX V7122 User Manual page 251

Element Element's
Description
<help> Catch a help event
<if> Simple conditional
logic
<link> Specify a transition
common to all
dialogs in the link's
scope
Generate a debug
<log>
message
<menu> A dialog for choosing
amongst alternative
destinations
<noinput> Catch a noinput
3Com VCX V7122 SIP VoIP Gateway User Manual
Parameters Parameter's Description
Declares the base URI from which relative URIs are
base
resolved. (NOT SUPPORTED)
The URI specifying the location of the grammar and
src optionally a rulename within that grammar, if it is
external.
Either "document", which makes the grammar active
in all dialogs of the current document or "dialog", to
scope
make the grammar active throughout the current
form.
type The media type of the grammar.
count The event count.
An optional condition to test to see if the event is
cond
caught by this element.
next The URI to go to.
Like next, except that the URI is dynamically
expr
determined.
The event to throw when the user matches one of
event
the link grammars.
An ECMAScript expression evaluating to the name
eventexpr of the event to throw when the user matches one of
the link grammars.
A message string providing additional context about
message
the event being thrown.
An ECMAScript expression evaluating to the
messageexpr
message string.
dtmf The DTMF sequence for this link.
label A string which may be used.
expr An ECMAscript expression evaluating to a string.
id The identifier of the menu.
scope The menu's grammar scope.
When set to true, the first nine choices that have not
Dtmf explicitly specified a value for the dtmf attribute are
given the implicit ones "1", "2", etc.
count The event count.
Supported
251
