2
Set the BootP and TFTP preferences (see
3 Add client configuration for the VoIP gateway that you want to initialize by the BootP,see
Configuring the BootP Clients
4 Reset the VoIP gateway, either physically or remotely, causing the device to use BootP
to access the network and configuration information.

BootP/TFTP Application User Interface

Figure 65 shows the main application screen for the BootP/TFTP utility.
Figure 65
Main Screen

Function Buttons on the Main Screen

•
Pause: Click this button to pause the BootP Tool so that no replies are sent to
BootP requests. Click the button again to restart the BootP Tool so that it
responds to all BootP requests. The Pause button provides a depressed graphic
when the feature is active.
•
Edit Clients: Click this button to open a new window that enables you to enter
configuration information for each supported VoIP gateway. Details on the Clients
window are provided in
•
Edit Templates: Click this button to open a new window that enables you to
create or edit standard templates. These templates can be used when
configuring new clients that share most of the same settings. Details on the
Templates window are provided in
•
Clear Log: Click this button to clear all entries from the Log Window portion of
the main application screen. Details on the log window are provided in
Log Window
3Com VCX V7122 SIP VoIP Gateway User Manual
Setting the Preferences
on page 199.
Configuring the BootP Clients
Managing Client Templates
on page 196.
on page 197).
on page 199.
on page 203.
195
