Installing and Uninstalling the Software

2-1-9 Starting the CX-Process Tool

5. When the uninstallation has been completed, the following dialog box will be

displayed. Click the Finish Button. The Add/Remove Programs Dialog Box

or Add/Remove Applications Dialog Box will be displayed again.

6. In the same way, select CX-Server from the Add/Remove Programs Dialog

Box, click the Change/Remove Button, and uninstall the CX-Server follow-

ing the messages that appear on the screen.

7. Reboot the computer.

1. Select Program - OMRON - CX-One - CX-Process Tool - CX-Process

Tool from the Windows Start Menu. The following dialog box will appear to

select the communications driver.
