Overview of User Interface
Menu Instruction
Validate Action Start
Stop
Pop-up Menu (Menu Displayed by Clicking Right Button)
Pop-up menu command
Data Configuration
Edit Mode
Select Cell
Draw Line
Delete Line
Symbols y
Selected
Edit
Annotation
Bring to Front
Send to Back
Send Behind Symbols
and Lines
Font Size
Cut
Copy
Paste
Starts checking the operation of the ladder diagram.
Ends checking the operation of the ladder diagram.
Description
Inputs an operand.
Set the cursor to normal selection
status.
Sets line connection mode.
Sets line deletion mode.
LOAD Inputs a condition.
LOAD Inputs a NOT condition.
NOT
OUT Inputs an output.
OUT NOT Inputs a NOT output.
SET Inputs a SET instruction.
RESET Inputs a RESET instruction.
ON DIFF Inputs an upward differentiation
instruction.
OFF DIFF Inputs a downward differentiation
instruction.
STEP Inputs a STEP declaration.
Declara-
tion
BLOCK Inputs a BLOCK SET instruction.
SET
BLOCK Inputs a BLOCK RESET instruction.
RESET
JUMP Inputs a JUMP instruction.
STEP Inputs a STEP TIMER instruction.
TIMER
ALARM Inputs a ALARM TIMER instruction.
TIMER
Annota- Inputs a comment.
tion
Same as selecting Selected
Annotation/Edit from the Manipulate
Ladder Menu.
Displays the selected annotation in
front of other annotations.
Displays the selected annotation
behind other annotations.
Makes the selected annotation
transparent.
Changes the selected annotation's font
size.
Cuts a selected symbol, area, or line
and places it in the special copy buffer
for CS-Process Tool (i.e., not on the
clipboard).
Copies a selected symbol, area, or line
and places it in the special copy buffer
for CS-Process Tool (i.e., not on the
clipboard).
Pastes the symbol, area, or line from
the special copy buffer for CS-Process
Tool (i.e., not from the clipboard).
Section
Description
Conditions for selection
When an instruction symbol is selected
---
---
---
---
When an annotation is selected
When a symbol, area, or row is
selected
When a symbol, area, or row is
selected
When an area that can be pasted to is
selected
2-2
