CX-Process Tool

1-1-2 Project Workspace

Project Workspace

1-1-3 Files Created with CX-Process Tool

Project File (.mul)
Project Workspace can be used to access the data created in memory with the
CX-Process Tool. Data can be created for up to 32 CPU Units and 96 Loop Con-
trol Units (3 Loop Control Units each for 32 CPU Units) or 32 LCBjjs (1
LCBjj each for 32 CPU Units). The data has the following configuration.
LCU/LCB Elements
(one for each Loop
Controller)
Function Block File
for Each Node (.ist)
00-LCB03
00-LCB01
Node01.ist
00-LCB05
Node02.ist
00-LCB05D
01-LC001
02-LC001
Node32.ist 03-LC001
Project file (.mul)
Project Workspace data is stored in one folder called the project folder. Project
folders are created for the following commands.
• File – New
When a new project is created, the project name will be used as the folder
name.
• File – Save As
When a project is saved under a new name, the new project name will be used
as the folder name.
The CX-Process Tool creates a folder with the project name in the data folder
under the default installation folder for the CX-Process Tool, and then creates
the following files inside the project folder.
The project file consists of administrative data for the Project Workspace.
Files
Function block files
Block diagram information files
Mnemonics/Ladder diagram
information files
Comment files
CSV tag setting files
CX-Server configuration files
Job information files
Loop Controller configuration
files
Data files of user link tables
Data files of sequence tables
The project file (.mul) can be specified when opening files so that the above re-
lated files will be all read at the same time. The project file is created by selecting
New from the File Menu and specifying the project name. The file name will be
the same as the project name.
Function Block Groups
System common
Field terminals
Function Blocks
Block diagrams
File name
extension
.ist
.mtbd
.mtld
.cmt
project_name.csv
.cdm Only when CX-Server is
selected as the
communications driver
.sjb
.lcb
LnkTable.csv
.stbl
Section 1-1
Basic PID
Remarks
3
