Using SCADA Software
146
Setting
Tag name (representative tag)
Tag Comment
Upper Limit
Lower Limit
Decimal Point (number of digits
below decimal point for scaling)
Unit
Note When the node function block is saved, a CSV setting file (named
project_name.CSV) is automatically stored with the following data
added to the user-set data.
Network address
Node address
Unit address
Block model
Block address
Block model name
Note When CX-Server has been selected as the communications driver,
the node address must be set to a non-zero value before compiling
the CSV tag file.
Note Always set tag names. SCADA software uses these to identify data.
16 characters max. (All characters can be
used.)
16 characters max. (All characters can be
used.)
–5,000 to 99,999 (e.g., if decimal point is set to
1: –550.0 to 9,999.9)
–5,000 to 99,999 (e.g., if decimal point is set to
1: –550.0 to 9,999.9)
0 to 9
8 characters max. (All characters can be used.)
Setting
0 to 127
0 to 32
16 to 31, 255
0 to 1000
0 to 1000
---
Section
Setting range
Setting range
