Omron CX-PROCESS TOOL V5.2 - REV 10-2010 Operation Manual page 181

Using SCADA Software
(1) HMI interface tags (Control/operation blocks +
External Controller Terminal Block tags)
Set System Common Block HMI interface-re-
lated ITEMS.
a) When edited by Excel after
automatic registration
1. To register a function block, select the
CSV Tag Auto Register option.
2. When the node function block is
saved (File/Save), the CSV tag setting
file (.csv) is automatically compiled.
3. Using program such as Excel, edit
(tag names, scaling, etc.) the CSV tag
setting file (.csv) in the Projects folder.
4. Open the Projects folder (File/Open).
154
Note OPC server direct access tags can also be added to the RS View tag
file. The procedure is basically the same as when added OPC server
direct access tags to SCADA tag files.
The following flowchart shows all the operations involved in using RS View32 to
specify an ITEM in the Loop Controller.
b) When set individually with
CSV Tags Dialog Box
1. Set CSV tags.
Select the control block or operation
block, and then Settings/Tag Setting/
CSV Tag.
Only when al-
ready edited.
Compile RS View 32 tag file.
(Execution/Create Tag File/RS View Tag)
Import RS View tag files to SYSMAC OPC
Server version 2.4 or higher.
Import the RS View32 tag files to the RS
View32. (RS View Database Import and
Export Wizard)
Specify the tag names from RS View32, and
read/write the Loop Controller's data or the
CPU Unit's I/O memory.
Section 3-4
(2) User link table tags
1. Register user link table tags.
(Settings/Edit/User Link Table)
2. Select the option to output
CSV tag information when reg-
istering the data link table.
2. When compiling CSV tag
files, check
Add User Link Table Informa-
tion.
