Omron CX-PROCESS TOOL V5.2 - REV 10-2010 Operation Manual page 69

Basic Operating Procedures
Using SCADA Software
Using the RS View 32
Step 3: Save the Project
Workspace Data
Step 4: Unit Setup
1, 2, 3...
11.Start the CX-Process Monitor Plus and click the Start Button.
Note For all Loop Controllers, the following function blocks must be
created and connected separately to enable monitoring and setting
individual contact signals and individual analog signals (i.e., other
than function block data).
• To monitor and set individual contact signals, contact signals must be
input/output using the Contact Distributor block (Block Model 201)
and Internal Switch block (Block Model 209).
• To monitor individual analog signals, analog signals must be output
from the Input Selection block (Block Model 162).
• To set individual analog signals, analog signals must be input to the
Constant Generator block (Block Model 166).
Note (1) For details on the CX-Process Monitor, refer to 3-2 Using the CX-Process
Monitor.
(2) For details on the CX-Process Monitor, refer to 3-3 Using the CX-Process
Monitor Plus.
8.Set the Send All Blocks or Receive All Blocks Function Blocks (and if neces-
sary, Expanded CPU Unit Terminal and CPU Unit Terminal Function
Blocks). (Required only for Loop Control Unit; not required for LCBjj.
9.Set the CSV tags (using Tag Settings – CSV Tag from the Settings Menu).
If using CX-Process Tool version 3.1 or higher, automatically register the
CSV tags and then edit the CSV tag settings file in Excel.
10.Output the CSV tag file (using Create Tag File – CSV Tags from the Execu-
tion Menu).
11.Import the CSV tag file for SCADA software into the SYSMAC OPC Server.
12.Manually export the RS View tag file from the SYSMAC OPC Server.
13.Import the RS View tag file to the RS View 32 using the import utility in the RS
View 32.
8.For a Loop Control Unit, register Send All Blocks and Receive All Blocks
blocks. (This is not necessary for LCBjj.)
9.Set the CSV tags (using Tag Settings – CSV Tag from the Setting Menu).
10.Output the CSV tag file (using Create Tag File – RS View Tags from the
Execution Menu).
11.Import the RS View tag file directly to the RS View 32 using the import utility
in the RS View 32.
Note For details on SCADA Software and RS View, refer to 3-4 Preparations for Using
SCADA Software.
Using Save from the File Menu
1. Mount the Units and wire the Analog I/O Units.
The Loop Controller does not need any wiring.
2. Set each Unit to a unique unit number.
3. Connect the Programming Device.
Note With CS1D CPU Units (using the CS1D-CPUjjP), connect to the
active CPU Unit.
4. Turn ON the PLC.
Section 1-7
41
