3-4-2 CSV Output Function for HMI Data Allocation Status

Procedure
Data Format

3-4-3 Other Interfaces with HMI

Starting Face Plate Auto-Builder for NS
Outline
With CX-Process Tool version 3.2 or higher, the allocation status of HMI data can
be output in CSV format. Allocation status shows the EM Area addresses allo-
cated to each tag/tag ITEM.
Note 1. User link table tags are not included.
2. The maximum number of lines is 65,535.
Select Execute – Create Tag File – Create HMI I/F Memory Map. The CSV
tags will be compiled and the CSV tag file will be saved in a file of the specified
name (default: HMI_IFMap.csv).
Analog Data
<tag_name>_<ITEM_tag_name>,<INT or UNIT>,
<allocated_EM_bank_number>_<address>,<comment>
Tag010_P,UINT,E5_89,Basic PID tag
Tag010_I,UINT,E5_90,Basic PID tag
Tag010_D,UINT,E5_91,Basic PID tag
Normal Contact Data
<tag_name>_<ITEM_tag_name>_<bit_position>,<BOOL>,
<allocated_EM_bank_number>_<address>,<comment>
Tag010_R/L_SW_Bit00,BOOL,E5_98,Basic PID tag
Tag010_A/M_SW_Bit01,BOOL,E5_98,Basic PID tag
Tag010_AOF_Bit02,BOOL,E5_98,Basic PID tag
Note If the option to use the CX-Programmer symbol table format is selected, the data
will be saved in a CSV file in a format that can be pasted into a CX-Programmer
symbol table.
Contact Data in CX-Programmer Symbol Table Format
<tag_name>_<ITEM_tag_name>_<bit_position>,<INT>,
<allocated_EM_bank_number>_<address>,<comment>
Tag010_RL_SW_Bit00,INT,E5_98,Basic PID tag
Tag010_AM_SW_Bit01,INT,E5_98,Basic PID tag
Tag010_AOF_Bit02,INT,E5_98,Basic PID tag
• The ITEM name will be deleted if it contains a slash (/).
• All BOOL data will be converted to INT data.
From CX-Process Tool version 4.0, the Face Plate Auto-Builder for NS (NSFP)
can be started in the sequence of operations when compiling CSV tags.
• CX-Process Tool Version 3.2 or Lower
The CSV tags were compiled in advance using CX-Process Tool, and then after
starting the NSFP, the folder path for the previously saved CSV tag file had to be
specified in the parameter setting screen.
• CX-Process Tool Version 4.0
NSFP can be automatically started after CSV tag files are compiled by selecting
Create Tag File Start NSFP from the Execute Menu. Using this method, the
folder path to the CSV tag file that has been created is automatically specified in
the parameter settings screen that is displayed when the NSFP starts.
Note For details on NSFP, refer to the Face Plate Auto-Builder for NS Operation
Manual (W418).
