5.1 Adjustment Items and Overview

This chapter describes adjustments required after the disassembly/reassembly of the printer.

5.1.1 Servicing Adjustment Item List

The adjustment items of this product are shown below.
The product names hereafter called as follows:
C H E C K
P O I N T
Notation
Artisan 810/PX810FW/
TX810FW
Artisan 710/PX710W/
TX710W
Artisan 835/PX820FWD/
TX820FWD
Artisan 725/PX720WD/
TX720WD
Artisan 837/PX830FWD
Artisan 730/PX730WD/
TX730WD
Adjustment Item
Install the Head Nozzle surface parallel to the printing surface and
set the gap between the paper and the Head Nozzle surface to the
specified value.
PG adjustment/PG inspection
ADJUSTMENT
Product name
Epson Artisan 810/Epson Stylus Photo
PX810FW/Epson Stylus Photo TX810FW
Epson Artisan 710/Epson Stylus Photo
PX710W/Epson Stylus Photo TX710W
Epson Artisan 835/Epson Stylus Photo
PX820FWD/Epson Stylus Photo TX820FWD
Epson Artisan 725/Epson Stylus Photo
PX720WD/Epson Stylus Photo TX720WD
Epson Artisan 837/Epson Stylus Photo
PX830FWD
Epson Artisan 730/Epson Stylus Photo
PX730WD/Epson Stylus Photo TX730WD
Table 5-1. Adjustment Items
Purpose
Adjustment Items and Overview
For information on how to carry out the adjustments and
C H E C K
media required for the adjustments, see the instructions
P O I N T
displayed by the adjustment program.
To reduce servicing time, the auto head cleaning (ACL) by the
AID function is disabled when running the adjustment
program. This is temporary setting; therefore, the menu setting
for the ACL on the LCD Panel is maintained. This temporary
setting becomes invalid when powering OFF. (Artisan 810/710/
PX810FW/TX810FW/TX710W only.)
Description in this chapter is applied to Artisan 810/710/
PX810FW/TX810FW/PX710W/TX710W but most of it can also
be applied to Artisan 835/837/725/730/PX820FWD/TX820FWD/
PX830FWD/PX720WD/TX720WD/PX730WD/TX730WD. For
Artisan 835/837/725/730/PX820FWD/TX820FWD/PX830FWD/
PX720WD/TX720WD/PX730WD/TX730WD, see below first and
follow the instructions.
" Artisan 835/725/PX820FWD/TX820FWD/PX720WD/TX720WD:
8.4 Adjustment (p.274)
Artisan 837/730/PX830FWD/PX730WD/TX730WD:
"
9.5 Adjustment (p.321)
Method Outline
For the adjustment method, see "5.3.1.1 PG Adjustment"
If the position of the notch on the Parallelism Adjustment
Busings have not changed, only "5.3.1.2 PG Inspection" (p.233)
is necessary.
Revision G
Tool
(p.229). • Parallelism
adjustment jigs
(two types; the one
for 0th column side
and the one for 80th
column side)
• Fixtures for
precision control
• Thickness Gauge
1.1 mm, 1.3 mm
• Phillips screwdriver
• Hex wrench
