Printer Options (continued)
Menu Item
START OF PRINT
ACTIVE HIGH
EDGE
LOW PULSE
HIGH PULSE
ACTIVE LOW
END OF PRINT
LOW PULSE
HIGH PULSE
ACTIVE LOW
ACTIVE HIGH
RIBBON LOW
ACTIVE LOW
ACTIVE HIGH
SLEW ENABLE
STANDARD
LOW PULSE
HIGH PULSE
ACTIVE LOW
ACTIVE HIGH
I-Class
Selects the type of input signal required to initiate
printing, where:
Triggers printing with a high signal.
Triggers printing with a signal edge transition.
Triggers printing with a low pulse.
Triggers printing with a high pulse.
Triggers printing with a low signal.
Sets the type of output signal generated to indicate End
of Print (EOP), where:
Outputs a low pulse upon completion.
Outputs a high pulse upon completion.
Outputs a logic low upon completion.
Outputs a logic high upon completion.
Sets the low ribbon signal (as determined by RIBBON
LOW OPTIONS; see Section 4.2.2), where:
Outputs a logic low when the roll reaches the setting.
Outputs a logic high when the roll reaches the setting.
Selects the type of input signal required to initiate label
slew, where:
Triggers slew with a low signal.
Triggers slew with a low pulse.
Triggers slew with a high pulse.
Triggers slew with a low signal.
Triggers slew with a high signal.
Details
35
