Communications (continued)
Menu Item
SERIAL PORT D ♦
PARALLEL PORT A ♦
PORT DIRECTION
UNIDIRECTIONAL
BIDIRECTIONAL
PARALLEL PORT B ♦
NIC ADAPTER ♦
QUICK SETUP
WIRED DHCP
WIRED DHCP?
CANCEL KEY = YES
WLAN UNSECURED
WLAN UNSECURED?
CANCEL KEY = YES
WLAN ADHOC
46
Controls the RS-232 communications settings for
optional Serial Port D; see SERIAL PORT A.
Note: The maximum baud is 38.4K BPS.
Controls the communications settings for Parallel Port
A, where:
Allows data return from the printer, where:
Returns no data; communication is one-way.
Returns data (compliant back-channel operation).
Controls the communications settings for optional
Parallel Port B; see PARALLEL PORT A.
Note: The default setting is BIDIRECTIONAL.
Controls the communications settings for the network
interface, where:
Note: Only when equipped with DMXNetII or
DMXrfNetII.
Selects settings to configure basic Wired or WiFi
operations, where:
Selects Wired operation, where:
Returns the NIC Adapter to defaults then sets Wired
Discovery to "Enable" and Wireless to "Disable."
Selects WiFi operation, where:
Returns the NIC Adapter default values then sets
Discovery to "Enable," SSID to "Any," and WLAN
network type to "Infrastructure."
Selects the DMXrfNetII default parameters, where:
Details
