Datamax Iclass Operator's Manual page 64

Diagnostics (continued)
Menu Item
LOOPBACK
PRINT SIGNAL INFO
TEST SCANNER
ALIGNMENT TEST
SCAN TEST
TEST RFID
TAG DATA
DEVICE VERSION
TAG ID – HF ONLY
PRINT TEST RATE (min)
000 (0 - 120)
54
Not Supported
Prints signal names, pin assignments, settings, and
current states for reference.
GPIO SIGNAL INFO
WED 11:04AM 24MAR2003
CARD ID#1
OUTPUT SIGNALS
END OF PRINT
PIN# 6
LOW PULSE
CURRENT LEVEL 1
RIBBON LOW
PIN# 5
ACTIVE LOW
CURRENT LEVEL 1
SERVICE REQUIRED
PIN# 4
ACTIVE LOW
CURRENT LEVEL 0
MEDIA OUT
PIN# 3
ACTIVE LOW
CURRENT LEVEL 1
RIBBON OUT
PIN# 2
ACTIVE LOW
CURRENT LEVEL 1
Tests the Linear Scanner, where:
Reads a bar code then displays the decoded data, the
code type and scan count, repeating.
Reads a bar code then displays the decoded data, the
code type and scan count, non-repeating.
Tests RFID, where:
Reads the data encoded on the RFID chip.
Displays the type and version of the encoding device.
Reads and displays the High Frequency Tag ID number.
Allows a label-to-label delay (0 - 120 minutes) when
printing test label batches, where:
Is the selected delay interval, in minutes.
Details
INPUT SIGNALS
START OF PRINT
PIN# 8
ACTIVE HIGH
CURRENT LEVEL 0
BACKUP LABEL
PIN# 7
DISABLED
CURRENT LEVEL 0
I-Class
