10.1.2 The Structure of the Web MMI

If you click the menu for the "Navigation bar area", the menu will be displayed in the
"Menu display area."
The menu selected in the "Menu display area" will be reflected upon the contents
display area.
Model name
display
Menu display area

1. User Authentication Area: Admin login

The contents of the Navigation bar menu will vary between the Users' mode,
Administrator's mode, and Service mode.
In order to enter the Administrator's mode or Service mode, click the box [admin login]
in the user authentication area, and enter the Username and Password required for
entering each mode.
Mode
Users' mode
Administrator's
mode
Service mode
Signal strength
position display
display
Date/time display
User name
Admin 01234567
Service fb5963
Own vessel
Alarm display
Contents display area
Password Navigation bar area menu
Main, SMS, Contacts, SIM
Main, SMS, Contacts, SIM,
Setting, Device, Log, Selftest
Main, SMS, Contacts, SIM,
Setting, Device, Log, Selftest, Service
10-2
10.1 Overview
User authentication
Navigation bar area
