[Software update procedure of Incoming Indicator FB-3000]
Procedure described here is applicable only when the software is updated from 1.04 or older
version to 01.05.
Notes
1) Files updated by software 1650220-0105 is; ROM.bin, IMAGE.bin.
2) PC OS should be Windows XP.
3) PC and Incoming Indicator is to be connected to LAN port of the communication unit.
Only one unit can be updated at a time.
4) Take a note of original MAC address written on the LAN module.
5) Take a note of Mac address by [Settings] [LAN] [IP address] [lease information]. If reset
to default, address 00-40-9D-43-35-97 is displayed.
6) Do not disconnect LAN cable during software update.
communication unit or the Flash ROM of LAN module can be defective.
7) Save the update software "Maintenance IncInd" of FB-3000 onto the PC used for updating.
Step 1 Software updating
1. Connect PC to communication unit by LAN cable.
2. Turn on the communication unit and check that FB-3000 starts up. It takes two minutes
to start up FB-3000. Press [ACK] and check that buzzer sounds and [ACK] LED lights.
3. Start up the FELCOM500 web software.
4. Change to Admin mode and check the Mac address by [Settings] [LAN] [IP address]
[lease information]. If 00-40-9D-43-35-97 is displayed, it has to be reprogrammed in Step
2.
5. Click MaintenanceIncInd.exe. icon and turn on Maintenance Incoming Indicator.
Note: Japanese characters are included in the screen text that would appear in corrupted
character.
Vista or Windows 7 cannot be used.
Also do not turn off the
