  • Page 1 INMARSAT-C MOBILE EARTH STATION FELCOM 12 MODEL...
  • Page 2 Y o u r L o c a l A g e n t / D e a l e r 9 - 5 2 , A s h i h a r a - c h o , N i s h i n o m i y a , J a p a n T e l e p h o n e : 0 7 9 8 - 6 5 - 2111 T e l e f a x :...
  • Page 3 SAFETY INSTRUCTIONS WARNING WARNING WARNING WARNING Do not open the equipment. Do not operate the equipment with wet hands. Hazardous voltage which can cause electrical shock, burn Electrical shock can result. or serious injury exists inside the equipment. Only qualified Keep heater away from equipment.
  • Page 4 WARNING Label attached Name: Warning Label Type: 16-013-2013-1 Code No.: 100-251-640 Antenna Unit Name: Warning Label(1) Type: 16-003-1011-0 Code No.: 100-236-230 Terminal Unit...

  • Page 5: Table Of Contents

    CONTENTS MENU TREE ..................vii OPERATIONAL OVERVIEW ............viii PROGRAM NUMBER ................ ix FOREWORD ..................1 Introduction ..........................1 Features ............................. 2 About This Manual ........................3 FELCOM 12 System Configuration ..................4 INMARSAT-C SYSTEM ..............5 Introduction ..........................5 Inmarsat System Configuration ....................
  • Page 6 SYSTEM INITIALIZATION ...............2-1 System Settings........................2-1 Two sets of DTEs installed ....................2-1 System setup ........................2-2 Terminal Setup ........................2-6 Login and Logout ........................2-7 Login ..........................2-8 Logout ..........................2-9 EGC Settings ........................2-11 What is the EGC (Enhanced Group Call) service?............2-11 EGC setup.........................2-12 Programming EGC channels ....................2-15 Programming NCS Channels....................2-16...
  • Page 7 INMARSAT-C COMMUNICATIONS ..........4-1 Transmitting ...........................4-1 Code description ......................... 4-1 Transmitting prepared message ..................4-2 Transmitting message stored on floppy disk (multiple address) ........4-9 Canceling transmission.....................4-13 Confirming delivery status (message status list) ..............4-14 Manually requesting delivery status .................4-16 The 2-digit code services ....................4-17 Inserting the destinations of a fax terminal ..............4-19 Receiving ..........................4-20 When a message is received .....................4-20...
  • Page 8 OTHER FUNCTIONS ...............7-1 Aborting an Operation ......................7-1 Scanning NCS........................7-2 Selecting EGC Receiving Channel ..................7-3 Selecting NCS Channel ......................7-4 MAINTENANCE ................8-1 Safety Information ......................... 8-1 General Checking and Maintenance ..................8-2 Cleaning the terminal unit and communication unit ............8-2 Checking connectors and earth terminal ................8-2 Floppy disk drive head .......................8-2 When the power can’t be turned on (power lamp does not light) ........

  • Page 9: Menu Tree

    MENU TREE Numerals in parenthesis are page numbers. F5: Reports F1: File (5-1) 1: Data Report 1: New ALT-N (3-1) (5-4) 2: Message Report 2: Open ALT-O (3-10) (5-8) 3: Date Network ID 3: Close ALT-Q (3-9) 4: Save ALT-S (3-12) F6: Logs 5: Delete...

  • Page 10: Operational Overview

    OPERATIONAL OVERVIEW Power On Login System Initialization Program LES Program Station Prepare Message Saving a message (page 3-8) Retrieving a message (page 3-10) Transmitting Receiving The FELCOM 12 should be turned on for the duration of a voyage. Be sure to logout with Inmarsat-C system before turning off the equipment. Logout Power Off viii...

  • Page 11: Program Number

    PROGRAM NUMBER...
  • Page 12 This page is intentionally left blank.

  • Page 13: Foreword

    FURUNO Electric Company thanks you for considering and purchas- ing the FELCOM 12 Inmarsat-C Mobile Earth Station. We are confi- dent you will discover why the FURUNO name has become synony- mous with quality and reliability. Mainly consisting of an antenna unit, a communication unit and ter-...

  • Page 14: Features

    Features ¡ Conforms to the following standards: IMO A.807(19), MSC. 68(68), Annex 4, IMO A.694(17), IEC 61097-4 (1994), IEC 60945 (1996), IEC 61162-1 (2000) ¡E-mail facility To transmit E-mail, register with the LES provider. E-mail charges are calculated separately. ¡Built in Enhanced Group Call (EGC) receiver permits operation as EGC-only receiver.

  • Page 15: About This Manual

    About This Manual A word about the organization of this manual: It is laid out in a user- friendly manner as possible. We realize a machine like this with its many, many functions can be a little intimidating to even the experi- enced MES operator.

  • Page 16: Felcom 12 System Configuration

    FELCOM 12 System Configuration DISTRESS TYPE IC-302 SEL NO. COMPASS SAFE DISTANCE FURUNO ELECTRIC CO., LTD Antenna Unit Distress Alert Unit IC-302 DISTRESS TYPE IC-302 SEL NO. INMARSAT- C MOBILE EARTH STATION COMPASS SAFE DISTANCE FURUNO FURUNO ELECTRIC CO., LTD...

  • Page 17: Inmarsat-C System

    INMARSAT-C SYSTEM This chapter provides an overview of the Inmarsat-C satellite com- munication system. Introduction The Inmarsat-C system provides worldwide telex and data transmis- sion and reception of written information to owners of an Inmarsat-C transceiver or a terrestrial telex network via satellite. Communication mode is store-and-forward telex, which means all information sent are first stored at a LES and then delivered to desig- nated party.

  • Page 18: Inmarsat System Configuration

    Inmarsat System Configuration Figure 2 Inmarsat-C satellite communication system...
  • Page 19 The Inmarsat-C system consists of the Operation Control Center (OCC), Satellite Control Centers (SCC), Network Coordination Sta- tions (NCS), Land Earth Stations (LES) and Mobile Earth Stations (MES). The OCC, located at Inmarsat’s London headquarters, coor- dinates a wide range of activities in the Inmarsat system, including commissioning of mobile earth stations.

  • Page 21: Communications Network

    Communications Network Figure 4 shows the Inmarsat-C communications network. Network NCS/NCS Signaling Link Coordination Station (NCS) NCS/LES NCS Common Channel Signaling Link Mobile Earth Station (MES) MES Signaling Data Channel Data Terminal Communications Equipment (DTE) Data Circuit Network Land Earth Terminating Station Equipment...

  • Page 22: Types Of Mes

    MES interface The MES consists of the Data Circuit Terminating Equipment (DCE) and the Data Terminal Equipment (DTE). The DCE consists of the antenna unit and the communication unit. And the DTE consists of the terminal unit (or a PC), keyboard and printer.

  • Page 23: Peripheral Equipment

    Peripheral Equipment The following equipment can be additionally connected to the FELCOM 12. Distress/Urgent Receiving Unit (IC-303) The IC-303 releases an audible alarm and blinks the lamp when dis- tress message is received. (Refer to page 4-26 for further details.) When an EGC distress or urgent message is received, with an aural alarm and blinking lamp.
  • Page 24 This page is intentionally left blank.

  • Page 25: Operational Overview

    On its front panel you should see the POWER switch and POWER lamp. Normally, the power is left on while underway. POWER POWER lamp Switch FURUNO INMARSAT- C MOBILE EARTH STATION POWER NAME PLATE Figure 1-1 Communication unit IC-212 Self test When the communication unit is turned on it conducts a series of self-tests to check itself for proper operation.

  • Page 26: The Terminal Unit

    The Terminal Unit The DTE may consist of IB-581 or IBM compatible pc. All opera- tions are carried out from the terminal unit, through an easy-to-un- derstand menu system. For personal computer connection a system disk (supplied) is required to boot up the computer. Opetarion by a computer is the same as with the terminal unit except when turning on the power.

  • Page 27: Printer Pp-510 (Optional Supply)

    Printer PP-510 (optional supply) The printer prints transmitted and received messages. The POWER switch is on the right side of the unit. A lamp on the switch lights when the power is on. If the paper is set correctly the ON LINE lamp also lights.

  • Page 28: Keyboard

    Keyboard The FELCOM 12 is almost 100% keyboard controlled. Operation is simplified by the use of menus which you access by pressing func- tion keys, numbered F1-F10 at the top of the keyboard. Figure 1-4 shows keyboard layout. Insert Delete Prt Sc Scroll Pause...
  • Page 29 Shift Selects upper or lower case letters. Press and hold down the key to get upper case letters. Note that only upper case letters are used in telex. Executes the shortcut key operation when combined with an alphabet key. Space Bar Inserts a space.

  • Page 30: Shortcut Key Operation

    Shortcut key operation The FELCOM 12 provides the keyboard shortcuts shown below for commonly used functions. Table 1-2 Shortcut keys Short Cut key Operation ALT+N Same as NEW in File menu ALT+O Same as OPEN in File menu ALT+Q Same as CLOSE in File menu ALT+D Same as DELETE in File menu ALT+S...

  • Page 31: Selecting Menu, Menu Options

    Selecting menu, menu options Press appropriate function key to select a menu. For example, press [F1] to select the File menu. File Edit Transmit Reports Logs Options Setup Position StopAlarm File 1. New ALT-N 2. Open ALT-O 3. Close ALT-Q 4.

  • Page 32: Sample Menu Operation

    Sample menu operation For example, you want to display a transmitted message. All opera- tions begin from the standby display. File Edit Transmit Reports Logs Options Setup Position StopAlarm Date 97-08-04 BBER Time 01:32 (UTC) OK ( 36dB) Send level OK ( 0) Position RxIF AGC Level...

  • Page 33: Display Indications

    Display Indications The display is divided in three sections: 1) The menu area 2) The working area 3) The operating status area 1 Function File Edit Transmit Reports Logs Options Setup Position StopAlarm Menu 2 WORKING AREA 3 Operating Status (10) (10) Figure 1-10 Location of display indications...
  • Page 34 (3) Communication unit status Idle Idle (awaiting receiving, awaiting trans- mitting) Idle (pending) Awaiting reply from LES Sending During message transmission Receiving During receiving Login Logging in with NCS Logout Logging out with NCS Distress Alert When own vessel is transmitting the distress alert Data Report During transmission of data report...

  • Page 35: Error Messages And Alerts

    (7) Logging status LOGOUT Logged out with ocean region LOGIN Logged in with ocean region LOGIN (blinking) Logging in with ocean region (8) Other information No display No receive message in memory, or printer is operating. REC. MESSAGE EXISTS Displayed when a routine message has (blinking) not been printed, or a confidential mes- sage is received.

  • Page 36: Silencing The Audible Alarm

    Silencing the Audible Alarm Some error messages and alerts are accompanied by the audible alarm. This alarm can be silenced, in most instances, by pressing any key. If the alarm cannot be silenced in that manner, go to the Setup menu to silence it.
  • Page 37 File Edit Transmit Reports Logs Options Setup Position StopAlarm Setup 1. Distress Alert Setup 2. System Setup 3. Editor Setup 4. Terminal Setup 5. EGC Setup 6. Auto Mode Setup 7. E-Mail Setup 8. Directories 9. Configuration Current State: IDLE SYNC ( NCS ) 97-08-04 01:42 (UTC) NCS: IOR...

  • Page 38: Contents Of Program Disk

    Contents of program disk READ.ME: Instructions for installation of software IBINST.BAT: English software for IB-581 IBRINST.BAT: Russian software for IB-581 PCINST.BAT: English software for PC PCRINST.BAT: Russian software for PC INSTALL.BAT: Program start up FELCOM12.EXE: Terminal software ENGLISH.DAT: English text definition file RUSSIAN.DAT: Russian text definition file ENH_FONT.EXE:...

  • Page 39: System Initialization

    SYSTEM INITIALIZATION This chapter provides the information necessary for initializing the FELCOM 12. Once the FELCOM 12 is initialized you need do no more than press a few keys to get fully automatic transmission and reception. Inmarsat assigns each MES an Inmarsat Mobile Number (IMN). The IMN has already been entered into the FELCOM 12.

  • Page 40: System Setup

    System setup The System Setup menu provides for input of date, time, operating mode, and port function. 1. Press [F8] to select the Setup menu. File Edit Transmit Reports Logs Options Setup Position StopAlarm Setup 1. Distress Alert Setup 2. System Setup 3.
  • Page 41 7. Press [Enter] to open the selection window. Setup System Setup System Date & Time 01:53 97-08-04 (YY-MM-DD) Auto Preferred NCS AOR (WEST) MES Operation Mode INMARSAT-C Nav Port AOR (EAST) Active Port DTE1 Message Output Port DTE1 EGC Output Port 9.
  • Page 42 15. Press [Enter] to open the selection window. Setup System Setup System Date & Time 01:53 97-08-04 (YY-MM-DD) Preferred NCS MES Operation Mode INMARSAT-C Nav Port DTE1OFF Active Port DTE1 Message Output Port DTE1 EGC Output Port 9. Configuration Figure 2-9 System setup menu, nav port 16.
  • Page 43 23. Press [Enter] to open the selection window. Setup System Setup System Date & Time 01:53 97-08-04 (YY-MM-DD) Preferred NCS MES Operation Mode INMARSAT-C Active Port DTE1 Nav Port Message Output Port DTE1 DTE1 EGC Output Port DTE2 9. Configuration PC/DATA AUTO Figure 2-11 System setup menu, message output port...

  • Page 44: Terminal Setup

    30. Press [Esc] to open the update window. Setup System Setup System Date & Time 01:53 97-08-04 (YY-MM-DD) Preferred NCS MES Operation Mode INMARSAT-C Nav Port Update Active Port DTE1 Message Output Port DTE1 EGC Output Port DTE1 9. Configuration Figure 2-13 System setup menu, update 31.

  • Page 45: Login And Logout

    12. Select “Normal Mode” or “Reverse Mode”. Normal Mode displays black characters on white backgrund. Reverse Mode displays white characters on black backgrund. 13. Press [Enter] to close the selection window. 14 Press [Esc] to return to the standby display. Login and Logout Each time the DTE and communication unit are turned on register your vessel with the Inmarsat C system, to enable communications...

  • Page 46: Login

    Login 1. Confirm that “SYNC (NCS)” appears at the bottom of the screen. 2. Press [F7] to display the Options menu. File Edit Transmit Reports Logs Options Setup Position StopAlarm Options 1. Login 2. Logout 3. Abort 4. Select NCS 5.

  • Page 47: Logout

    5. LOGIN begins and the screen should now look something like Figure 2-17. The indication LOGIN appears in blinking reverse video. File Edit Transmit Reports Logs Options Setup Position StopAlarm Options Login Starting Login Process. Press any key to escape. LOGIN replaces IDLE.
  • Page 48 File Edit Transmit Reports Logs Options Setup Position StopAlarm Options Logout Start Current State: IDLE SYNC ( NCS ) 97-08-04 02:04 (UTC) Successful Login. NCS: IOR LOGIN LAT: DCE Ver ** LON: Figure 2-18 Options menu, logout screen 3. Press [Enter] to start logout. Logout begins and the screen now looks something like Figure 2-19.

  • Page 49: Egc Settings

    EGC Settings What is the EGC (Enhanced Group Call) service? The EGC service enables EGC information providers to send SafetyNET or FleetNET messages via a LES to select groups of ships, or to all ships within a defined geographical area. To send an EGC message, the information provider prepares the mes- sage, and then accesses the Country of international telex network to send the message to the LES.

  • Page 50: Egc Setup

    EGC setup The FELCOM 12 receives EGC messages directed to its present po- sition and Navarea without further programming. The EGC Setup screen lets you select additional areas for which you wish to receive messages and also the Navtex station and type of message for Coastal Warning (NAVTEX Re-broadcast).
  • Page 51 5. Press [Enter] to close the position window. 6. Press [ ] to send the cursor to the Navarea line. 7. Press [Enter] to open the Navarea window. Setup EGC Setup Receive EGC Area Additional Position Navarea Fixed Area Waypoint (from NAV Equipment) NAVTEX Station Code Type of Message (Can’t reject other report)
  • Page 52 13. Press [Enter] to open the Waypoint window. Setup EGC Setup Receive EGC Area Additional Position Navarea Fixed Area Waypoint (from NAV Equipment) OFF ON NAVTEX Station Code Type of Message (Can’t reject other report) Ice reports OMEGA messages Meteo. forecasts SATNAV messages Pilot service Other navaid msg...

  • Page 53: Programming Egc Channels

    21. Press [Esc] to open the update window. Setup EGC Setup Receive EGC Area Additional Position Navarea Fixed Area Waypoint (from NAV Equipment) NAVTEX Station Code Type of Message (Can’t reject other report) Ice reports OMEGA messages Meteo. forecasts SATNAV messages Update Pilot service Other navaid msg...

  • Page 54: Programming Ncs Channels

    6. Press [Enter] to open the text window. Setup Configuration EGC Channel List ENT: set ESC: quit 11080* 12580* 10840* 11088* Figure 2-28 EGC channel list, cursor displayed 7. Enter EGC channel frequency code. 8. Press [Enter] to close the text window. 9.
  • Page 55 Setup Configuration NCS Channel List ENT: set ESC: quit AOR (WEST) AOR (EAST) FREQ FREQ FREQ FREQ 11080* 12580* 12580* 10840* Figure 2-30 NCS channel list 4. Current NCS common channels are marked with an asterisk. These channels cannot be changed. 5.

  • Page 56: Les List Operations

    LES List Operations The LES List provides for storage of 44 LES names per ocean re- gion. When the LES table is opened on the Send menu, LES names entered in this LES List appear along with their IDs. See page 2-21. Programming the LES list 1.
  • Page 57 4. With the arrow keys place the cursor where no data is entered. 5. Press [Enter]. Setup Configuration LES List Ctrl+P: print ENT: list entry ESC: quit AOR (WEST) AOR (EAST) Name Name Name Name SOUTHBURY SOUTHBURY SANTA PAULA GOONHILLY GOONHILLY Name YAMAGUCHI...

  • Page 58: Deleting And Changing The Les List

    Deleting and changing the LES list 1. Press [F8], [9] and [2] to display the LES list. 2. Select the LES you want to edit. 3. Press [Enter]. The cursor should be on the Name line. Name : Yamaguchi : 303 Remarks : KDD Japan..
  • Page 59 Table 2-1 LES IDs Land earth station operator Country AOR- E AOR- W Beijing Marine China Bezeq Israel Thailand CP Radio Marconi Portugal Embratel Brazil France Telecom France France Telecom (Ex DeteSat) France KDDI Japan Korea Telecom South Korea Morviasputnik (Nudel Les) Russia Greece Polish Telecom...

  • Page 60: Station List Operations

    Setup Position StopAlarm Setup Configuration Station List Station Name Type Code, ID / Address E-Mail abc@ furuno.co.jp E-Mail xyz@ furuno.co.jp Seagull TELEX 463609999 Ctrl+P: print Figure 2-39 Sample station list 4. Operate [ ] to place the cursor on a blank line.
  • Page 61 10. Press [Enter] to open the destination type window. TELEX E-Mail CSDN PSDN X400 DNID SPEC TELEX (Prefixed) (Prefixed) PSDN (Prefixed) X400 (Prefixed) DNID (Prefixed) SPEC (Prefixed) Figure 3-41 Selection window for “destination type” TELEX: Telex communication Facsimile service FAX: - to an office facsimile machine E-Mail: E-mail (electronic mail) Service...
  • Page 62 x i f s ' r t s i l a i t s i c i t 16. Press [Enter] to close the prefix code window. 17. Press [ ] to advance the cursor to the Country Code line for TELEX, FAX, PSDN.

  • Page 63: Editing The Station List

    Options Setup Position StopAlarm Setup Configuration Station List Station Name Type Code, ID / Address E-Mail abc@ furuno.co.jp E-Mail xyz@ furuno.co.jp Seagull TELEX 463609999 Ctrl+P: print Figure 2-42 Station list 2. Press [ ] and [Enter] to select the station you want to edit.

  • Page 64: Entering Own Ship's Position

    Entering Own Ship’s Position When there is no navigation device connected, select OFF on the Nav Port line in the System Setup menu, as explained on page 2-4, and enter ship’s position manually as follows: 1. Press [F9] to display the Position menu. File Edit Transmit...

  • Page 65: Setting Directories

    Setting Directories You can designate the directory where to save incoming and outgo- ing messages as follows: 1. Press [F8] to display the Setup menu. 2. Press [8] to display the Directories menu. File Edit Transmit Reports Logs Options Setup Position StopAlarm Setup Directories Message Directory...

  • Page 66: E-Mail Service List

    E-mail Service List The E-mail service list provides for E-mail set up. Currently there are four service stations which handle E-mail. The procedure below de- scribes how to add service stations to the list. 1. Press [F8] to display the Setup menu. 2.
  • Page 67 5. Press [Enter] to open the window for service station name entry. Setup Configuration E-Mail Service List 1. Station List Station Name AOR.W AOR.E POR 2. LES List 3. EGC Channel List Comsat 4. NCS Channel List PTT Telecom 5. E-Mail Service List Service Station Name British Telecom Service ID...

  • Page 68: E-Mail Setup

    29. Press [ ] to place the cursor on the “Separator” line. 30. Press [Enter] to open the window for separator entry. 31. Type proper Separator (for example, blank space, STX:, etc.). 32. Press [Enter] to close the window. 33. Press [ ] to place the cursor on the “Attach File (MIME)” line. 34.
  • Page 69 5. Press [Enter] to the update window. Setup E-Mail Setup Station Name AOR.W AOR.E POR Station Name AOR.W AOR.E POR Comsat Comsat PTT Telecom 6. Auto Mode Setup British Telecom 7. E-Mail Setup Stratos 8. Directories Update Telstra 9. Configuration Figure 2-56 update window 6.
  • Page 70 This page is intentionally left blank.

  • Page 71: File Operations

    FILE OPERATIONS This chapter describes how to prepare, edit, save and print files (mes- sages). Preparing a Message There are two types of files: routine and confidential. Messages can be assigned a file name and saved to a floppy disk for later use.

  • Page 72: Preparing A Confidential Message

    If the text editor screen does not appear and “close” screen Note: appears, see “Opening a file where a working area is oc- cupied” on page 3-11. 3. The cursor is on the first line. Type your message. Preparing a confidential message If communicating with another FELCOM 12, you can prepare a con- fidential message by entering “S???-addressee code(-password):”...

  • Page 73: Editor Menu Setup

    When the recipient receives a message with both addressee code and password, he must enter the password to view contents of the mes- sage. Editor menu setup The Editor menu sets the parameters of the text editor. 1. Press [F8] to display the Setup menu. 2.

  • Page 74: Cutting And Pasting Text

    <[1] UNTITLED1> 0001 WE ARE CONFIDENT THAT YOU WILL ENJOY MANY YEARS OF OPERATION WITH 0002 THIS INMARSAT STANDARD C MOBILE EARTH STATION FELCOM 12 0003 CONGRATULATIONS ON YOUR CHOICE IF FURUNO FELCOM 12t ---- * ---------+---------+---------+---------+---------+---------+---------< ASCII 173 Char.

  • Page 75: Copying And Pasting Text

    [3] (Paste). Copying and pasting text 1. Select the text you want to copy. <[1] UNTITLED1> 0001 THE FURUNO FELCOM 12 INMARSAT STANDARD C MOBILE EARTH STATION, A 0002 SATELLITE COMMUNICATIONS UNIT PACKAGE FOR VIRTUALLY EVERY VESSEL.t ---- * ---------+---------+---------+---------+---------+---------+---------<...

  • Page 76: Insert (With Citation)

    5. Press [F2] followed by [3]. The text is placed at the cursor loca- tion. <[1] UNTITLED1> 0001 THE FURUNO FELCOM 12 INMARSAT STANDARD C MOBILE EARTH STATION, A 0002 SATELLITE COMMUNICATIONS UNIT PACKAGE FOR VIRTUALLY EVERY VESSEL. 0003 UNITt ---- * ---------+---------+---------+---------+---------+---------+---------<...

  • Page 77: Saving A Message

    Saving a Message Formatting a floppy disk To save a message to a floppy disk the disk must be formatted. For- matting prepares the disk no information can be written to its surface. 1. Insert a blank floppy disk into the disk drive. 2.

  • Page 78: Saving A Message

    Reports Logs Options Setup Position StopAlarm File <[1] UNTITLED1> Save 0001|THE FURUNO FELCOM 12 INMARSAT STANDARD C MOBILE EARTH STATION, A 1. New ALT-N 0002|SATELLITE COMMUNICATIONS UNIT PACKAGE FOR VIRTUALLY EVERY VESSEL. 2. Open ALT-O Filename Size Date & Time 3.
  • Page 79 NT THAT YOU WILL ENJOY MANY YEARS OF OPERATION WITH 2. Open ALT-O STANDARD C MOBILE EARTH STATION FELCOM 12 3. Close ALT-Q S ON YOUR CHOICE IF FURUNO FELCOM 12t. 4. Save ALT-S 5. Delete ALT-D 6. Rename Save this message? 7.

  • Page 80: Opening A File

    Open 1. New ALT-N SEIZOU 2. Open ALT-O 3. Close ALT-Q THE FURUNO FELCOM 12 INMARSAT STANDARD C MOBILE EARTH STATION, A 4. Save ALT-S SATELLITE COMMUNICATIONS UNIT PACKAGE FOR VIRTUALLY EVERY VESSEL. UNITt 5. Delete ALT-D 6. Rename 7. Print ALT-P 8.

  • Page 81: Switching Between Files

    2. Open ALT-O STANDARD C MOBILE EARTH STATION FELCOM 12 Filename Size Date & Time 3. Close ALT-Q S ON YOUR CHOICE IF FURUNO FELCOM 12t. ABC281 . 97-07-28 20:54 4. Save ALT-S COIEKI . 97-07-15 02:13 5. Delete ALT-D COMTEST.

  • Page 82: Saving A File Under A New Name

    NT THAT YOU WILL ENJOY MANY YEARS OF OPERATION WITH 2. Open ALT-O STANDARD C MOBILE EARTH STATION FELCOM 12 3. Close ALT-Q S ON YOUR CHOICE IF FURUNO FELCOM 12t. 4. Save ALT-S 5. Delete ALT-D 6. Rename Save this message? 7.

  • Page 83: Printing A File

    [B:\SEIZOUSE 2. Open ALT-O STANDARD C MOBILE EARTH STATION FELCOM 12 Filename Size Date & Time 3. Close ALT-Q S ON YOUR CHOICE IF FURUNO FELCOM 12t. ABC281 . 97-07-28 20:54 4. Save ALT-S COIEKI 97-07-15 02:13 5. Delete ALT-D COMTEST .

  • Page 84: Combining Files

    Combining Files In the procedure below we’ll combine file A and B. 1. Open file A. 2. Open file B. File B appears on the display. 3. Place the cursor at the beginning of the file. While pressing and holding down [Shift] press [ ] to highlight the entire file.

  • Page 85: Mime (Multipurpose Internet Mail Extensions)

    4. Press [Enter]. The prompt “OK to delete file?” appears. File Delete 1. New ALT-N [B:\ABC28 2. Open ALT-O Filename Size Date & Time 3. Close ALT-Q ABC28 97-07-28 20:53 4. Save ALT-S ABC281 . 97-07-28 20:54 5. Delete COIEKI . ALT-D 97-07-15 02:13 COMTEST.

  • Page 86: Rename

    Rename Do the following to change file name. 1. Press [F1]. 2. Press [6]. File Rename 1. New ALT-N [B:\ABC28 2. Open ALT-O Filename Size Date & Time 3. Close ALT-Q Test .txt 97-07-28 20:53 4. Save ALT-S ABC281 . 97-07-28 20:54 COIEKI .

  • Page 87: Inmarsat-C Communications

    INMARSAT-C COMMUNICATIONS This chapter explains how to transmit and receive in the Inmarsat-C system. Before conducting any communications, be sure to login with the NCS in your area. To transmit E-mail, register with the LES provider. E-mail charges are calculated separately. Transmitting To transmit a message, you first create the message, attach the ad- dress of the recipient and send it to the LES.

  • Page 88: Transmitting Prepared Message

    Table 4-1 Message, subscriber destination and code s i l l i a l i a a l i l i a l i a a l i a l i l i a l i a Transmitting prepared message This section explains routine telex transmission.
  • Page 89 3. Press [Enter] or [1] to display the Transmit Message menu. The cursor is on the Priority line and “Normal” is selected. File Edit Transmit Reports Logs Options Setup Position StopAlarm Transmit <[1] UNTITLED1> Transmit Message 0001|t 1. Transmit Message 2.
  • Page 90 8. Follow instructions below for TELEX (Prefixed), or go to page4- 5 for FAX or E-Mail. Destination type: TELEX (Prefixed) (1) Press [ ] to place the cursor on the Prefix Code line. (2) Press [Enter] to open the window for prefix code entry. (3) Key in prefix code in the digits.
  • Page 91 (9) Press [ ] to send the cursor to the Station ID line. (10) Press [Enter] to open the window for station ID entry. Transmit <[1] UNTITLED1> 0001|t 1. Transmit Message Transmit Message 2. Cancel Priority Normal 3. Request Delivery Status Message File Message now being edited Size...
  • Page 92 (2) Press [Enter] to open the window for address entry. Transmit <[1] UNTITLED1> Transmit Message 0001|t 1. Transmit Message 2. Cancel Priority Normal 3. Request Delivery Status Message File Message now being edited Size Station Name Destination Type E-Mail Prefix Code Country/Ocean Code Station ID INET...
  • Page 93 Transmit <[1] UNTITLED1> Transmit Message 0001|t 1. Transmit Message 2. Cancel Priority Normal 3. Request Delivery Status Message File Message now being edited Size Station Name Destination Type E-Mail Prefix Code Select File Country/Ocean Code Station ID Modem Type Address ---- * ---------+---------+---------+---------+---------+---------+---------<...
  • Page 94 13. Press [ ] to send the cursor to the Option line. 14. Press [Enter] to open the option window. Transmit <[1] UNTITLED1> Transmit Message 0001|t 1. Transmit Message 2. Cancel Priority Normal 3. Request Delivery Status Message File Message now being edited Size Station Name Destination Type...

  • Page 95: Transmitting Message Stored On Floppy Disk (Multiple Address)

    31. Press [Enter] to open the start window. 32. Press [Enter] to transmit the message to the message buffer. (To escape, select No and press [Enter].) The message “Message is entered in sending Buffer.” appears and the message prepared is printed.
  • Page 96 File Edit Transmit Reports Logs Options Setup Position StopAlarm Transmit 1. Transmit Message 2. Cancel 3. Request Delivery Status Figure 4-12 Transmit menu 4. Press [1] to select Transmit Message. The cursor is on the Priority line and “Normal” is selected. File Edit Transmit...
  • Page 97 Station Name RxIF AGC Level OK (135) Station Name Type Code, ID / Address Destination Type TELEX REF Offset Freq OK ( 0Hz) FURUNO TELEX Waypoint Country/Ocean Code Synthe 1st local FRNINMBTSTS TELEX 343199999 Station ID 65-2111 3rd local Course...
  • Page 98 97-08-04 BBER Time 01:32 (UTC) Priority Normal Message File SEISETU.TXT Send level Size Position Station Name FURUNO RxIF AGC Level Destination Type TELEX REF Offset Freq Waypoint Prefix Code Synthe 1st local Country/Ocean Code 3rd local Course Station ID Synthesizer...

  • Page 99: Canceling Transmission

    If a file name which was entered manually does not exist Note: when you attempt to transumit the file at step 13. “Input Error: Message File” appears. Press any key to erase the error message then enter correct name. Canceling transmission As noted earlier a transmit message is held in the buffer, usually until it is transmitted satisfactorily.

  • Page 100: Confirming Delivery Status (Message Status List)

    <[1] UNTITLED1> 0001|t 1. Transmit Message 2. Cancel !!!!! Location error !!!!! Cancel 3. Request Delivery Status Message File Station Priority Send Status Delivery FURUNO Perth Normal Waiting FELCOM FUSA SANTAPAULA Normal Sending Cancel ---- * ---------+---------+---------+---------+---------+---------+---------< ASCII 25 Char.
  • Page 101 2. Press [3] to display the Request Delivery Status menu. Request Delivery Status Message File Station Priority Send Status Delivery FURUNO Yamaguchi Normal Waiting FURUNO Yamaguchi Normal Sending ASDFASDF Normal 97-03-20 9:40 OCC(002) Normal 97-03-18 20:16 ABCDEFGHIJ Normal 97-03-18 16:09 Complete edit msg.002...

  • Page 102: Manually Requesting Delivery Status

    24 hours. 1. Press [F3]. 2. Press [3] to display the Request Delivery Status display. Request Delivery Status Message File Station Priority Send Status Delivery FURUNO Perth Normal 97-11-06 16:10 edit msg.002 FURUNO Perth Normal Figure 4-24 Request delivery status display 3.

  • Page 103: The 2-Digit Code Services

    The 2-digit code services A range of special safety and general maritime services, known as the 2-digit code services, may be received. The list on the next page shows the 2-digit code services available. To access a 2-digit code service; 1.
  • Page 104 For maritime safety service; Medical advice Used for requesting medical advice. Medical assistance Used for requesting medical assistance. Maritime assistance Used for requesting maritime search and rescue assistance. Meteorological reports Necessary for ease of addressing weather reports from ships to meteorological centers. Navigational Hazards and Used for making urgent navigational meteorological warnings...

  • Page 105: Inserting The Destinations Of A Fax Terminal

    Inserting the destinations of a fax terminal You can send a text message to a Group 3 type fax terminal which is connected to the international PSTN (telephone) land line, provided the LES selected supports fax delivery. 1. Prepare message. (To send stored file, close any open files.) 2.

  • Page 106: Receiving

    17. Press [Enter] to close the window. 18. Press [ ] to send the cursor to the Modem Type line. 19. Press [Enter] to display the list of modem types. 20. Press [Enter] to select “T30”. (Other modem types are not sup- ported.) 21.

  • Page 107: Setting The Receive Alarm

    3) display log The Display Log shows message number, priority, date and time of transmission, LES ID and file size (in bytes) of the latest 50 received and transmitted messages. 4) printing Printing of a message begins (except messages with passwords) as soon as it is received.

  • Page 108: Displaying Receive Messages

    6. Press [Enter] to close the selection window. 7. Press [Esc] twice. Displaying receive messages When you can't read an attached file in Log menu refer to page 3-15. 1. Press [F6]. 2. Press [2] to display list of receive messages. Received Message Log Message No.

  • Page 109: Printing Receive Messages

    4. Press [Enter] for routine messages and messages with addressee code (no password). Your selection appears on the display. Display Receive Message <R0971123.002-> FROM FURUNO TO FRONTIER THE QUICK BROWN FOX JUMPS OVER LAZY DOG. ABCDEFGHIJKLMNOPQRSTUVWXYZ. 1234567890 Ctrl+P: print Figure 4-30 Sample receive message 5.

  • Page 110: Saving Receive Messages To A Floppy Disk

    Saving receive messages to a floppy disk 1. Press [F6]. 2. Press [2] to display the Receive Message Log. Receive Message Log Message No. Priority Size Addressee Rec date & Time Status R0971106.001 Perth Normal 32767 97-11-06 16:10 Saved R0971105.002 ABCDEFGHIJ Normal CAPTAIN...

  • Page 111: Deleting Receive Messages

    The drive and directory where to save receive messages and created files can be specified with “MSG Directory”. The default setting is as follows; For IB-581 For PC “MAIL” directory in directory which stores program files For IB-581 do not specify the ROM disk (drive A) as the “MSG Note: directory.”...

  • Page 112: Distress/Urgent Receiving Call Unit Ic-303

    1. Press [F6]. 2. Press [4] to display the Display Log. Display Log Message No. Type Date Time Station Size Cond T0971110.001 TELEX 97-11-10 19:10 FURUNO 12345 Success R0971110.001 TELEX 97-11-10 19:25 PSTN Fail PSDN E-mail (etc.) 50 (max) Ctrl+P: print Figure 4-37 Sample display log 3.

  • Page 113: Automatic Printing Of Display Log

    display log description S/R: Send or Receive message Message No.: Message no. or file name Type: Currently, TELEX, PSTN, PSDN or SPEC (2-digit code service). Pri: Normal or distress Date: Date message was received (or transmitted). Time: Time message was received (or transmitted). LES: ID of LES which handled the message Station:...

  • Page 114: Display Send Message Log Or Receive Message Log

    Display send message log or receive message log You can display send message log or receive message log as follow. 1. Press [F6]. 2. Press [1] (Send message log) or [2] (Receive message log). 3. Press [Esc] to escape. EGC Messages EGC messages are automatically received, printed and saved to the DTE.

  • Page 115: Displaying Egc Closed Network Id (Enid)

    Options Setup Position StopAlarm 1. Display EGC Message EGC Network ID List 2. EGC Network ID ENT: Activate SPACE: Inhibit Ctrl+P: Print ESC: Quit Mark ‘*’ means activation 00001 FURUNO 00002 FURUNO 04001 FURUNO 04002 FURUNO 04003 FURUNO 04005 FURUNO...

  • Page 116: Receiving Egc Distress Or Urgent Message

    3. Select an ENID you want inhibit (or activate). 4. Press the Space bar to inhibit (or [Enter] key to reactivate). 5. Press [Esc] to return to the standby display. Receiving EGC distress or urgent message When the FELCOM 12 receives a EGC distress or an urgent mes- sage, an alarm buzzer sounds on the terminal unit and the Distress/ Urgent Receiving Unit IC-303 or the Distress Message Controller DMC-5 when connected.
  • Page 117 Confirmation "ON" The message "Delivery Status received for (file name)" is displayed when you received message delivery data and the message is printed. Note: After the message "Delivery Status received for" appears, wait more than two minutes before sending another message. If you at- tempt to transmit before two minutes has elapsed the the message and delivery information will be printed again.
  • Page 118 (This page intentionally left blank.) 4-32...

  • Page 119: Data Reporting And Polling

    DATA REPORTING AND POLLING This chapter explains data reporting settings and polling reception. Data reporting provides automatic data transmission at regular intervals from your ship to your home office, when your ship receives a polling command from your home office, it automati- cally transmits data to your home office.
  • Page 120 2. Press [Enter] or [1] to display Data Report screen. 3. Press [1], [2], [3] or [4] to set addressee desired. You can set four addressees. The cursor is on the Status line and “OFF” is selected. Position Reports Data Report 1.
  • Page 121 16. Press [Enter] to open the selection window. 17. Select “Regular Interval” or “Daily”. 18. Press [Enter] to close the selection window. 19. Press [ ]. ` When “Regular Interval” is selected on step 17, (1) Press [Enter] to open the window for interval time entry. (2) Key in the interval time at Interval Time.

  • Page 122: Setting A Message Report

    Setting a message report 1. Press [F5] to display the Position Reports menu. Position Reports 1. Data Report 2. Message Report 3. Data Network ID Figure 5-4 Position reports menu 2. Press [2] to display the Message Report. 3. Press [1], [2], [3] or [4] to set addressee desired. You can set four addressees.
  • Page 123 14. Press [Enter] to close the station list. 15. Press [ ] to place the cursor on the LES ID line. 16. Press [Enter] to display the LES list. 17. Select LES. 18. Press [Enter] to close the LES list. Note: If the item "Activation"...

  • Page 124: Polling

    27. Press [Esc] to register the above settings. Message Report PIN Code 12345678 ********* Message Report Programming Status Station Name FRNINMBTSTSES Destination Type TELEX Country/Ocean Code 343199710 Station ID Modem Type Subject LES ID 303 (YAMAGUCHI) Daily Activation Interval Time 01:00 Report Times 24 (- - - : No Limit)

  • Page 125: Other Polling Command

    Polling command on MES message channel To make the polling command, enter D???, hyphen, PIN code (max. 8 digits), hyphen, file name (stored in the floppy disk of the FELCOM 12), colon and text of message. To send file data, type a hyphen and file name. If no hyphen and file name is entered, MES automatically transmits nav data (own ship position, course, speed, etc).

  • Page 126: Polling Reception

    MES transmits position, speed, bearing, water temperature, current and depth to telex number 720-5644325. P???/12345678/TELEX/203/720/5644325/: Mobile earth station transmit position, speed and bearing to e-mail address abc@furuno.co.jp. P???/12345678/EMAIL/203/abc@furuno.co.jp: Polling reception No operator intervention is required during polling reception. The printer PP-510 prints the status of polling reception and data transmission in response to polling request as shown below.

  • Page 127: Dnid (Data Network Identification)

    Note: You can turn off printing of the data report and polling com- mands as follows: 1. Press [F8], [6] to display the Auto Print Mode Setup screen. Setup Auto Mode Setup Auto Log Print Receive Alarm Auto Telex Msg Save Auto EGC Msg Save Data Report &...

  • Page 128: Enabling/Disabling Dnid

    DNID with “*” mark are available for use(Refer to Figure Note: 5-11). POLLING Message - - - Program Unreserved Data Reporting - - - DNID : 0004 LES ID : 101 (Southbury) Sub Address : 000 Member Number : 001 Response: No Response Receive Data &...

  • Page 129: Distress Alert

    DISTRESS ALERT Preparing a Distress Alert 1. Press [F8] to display the Setup menu. Note that this key has pre- cedence over any operation. 2. Press [1] to display the Distress Message Setup screen. Distress Alert Setup LES ID Update Time 06:23 97-08-20 (YY-MM-DD) Position 35:00N...
  • Page 130 11. Press [ ] to select Nature. Press [Enter] to display the list. Select appropriate nature of distress. Undesignated Listing Fire/Explosion Sinking Flooding Disabled & Adrift Collision Abandoning ship Grounding Further assistance required Piracy or Armed Attack If nature of distress is not specified, “Undesignated” is auto- matically selected.

  • Page 131: Transmitting A Distress Alert

    IC-302 SEL NO. COMPASS SAFE DISTANCE FURUNO ELECTRIC CO., LTD Figure 6-4 Distress Alert Unit IC-302 Do not press the button to silence an alarm for incoming distress or urgent message. This will transmit a distress alert for own ship.

  • Page 132: Testing Distress Button

    Testing Distress Button The DISTRESS button on the IC-302 may be tested without trans- mitting the distress signal as follows: 1. Press [F7] to display the Options menu. 2. Press [6] to display the Test menu. Test 1. PV Test 2.

  • Page 133: Distress Communications

    Distress Communications distress alert provides the minimum distress reporting require- ments: own vessel’s ID, speed, course, L/L position and nature of distress. After receiving the distress alert acknowledgment and you are not pressed for time you may send detailed information as fol- lows: 1.
  • Page 134 11. Press [Enter] to close the LES list. 12. Press [ ] to place the cursor on TRANSMIT. 13. Press [Enter]. The display should look similar to Figure 6-9. Transmit <[1] UNTITLED1> Transmit Message 0001|t 1. Transmit Message 2. Cancel Priority Distress 3.

  • Page 135: Other Functions

    OTHER FUNCTIONS This chapter describes how to abort operation, scan NCS and select EGC and NCS channels. Aborting an Operation You can abort transmission, receiving or scanning during operation. 1. Press [F7] to display the Options menu. Options 1. Login 2.

  • Page 136: Scanning Ncs

    Scanning NCS The communication unit automatically tunes itself to the NCS se- lected on the System Setup menu. You can, however, tune to another NCS which has a stronger signal. Scanning is possible only when the communication unit is IDLE and FELCOM 12 is set to operate as an Inmarsat-C transceiver.

  • Page 137: Selecting Egc Receiving Channel

    Selecting EGC Receiving Channel EGC channel can be selected when the DTE is set to operate as an EGC-only receiver. This procedure is shown for reference; currently there is only one EGC channel per NCS. 1. Press [F8] to display the Setup menu. 2.

  • Page 138: Selecting Ncs Channel

    Selecting NCS Channel NCS channel can be selected as shown in the procedure below. Cur- rently, each satellite transmits one global beam. In the future, the sat- ellites will transmit multiple spot beams, namely, the NCS will have multiple channels. 1.

  • Page 139: Maintenance

    MAINTENANCE This chapter provides the information necessary for the maintenance and checking of the FELCOM 12. Safety Information WARNING WARNING Do not open the cover of the equipment. This equipment uses high voltage electricity which can shock, burn, or cause serious injury.

  • Page 140: General Checking And Maintenance

    General Checking and Maintenance Turn off the power before conducting any maintenance procedures other than the cleaning of the terminal unit and communication unit. Cleaning the terminal unit and communication unit These units can be cleaned with a soft, dry cloth. DO NOT use chemi- cal cleaners.

  • Page 141: Self Tests

    Self Tests The communication unit and the terminal unit are equipped with self tests which check them for proper operation. Self test at power application (communication unit) The communication unit performs the following tests when it is turned a) ROM sum test b) RAM read and write test c) DP RAM read and write test d) EEPROM sum test...

  • Page 142: Performance Verification (Pv) Test

    5. When the test is completed the screen shows the results of the test. Options Test 1. Login 2. Logout Communication Unit 1. PV Test 3. Abort 2. PV Test Result CPU1 165-0086-100 CPU2 165-0087-103 4. Select NCS 3. Self Test 5.

  • Page 143: Pv Test Procedure

    8. The MES automatically transmits the distress alert test within two minutes after completion of step 8. 9. When the distress alert test is finished the results of the test are sent to MES. The entire PV test can be conducted automatically (taking about 15 minutes in total).

  • Page 144: Results Of Pv Test

    10. Though a prompt asks you to test distress alert, do not press any key. The alert test is automatically conducted two minutes later. 11. When testing is completed the indication TESTING is replaced by IDLE. 12. The test results appear on the PV Test Result screen. (The next section shows how to interpret the results.) Results of PV test 1.

  • Page 145: System Status Monitor

    Bulletin Board Error Rate (%). Pass ap- BBER: pears for no error. Shore-to-Ship Attempts: Number of tests initiated by LES. Number of tests initiated by MES. Ship-to-Shore Attempts: Distress Alert: “Pass (Test OK)” appears for successful testing. “Pass” appears if signal strength is greater Signal Strength: than standard level.

  • Page 146: Interpreting The System Status Monitor

    Interpreting the system status monitor Date: Current date Current time Time: Position: Vessel’s position (either manual entry or au- tomatic input by navigation aid) Waypoint: Destination Course: Heading Ship’s speed Speed: Current NCS: NCS your vessel is logged in with Channel in use Current Channel: Current TDM:...

  • Page 147: Replacing Internal Battery

    Operating normally. If it does not light check REF Offset Freq: RX Synthesizer or REF OSC in the RF CON Board. OK appears for figure less than 150. Synthe 1st Local: Check of RF CON Board. Check of RF CON Board 2nd local oscilla- RX 2nd Local: tor.

  • Page 148: Error Messages

    Error Messages This section shows the error messages which may appear on the screen and the means to remedy the associated problem. If normal operation cannot be restored, contact your dearer to request repair. n i l n i l t s i , l l n i l...
  • Page 149 v i l v i l r i f v i l e l i v i l v i l e l i c i t . y l e l i c i t . y l n i l n i l l i a e l i...
  • Page 150 e l i l l u y l l c i t . y l . y l . r i l l a i r r l i a . r i f l l ) t i e l i .
  • Page 151 . y l d i l d i l 8-13...
  • Page 152 This page is intentionally left blank.

  • Page 153: Specifications

    SPECIFICATIONS Transmitting Frequency 1626.5 to 1646.5 MHz Receiving Frequency 1530.0 to 1545.0 MHz Antenna Omnidirectional Better than -23 dB/K (elevation angle 5˚) EIRP 12 to 16 dBW (elevation angle 5˚) Modulation BPSK Modulation Rate 1200 sps Coding Convolutional coding with coding rate 1/2 and constraint length 7 Decoding Viterbi decoder...
  • Page 154 Power Consumption IC-112 & IC-212: Receiving 25W, Transmitting 120W IB-581: 18W PP-510: 36 W MAX Antenna unit: N9.5 Color Antenna unit base: 2.5PB3.5/10 Communication unit: N3.0 Terminal unit: Cover: 2.5GY5/1.5 Panel: N3.0 Distress alert unit: 2.5GY5/1.5 Received call unit: 2.5GY5/1.5 Waterproofing: Antenna unit: IEC529 IPX6 Communication unit: IEC529 IPX2...

  • Page 155: Appendix

    APPENDIX International Telex/Telephone Country Code List Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Afghanistan Alaska Albania Algeria American Samoa American Virgin Is. Telex calls to former WUI subscribers, insert the figure “9” after the destination code “208”. Andorra Angola Anguilla...
  • Page 156 Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Cambodia Kampuchea Rep. Cameroon Canada Disregard the figure “0” at head of subscriber number. Canary Is. Destination code is the same as for Spain. Cape Verde Cayman Is. Central Africa Rep.
  • Page 157 Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Falkland Is. (Malvinas) Faroe Is. Fiji Finland France French Guiana French Polynesia Gabon Gambia Georgia Germany (Fed, Rep. of) formerly East Germany formerly West Germany Ghana Gibraltar Greece Greenland Grenada...
  • Page 158 Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Jamaica Japan KDD (for 5 digits) Jordan Kazakhstan Kenya Kiribati Subscriber numbers are 770XX Korea (Demo, People’s (899) Rep. of) Korea (Rep. of) Kuwait Kyrgyzstan Latvia (formerly USSR) Lebanon Lesotho Liberia...
  • Page 159 Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Montserrat Morocco Mozambique Myanmar (formerly Burma) Namibia Nauru Nepal Netherlands Netherlands Antilles New Caledonia New Zealand Nicaragua Niger 2XXXX other numbers are for Semi-automatic calls. Nigeria Niue Is. Northern Mariana Is.
  • Page 160 Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Reunion Subscriber numbers are 916XXX Romania Disregard the figure “0” at head of subscriber number. Russian Federation Rwanda Saipan San Marino Sao Tome & Principe Manual calls Saudi Arabia Senegal Seychelles...
  • Page 161 Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Turks & Caicos Is. Tuvalu U. A. E. Abu Dhabi 2XXXX, 3XXXX, 5XXXX Ajman 695XX Dubai 4XXXX Fujairah 8XXXX Ras Al Khaimah 9XXXX Sharjah 68XXX Umm Al Qaiwain 697XX Uganda Ukraine...
  • Page 162 Telephone Telex Country Area and Country Remarks for Telex Code Country Code Code Zaire Telex calls to places other than Kinshasa Subscriber beginning with 2XXXX can be made as Semi-automatic calls. Zambia Zanzibar Zimbabwe Telephone Telex Ocean Ocean Area Remarks Ocean Region Region Access Access Code...

  • Page 163: International Telex Abbreviations

    International Telex Abbreviations Abbreviation Meaning Advise Acknowledge Again BI (GS) Good bye I cut off. Confirm Collation How do you receive? Out of order Down Error From Go ahead. Minutes Wait (Waiting) MUTI Mutilated Correspondence to this subscriber is not admitted. No circuits Snbscriber’s number has been changed.

  • Page 164: Glossary Of Acronyms

    Glossary of Acronyms Acronym Meaning AOR-E Atlantic Ocean Region-East AOR-W Atlantic Ocean Region-West Bulletin Board BBER Bulletin Board Error Rate BPSK Binary Phase Shift Keying Back Space C/N0 Carrier to Noise Power Spectral Density CNID Close Network ID Central Processing Unit CSDN Circuit Switched Data Network Data Circuit Terminating Equipment...
  • Page 165 International Telegraphy Alphabet FIGURES LETTERS FIGURES LETTERS ’ BELL CARRIAGE RETURN LINE FEED LETTERS FIGURES SPACE BLANK AP-11...

  • Page 166: Error Messages And Alerts

    Error Messages and Alerts A file by that name already exists on FD. This message appears when you attempt to copy a file from the internal memory to a floppy disk and a file by that name al- ready exists on the disk. Cannot use this LES.
  • Page 167 Current State : Idle (pending!) This message appears when a LES affir- matively acknowledges your request for PV testing. Current State : Testing You will see this display during PV test- ing. DCE Error : No response from DCE!! This message appears when you try to dis- play the PV test results and there was no response from the communication unit because it is off or its interconnection cable...
  • Page 168 Message file is too big (partial transmission possible). The size of the file you want to send is larger than 31,500 bytes. (The file can be sent, but only the first 32,000 bytes of in- formation will be received.) Message is entered in sending buffer. Before a message is transmitted it is sent to the message queue.

  • Page 169: Les Ids List

    LES IDs List AP-15...

  • Page 170: Digital Interface (Iec 61162-2

    Digital Interface (IEC 61162-2) Input sentences GGA, GLL, RMA, RMC, ZDA, VTG, RMB, WPL, MTW, DBT, VDR, BWC, BWR Output sentences GGA, ZDA, GLL, VTG, RMC, GSV Transmission interval GLL, GGA, VTG, RMC: 2 s ZDA: 1 s GSV: 10 s Data transmission Data is transmitted in serial asynchronous form in accordance with the standard referenced in 2.1 of IEC 61162-2.
  • Page 171 Schematic diagrams NAV IN port (listener) IC-212 16P0148 SRCN2A16-10S 16P1048 NMEA RX NMEA-A 3 PC-400 RX NMEA-B 4 CR16 1SS355 25A1362 Load requirements Isolation: Optocoupler Input Impedance: 486ohm Max. Voltage: 15V NAV OUT port IC-212 16P0148 SRCN2A16-10S CR1 CR17 NMEA TX NMEA-A 1 TX NMEA-B AM26LS31CNS...
  • Page 172 Data sentences Input sentences BWC - Bearing and distance to waypoint AP-18...
  • Page 173 BWR - Bearing and distance to waypoint -rhumb line DBT - Depth below transducer AP-19...
  • Page 174 GGA - Global positioning system (GPS) fix data AP-20...
  • Page 175 GLL - Geographic position - latitude and longitude MTW - Water temperature AP-21...
  • Page 176 RMA - Recommended minimum navigation information - Loran C data AP-22...
  • Page 177 RMB - Recommended minimum navigation information AP-23...
  • Page 178 RMC - Recommended minimum navigation information - GPS/TRANSIT data VDR - Set and drift AP-24...
  • Page 179 VTG - Course over ground and ground speed WPL - Waypoint location AP-25...
  • Page 180 ZDA - Date and time Output sentences GGA, GLL, RMC, VTG, ZDA - See input sentences. GSV - GNSS satellites in view AP-26...

  • Page 181: Index

    Index Address book ........2-22 Land Earth Stations(LES) ......7 Addressee code ........3-2 LES List ..........2-18 Log ............4-26 Logging status ........1-11 Cancel transmition ......4-13 Change Window ........3-11 Class 1/2/3 ..........10 Maritime saftey service ....... 4-18 Close .............

Table of Contents

Save PDF
