Furuno Felcom 250 Service Manual page 86

Name
Incoming indicator FB-3000
Telephone
FC755D1
equipment
Fax FAX-2810
Transformer OP16-25
Drum unit DR-20J
Toner cartridge TN-25J
AC-DC power
PR-240
supply
Handset FB-8000
Coaxial cable 12D-SFA-CV
CP16-04121
Installation
Material
CP16-04131
Connector CP03-28901
MOD-Z072-020+
MOD-Z072-050+
MOD-Z072-100+
LAN cable FR-FTPC-CY*10m*
FR-FTPC-CY*20m*
FR-FTPC-CY *30m*
FR-FTPC-CY *50m*
FR-FTPC-CY *100m* 000-153-327-10
Modular jack set OP16-13
Modular jack box OP16-8
Joint box TL-CAT-012
Cable assembly 81-521-1204-010
Incoming indicator KK-893-3977
OP16-10
Modular jack box
OP16-11
Antenna unit FB-1500-B
Note) The FELCOM-500 Antenna units with no attachments are FB-1500-B
(000-015-767)
Table 1.1.2 Architecture of options for FELCOM-250/500
Model Code number
-
-
-
004-446-850
000-170-982-10 For FAX-2820
000-170-983-10 For FAX-2820
-
-
000-136-423-11 Antenna cable – 100 m
001-067-300
001-067-310
008-542-460
000-167-175-10
000-167-176-10
000-167-177-10
000-147-472-10
000-147-473-10
000-147-474-10
000-153-326-10
000-043-228
000-043-272
000-167-140-10 LAN cable for extension
000-127-108-11
000-148-478
000-043-278
000-043-279
-
1-2
1.1 System Configuration
Notes
Engineering work material
CP16-04001 attached
Engineering work material
CP16-00511 and 00512 attached
Engineering work material
CP16-03510 attached
Transformer TSU-N05E +cable
for FAX-2820
Engineering work material
CP16-03901 attached
Connector N-SP-12DSFA-CF for
cable 12D-SFA-CV
Connector N-P-18U-CF (2 pcs)
for RG-18
Modular connector for LAN cabled: 2
of MPS588-C
2 m, with modular plugs on both
ends
5 m, with modular plugs on both
ends
10 m, with modular plugs on both
ends
With metal wire braid, 10m, no plug
attached
With metal wire braid, 20 m, no plug
attached
With metal wire braid, 30 m, no plug
attached
With metal wire braid, 50 m, no plug
attached
With metal wire braid, 100 m, no plug
attached
MJ-2S, 3 m cord, lug
MJ-2S, lug
5 m cable with D-sub 9P on both
ends
For analog telephone
Box-type
Flush mount type
No attachment
