2. The Settings and Operation Check
By copying the information displayed in the Web MMI and then pasting it
onto a text file, you can use that file as a list of equipment settings.
2.1 Inspection After Installation
The connection part of the Antenna coaxial cable is being waterproofed.
The Antenna radome attachment bolt is not slackened.
The connection cables are bundled, and the connection is not loosened.
Position data is displayed.
No Error / Warning Message is displayed.
The lights for Status-1 to 4 LED are lighted.
Reference) The lighting status shows the error status.
Ready LED is lighted.
Lighting conditions;
- The Antenna is in Tracking status.
- Position data is being input.
- Registration of CS and PS registration is completed successfully.
Handset is set to Reg. in; Settings -> PBX settings -> Extension.
The Incoming indicator is being detected in the Device menu.
All Handsets are available to make extension calls, make calls, and incoming
calls, and the quality of sound is sufficient.
All Handsets are showing the time
Reference) If the time is not displayed, set the time display via Settings ->
Basic -> Clock -> NTP server IP address to set it to Own IP address.
The Incoming indicator rings when there is an incoming call.
Connection to WAN is available via Standard IP data.
Connection to WAN is available via Streaming IP data.
Note) In some cases, you may be restricted due to the subscription contract
with the provider.
FAX can be sent / received.
Phones can be made / received using the Analog phone equipment.
Make sure to have an extension number list prepared.
Make sure to have a list of phone numbers and a list of service details prepared.
For next servicing, make sure to have the screen copy of Web MMI, contents for
System information, Status monitor, Setting information.
Item
ii
Check List
Checked
