30. Error 9201: (HUB) PoEthernet total output fault.
The status for this error is confirmed on a constant basis at the interval of 50 ms. This
message will be displayed when the volume for PoE (Power over Ethernet) which
supplies the power source for the equipments connected by the LAN cable exceeds
30.8 W. Please check the connected equipments. The tolerable volume for a single
handset is 7 W (Class-2), and that for a single incoming indicator is 4 W (Class-1).
The terminals other than PoE (PD: Power Device) are available. Please confirm the
power incoming terminal (PD: Power Device). It may also imply a failure in the HUB
board.
Reference)
The value displayed via; Web MMI -> Service -> BDE -> PoE feeding is the
value of power actually supplied, but the maximum output will be
calculated by adding up the rated power output for each power class.
For example, when a single handset is connected, the actual output will be
approx. 2 W, but the maximum output of 7 W will be added, and the remaining
power that can be supplied will be; 30.8 – 7.0 = 23.8 W.
31. Error 9202: (HUB) PoEthernet port output fault.
The status for this error is confirmed on a constant basis at the interval of 50 ms. This
error occurs when Class-4 (the class reserved by the specification) is detected.
FELCOM-500/250 does not support power supply for Class-4, and therefore, power
will not be supplied. Terminals other than PoE (PD) will be available.
Please check the connected equipments. It may also imply a failure in the HUB
board.
32. Warning 9203: (HUB) PoEthernet Controller fault.
The status for this error is confirmed in a constant basis. It implies an error in the PoE
Controller. It occurs when there is an abnormality in the PoE controlled IC. If the
status does not get restored after having rebooted the system, it implies that there is a
failure in the HUB board. Terminals other than PoE will be available.
33. Error 9204: (HUB) Invalid MAC address. Please contact FURUNO service.
The status for this error is confirmed in a constant basis. The MAC address for the
Communication unit HUB board is invalid. You will need to rewrite the MAC
address using the MAC address tool available in the factory. It implies a failure in the
HUB board.
34. Warning 9205: (HUB) High speed SIO fault.
The status for this error is constantly confirmed at an interval of 10 seconds. This will
be issued when abnormality is detected for the communication between the MODEM
board and the HUB board. Although there is a possibility that the abnormality is
observed as a temporary status, if the abnormality is confirmed to be constant,
communication will not be available. When the status does not get restored after
having rebooted the system, it implies that there is a failure in the MODEM board,
HUB board, or the IF board.
AP2-9
Appendix 2. Message List
