Chapter 4. Settings for TEL/FAX

4.1 Overview

Handset: The settings for the phone function will need to be made for both the
Communication unit and the Handset.
Analog terminal(TEL/FAX): The settings for the phone function will need to be made
the Communication unit.
The Communication unit requires to have the Handsets and the Analog terminals
registered in the SIP server, and the Handset requires to be set as client terminal for the
SIP server. In other words, if the SIP server can acknowledge the registered Handset as
client terminal, phone calls and extension calls will be available.
4.1.1 Overview

1. Settings on the Web MMI

The items requiring setting are Analog ports, Incoming indicator, and PBX settings
which you can reach via Settings -> Basic settings. "Contact" menu refers to the phone
number of the called party. Registration (each Handset) can be made via the Handset,
too. Make the settings as necessary.
Menu Menu-1
Basic
settings
Settings
PBX
settings
Contact
Table 4.1.1 Items requiring setting on the Web MMI
Menu-2
GPS
Specifying the service type for the
analog device connected to the
Analog ports
TEL1 – 4 port, and the setting for
the extension number
ON/OFF settings for the ringing for
Incoming indicator TEL, FAX, and UDI/RDI, and their
pattern settings
Serial port
Satellite
OTA
The settings for the routes of the
Incoming routing
TEL and FAX incoming calls.
Settings for the TEL calling
Call limit
limitations
Settings for grouping the extension
Group
lines
Registering the SIP server
Extension Registering the Handset extension
numbers, passwords, and Notes
Registering the TEL/SMS contacts
4-1
Notes
4.1 Overview
Page
4-7
4-28
4-20
4-25
4-26
4-12
4-29
