Chapter 3—Covers and Doors
EasyCoder PF2i
Magnetic lock
Front hinge
Short door
Rear hinge
EasyCoder PF2i with a short side door.
Magnetic lock
Front hinge
Hinge not used
Long door
Rear hinge
EasyCoder PF2i with a long side door.
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
43
