6
Transfer Ribbon Mechanism
This chapter describes the mechanism that drives the thermal transfer
ribbon in the transfer-printing capable models of the EasyCoder PF2i,
PF4i, and PF4i Compact Industrial printers. It covers the following topics:
• Description
• Ribbon supply unit
• Ribbon rewind unit
• Ribbon sensor
• Ribbon motor
• Front ribbon break shaft
• Rear ribbon break shaft
• Printhead ribbon break shaft
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
61
