Intermec EasyCoder PF2i Service Manual page 11

EasyCoder PF4i
Keyboard shows printer model Keyboard shows printer model Keyboard shows printer model
Wide front on side door Wide front on side door Wide front on side door
Keyboard shows printer model
Wide front on side door
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
The EasyCoder PF4i comes either as a dedicated direct thermal printer
or a combined direct thermal/thermal transfer printer. It has an 8 dots/
mm (203.2 dpi) or an 11.81 dots/mm (300 dpi) printhead (IPL only 8
dots/mm). It can use media up to 114.3 mm (4.5 inches) wide and has a
maximum print width of 104 mm (4.095 inches) at 8 dots/mm or 105.7
mm (4.161 inches) at 11.81 dots/mm.
The printer runs either Intermec Fingerprint Programming Language (FP)
v8.10 (or later) or Intermec Programming Language (IPL) v2.10 or later.
Externally, the difference is visible on the keyboard overlay. Fingerprint
printers have 22 keys and IPL printers have 7 keys.
Chapter 1—Models and Options
EasyCoder PF4i (Fingerprint version)
EasyCoder PF4i (IPL version)
3
