Chapter 1—Models and Options
EasyCoder PF4i Compact Industrial
Front door
Front door
4
The EasyCoder PF4i Compact Industrial is a special model of Easy-
Coder PF4i that has been adapted for demanding industrial applications.
It differs from EasyCoder PF4i in having a dark-painted casing, stronger
hinges, a front door, a full metal media supply roll post, and a modifi ed
print mechanism. The EasyCoder PF4i comes either as a dedicated direct
thermal printer or a combined direct thermal/thermal transfer printer. It
has an 8 dots/mm (203.2 dpi) or an 11.81 dots/mm (300 dpi) printhead
(IPL only 8 dots/mm). It can use media up to 114.3 mm (4.5 inches) wide
and has a maximum print width of 104 mm (4.095 inches) at 8 dots/mm
or 105.7 mm (4.161 inches) at 11.81 dots/mm.
The printer runs either Intermec Fingerprint Programming Language (FP)
v8.10 (or later) or Intermec Programming Language (IPL) v2.10 or later.
Externally, the difference is visible on the keyboard overlay. Fingerprint
printers have 22 keys and IPL printers have 7 keys.
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
EasyCoder PF4i Compact Industrial (Fingerprint version)
EasyCoder PF4i Compact Industrial (IPL version)
