Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
14
Interfaces
This chapter describes the various communication interfaces for the Easy-
Coder PF2i, PF4i, and PF4i Compact Industrial printers. However, some
interfaces are not supported by the Intermec Programming Language (IPL)
even though the connecors are present.
The chapter describes three categories:
• Standard built-in interfaces
RS-232 interface
USB interface (not supported by IPL)
Bar code wand interface (not supported by IPL)
• Optional interface boards
Serial/Industrial interface board (not supported by IPL)
Double Serial interface board (not supported by IPL)
IEEE 1284 Parallel interface board
• EasyLAN interface boards
EasyLAN Ethernet interface
EasyLAN Wireless interface
The printers can—in addition to the standard built-in interfaces—also
be fi tted with one or two optional interface boards and one EasyLAN
interface board.
Note: Device designations, such as "uart1:", "usb1:", or "net1:", only
apply to Fingerprint, not to IPL.
163
