1.2 EasyCoder PF2i Specifications
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width (min/max)
Media Width (min/max)
Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Width (min/max)
Ribbon Roll Diameter, Outer (max)
Ribbor Roll Core Diameter, Inner
Print Directions
Modes of Operation
Tear Off (Straight-through)
Peel Off (Self-strip)
Firmware (Fingerprint)
Operating System
Smooth Fonts
Built-in scaleable fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Firmware (IPL)
Operating System
Built-in scaleable fonts (std)
Built-in bar code symbologies (std)
Physical Measures
Dimensions (W×L×H)
Weight (excluding media)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board SDRAM SIMM
Power Supply
AC Voltage
PFC Regulation
Power Consumption
Sensors
Label Gap/Black Mark/Out of Media
Printhead Lifted
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Direct Thermal (Thermal Transfer as option)
8 dots/mm (203.2 dpi)
100 to 200 mm/sec. (approx. 4 to 8 in./sec.)
56 mm (2.2 in.)
32767 dots = 409.5 cm (161.25 in.)
25 to 60 mm (1.00 to 2.36 in.)
40 to 60 mm (1.57 to 2.36 in.)
213 mm (8.38 in.)
38 to 40 mm (1.5 in.) or 76 mm (3 in.)
25 to 60 mm (1 to 2.36 in.)
65 mm (2.44 in.)
25.4 mm (1 in.)
4
Yes
Optional
Intermec Fingerprint v8.10
TrueDoc and TrueType fonts
15
45
Intermec Shell v8.0
IPL v2.10
13 scaleable + 21 simulated bitmap
31
194×397×178 mm (7.64×15.63×7.00 in.)
approx. 5.5 kg (12 pounds)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
32 bit RISC
2 sockets (for 4 or 8 MB each)
1 socket (for 8 or 16 MB)
90 to 265 VAC, 45 to 65Hz
IEC 61000-3-2
Standby 15W; Peak 300W
Yes
Yes
Chapter 1—Models and Options
= 448 dots
1
Standard edge guide
Quick-Load guides
Short door/no takeup
240-300 m (787-985 ft)
With liner takeup unit
Incl. Direct Protocol
Unicode fonts
With long side door
Std. 1 × 4MB
Std. 1 × 8MB
5 fi xed positions
2
11
