1.3 EasyCoder PF4i Specifications
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width (min/max)
Media Width (min/max)
Media Roll Diameter (max)
Media Roll Core Diameter
Ribbon Width (min/max)
Ribbon Roll Diameter, Outer (max)
Ribbor Roll Core Diameter, Inner
Print Directions
Modes of Operation
Tear Off (Straight-through)
Cut Off
Peel Off (Self-strip)
Firmware (Fingerprint)
Operating System
Smooth Fonts
Built-in scaleable fonts (std)
Built-in bar code symbologies (std)
Startup Program (std)
Firmware (IPL)
Operating System
Built-in scaleable fonts (std)
Built-in bar code symbologies (std)
Physical Measures
Dimensions (W×L×H)
Weight (excluding media)
Ambient Operating Temperature
Humidity
Electronics
Microprocessor
On-board Flash SIMMs
On-board SDRAM SIMM
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Thermal Transfer and/or Direct Thermal
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
100 to 200 mm/sec. (approx. 4 to 8 in./sec.)
100 to 150 mm/sec. (approx. 4 to 6 in./sec.)
104 mm (4.095 in.) = 832 dots
105.7 mm (4.161 in.) = 1248 dots
32767 dots = 409.5 cm (161.25 in.)
25 to 114.3 mm (1.00 to 4.5 in.)
40/80 to 114.3 mm (1.57/3.15 to 4.5 in.)
213 mm (8.38 in.)
38 to 40 mm (1.5 in.) or 76 mm (3 in.)
25 to 110 mm (1 to 4.33 in.)
65 mm (2.44 in.)
25.4 mm (1 in.)
4
Yes
Optional
Optional
Intermec Fingerprint v8.10
TrueDoc and TrueType fonts
15
45
Intermec Shell v8.0
IPL v2.10
13 scalable + 21 simulated bitmap
31
244×397×178 mm (9.61×15.63×7.00 in.)
253×447×178 mm (9.96×17.60×7.00 in.)
244×471×225 mm (9.61×18.54×8.86 in.)
approx. 7 to 8 kg (15.5 to 17.7 pounds)
+5°C to +40°C (+41°F to +104°F)
20 to 80% non-condensing
32 bit RISC
2 sockets (for 4 or 8 MB each)
1 socket (for 8 or 16 MB)
Chapter 1—Models and Options
Standard
Option (not IPL)
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
1
Standard edge guide
Quick-Load guides
Short door/no takeup
240-300 m (787-985 ft)
With paper cutter
With liner takeup unit
Incl. Direct Protocol
Unicode fonts
With long side door
With paper cutter
With 8-in. Megatop
Std. 1 × 4MB
Std. 1 × 8MB
2
13
