Chapter 7—Print Mechanism
10.3 mm (0.41 in.)
Print Width
max. 104.0 mm (4.095 in.)
Dot-line
on printhead
FEED Dot #831
Dot #0 DIRECTION
Media Width
25-114.3 mm (1-4.5 in.)
8 dots/mm (203.2 dpi) printhead
8.6 mm (0.34 in.)
Print Width
max. 105.7 mm (4.161 in.)
Dot-line
on printhead
FEED Dot #1247
Dot #0
DIRECTION
Media Width
25-114.3 mm (1-4.5 in.)
11.81 dots/mm (300 dpi) printhead
