Intermec EasyCoder PF2i Service Manual page 14

Chapter 1—Models and Options
Options for EasyCoder PF2i
Label taken
sensor
Short side door
Long side door
Transfer ribbon
mechanism
6
The EasyCoder PF2i can be fi tted with a number of options:
• Transfer Ribbon Mechanism
• Label Taken Sensor
• Liner Takeup Unit
• Media Supply Hub (replaces Supply Post)
• 3-inch Adapter (for Media Supply Hub)
• Quick-Load Guides
• Long or Short Side Door
• Real Time Clock Circuit (not IPL)
• Interface boards of various types
Quick-Load guides
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
(see Chapter 6)
(see Chapter 9)
(see Chapter 8)
(see Chapter 5)
(see Chapter 5)
(see Chapter 5)
(see Chapter 3)
(see Chapter 13)
(see Chapter 14)
Media supply
roll post with
edge guide
Media supply
hub
3-inch adapter
Liner takeup
with guide
shaft
