Appendix A—Program Overviews
Intermec Shell v8.0 Overview
POWER ON
ENTER=SHELL
5 sec. v.8.0
ENTER=SHELL
4 sec. v.8.0
ENTER=SHELL
3 sec. v.8.0
ENTER=SHELL
2 sec. v.8.0
ENTER=SHELL
1 sec. v.8.0
Last selected
application is started
Default:
Fingerprint 8.10 w. std I/O = "auto"
Legend:
Return to previous menu.
Proceed to next menu.
Accept displayed option
and proceed, or
execute displayed option.
Perform a Testfeed
anywhere in Intermec Shell.
Enter the Setup Mode
from anywhere
in Intermec Shell.
240
SHELL
SEL. APPLICATION
SHELL
SETUP
SHELL
PRINT SETUP
SHELL
TESTFEED
SHELL
TEST LABEL
SHELL
DEFAULT SETUP
SHELL
SOFTWARE UPDATE
SHELL
REBOOT
Restarts the printer (same as power off/on)
Note: To enter Intermec Shell if a custom-made autoexec-fi le prevents
access, lift the printhead and press any key on the printer's keyboard
(except the <Shift> key), then turn on the power while continuing to
press the key. When the Shell countdown begins, release the key and press
<Enter> to start Shell. Do not forget to lower the printhead if you want to
print for example test labels.
Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
SEL. APPLICATION
CURRENT APPL.
SEL. APPLICATION
Fingerprint 8.10
SEL. APPLICATION
Direct Protocol
Optional application
programs
SEL.APPL rom:
LINE_AXP.PRG
SETUP:
See the chapter "Setup Mode"
SER-COM,UART1
Prints a list of current setup values (test label "Setup Info").
Performs a Testfeed (feeds out a number of blank copies
while autoadjusting the label stop sensor).
Prints test labels "Diamonds", "Chess", "Bar Codes #1", and "Bar Codes #2" in a loop
Press Enter for each new label.
ARE YOU SURE? DEFAULT SETUP
YES=ENTER/NO=ESC PERFORMED
UPDATE: TRANSFER FILE
COMPACT FLASH? USING ZMODEM
TRANSFER
COMPLETED
UPDATE: TRANSFER FILE
FIRMWARE? USING ZMODEM
Last selected application is started
Note: Dotted channels are only shown if
the corresponding optional interface pcb
is fitted.
STD I/O CHANNEL
auto
STD I/O CHANNEL
uart1:
STD I/O CHANNEL
uart2:
STD I/O CHANNEL
uart3:
STD I/O CHANNEL
centronics:
STD I/O CHANNEL
net1:
STD I/O CHANNEL
usb1:
Printer rebooted
automatically.
