Intermec EasyCoder PF2i, PF4i, and PF4i Compact Industrial—Service Manual
Network extension cable
Cable tie
Optional interface board
(Serial/Industrial,
Double Serial, or
IEEE 1284 Parallel)
RJ-45 Ethernet
connector
Serial number label
Chapter 14—Interfaces
Light guide
Screw and spacer
CPU board
EasyLAN Ethernet interface
board
197
