Figure Legend
1 DC power fail indicator
2 Fan fail indicator
3 AC power fail indicator
4 Power supply status indicator
5 Power on/off switch
The following figure shows power supply with fan module indicators for these disk shelves:
Sun Disk Shelf
■
76
Oracle ZFS Storage Appliance Installation Guide • January 2014 E48491–02
6 Universal power input connector
7 Power cord tie wrap
