Prerequisites
Refer to the Quick Setup poster that shipped with the product or the following sections for an
overview of your controller.
7120 Overview
■
7320 Overview
■
7420 Overview
■
Tools and Equipment Needed
To install the system, you need the following tools:
No. 2 Phillips screwdriver
■
ESD mat and grounding strap
■
Pencil, stylus, or other pointed device, for pushing front panel buttons
■
You also need a system console device, such as one of the following:
Sun workstation
■
ASCII terminal
■
Terminal server
■
Patch panel connected to a terminal server
■
Tasks
7x20 Controllers Tasks
▼
Installing Mounting Brackets on the Controller Chassis
If the mounting brackets are shipped inside the slide rails, you must remove them before
beginning this procedure, as follows.
Unpack the slide rails and locate the slide rail lock at the front of the assembly.
■
Squeeze and hold the tabs at top and bottom of the lock (1) while you pull the mounting
■
bracket out to the stop.
Push the mounting bracket release button toward the front of the mounting bracket (2)
■
while withdrawing the bracket from the assembly.
The following graphic illustrates the procedure for disassembling the 7120/7320 rail kit.
Chapter 2 • Installation
