Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
When connect the Ethernet port, please use crossover cable to connect the PC and use the
straight cable to connect to the switcher or router.

2.3 Connection Sample

2.3.1 Mini 1U Series

Please refer to Figure 2-18 for connection sample.
The following figure is based on the simple entry-level series product.
GND port
Power socket
On/off button
Fan
th
th
DB25 port ( 5
to 16
-channel audio input port)
st
th
1
to 4
-channel audio input
Loop video output
Video input
Video CVBS output
Matrix video output
Audio output
Bidirectional talk input
Bidirectional talk output
Alarm input/Alarm output/RS485 port
Video VGA output
HDMI port
RS-232 port
eSATA port
USB port
Network port
Figure 2-17
35
