Optiview VR4HT User Manual page 43

13
2.2.2.4 4-ch Audio CIF Real-time Series
This series DVR rear panel is shown as below. See Figure
2-14.
Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
9
10
11
12
13
2.2.2.5 16-ch Audio CIF Real-time Series
This series DVR rear panel is shown as below. See Figure 2-15.
Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
GND port
Video input
st th
1 to 4 -channel audio input
Audio output
Video output
Video VGA output
HDMI port
RS232 port
USB port
Network port
Alarm input/Alarm output/RS485 port
On/off button
Power socket
GND port
Video input
st th
1 to 4 -channel audio input
Audio output
Video output
Video VGA output
HDMI port
RS232 port
Figure 2-14
Figure 2-15
33
