Table of Contents FEATURES AND SPECIFICATIONS ............. 1 Overview ........................1 Features ........................1 Specifications ......................2 1.3.42 4 Megapixel Tribrid Series .................. 98 1.3.43 HDVR4/8/16-Q2 ....................126 1.3.44 HDVR8/161080-Q2 ................... 133 1.3.45 HDVR32-Q4 ...................... 136 1.3.46 HDVR161080-Q4 ....................138 1.3.47 HDVR32-Q8 ......................
Page 3 OVERVIEW AND CONTROLS ............145 Front Panel ......................145 2.1.1 1U Series ....................... 150 2.1.2 1.5U Series ......................151 2.1.3 2U Series ....................... 153 Rear Panel ......................155 1U Series……………………………………………………………………… 2.2.30 2.2.31 General 4MP 1U Series ..................214 2.2.32 1.5U Series ....................... 215 2.2.33 2U Series ......................
Page 4 3.3.4 1U Series ....................... 243 3.3.5 1.5U series ......................244 3.3.6 2U series ....................... 244 3.3.7 Rack Installation ....................245 Connecting Power Supply ..................245 Connecting Video Input and Output Devices ............245 3.5.1 Connecting Video Input ..................245 3.5.2 Connecting Video Output ..................
Page 5 Right-Click Menu ....................261 4.5.1 Window Switch ...................... 262 4.5.2 Previous Screen/Next Screen ................263 4.5.3 PTZ Control ......................263 4.5.4 Auto Focus ......................268 4.5.5 Color ........................268 4.5.6 Display ........................270 4.5.7 Face Search ......................271 4.5.8 Search ........................271 4.5.9 Record Control ......................
Page 6 4.10 Information ......................288 4.10.1 System Info ....................... 288 4.10.2 Event ......................... 295 4.10.3 Network ......................295 4.10.4 Log ........................298 4.11 Setting ........................300 4.11.1 Camera ......................300 4.11.2 Network ......................318 4.11.3 Event ......................... 338 4.11.4 Storage ......................370 4.11.5 System ......................
Page 7 5.8.5 Setting ........................471 Information ......................489 5.9.1 Version ........................489 5.9.2 Log ........................490 5.9.3 Online User ......................491 5.9.4 HDD ........................491 5.10 Playback ........................ 491 5.10.1 Search Record ....................492 5.10.2 File List ......................493 5.10.3 Playback ......................494 5.10.4 Download ......................
Page 8 Appendix B-3 Compatible Portable HDD list ..............513 Appendix B-4 Compatible USB DVD List ................. 513 Appendix B-5 Compatible SATA DVD List ................ 513 Appendix B-6 Compatible SATA HDD List ............... 514 APPENDIX C COMPATIBLE CD/DVD BURNER LIST ......518 APPENDIX D COMPATIBLE DISPLAYER LIST ........
Page 9 Welcome Thank you for purchasing our 5-WAY DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series standalone DVR features and functions, as well as a detailed menu tree.
Page 10: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation.
Page 11: Features And Specifications
FEATURES AND SPECIFICATIONS 1.1 Overview The standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.
Page 12: Specifications
Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc. Support various playback modes: slow play, fast play, backward play and frame by frame play. Support time title overlay so that you can view event accurate occurred time Support customized zoom function during the preview.
Page 13 32Kbps-6144Kbps， Video Frame Rate For 720P: default setup is 2Mbps，max supports 4Mbps. For 1080N: default setup is 4Mbps，max supports 6Mbps. For 2K: non realtime default setup is 4Mbps，max supports 6Mbps. Bit Stream Type Video stream/composite stream Support Dual-Stream G.711A/G.711U/PCM Audio Encode Standard Parameters 8KHz，16Bit...
Page 14 Model Parameters 4-ch 8-ch 16-ch bandwidth:8Mbp bandwidth:16 bandwidth:32Mbp s-24Mbps Mbps-48Mbps 96Mbps 1-channel VGA output， Video Output 1-channel HDMI output, max 4K(3840*2160)@30f HDMI/ VGA video output at the same time (of the same video sourc or different video source). Loop Output Matrix Output When the HDMI and VGA are outputting different video, syste supports one matrix output.
Page 15: Hdvr4/8/16-Q2
1.3.2 HDVR4/8/16-Q2 Model Parameters 4-Ch 8-Ch 16-Ch System Main Processor High-performance industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Standard Encode 1080P@15f/1080N/720P/960H/D1/HD1/2CIF/CIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Bit Rate 32Kbps～6144Kbps Stream Video stream/composite stream Type Dual-Stream Support G.711A, G.711U, PCM...
Page 16    Network Video There is no IP There is no IP There Input channel by default. channel by default. channel channel channel by default. connections connections Max add 8   Analog Analog IP channel /digital channel /digital channel connectio switch.
Page 17 Video Output 1-ch VGA output, 1-ch HDMI output， HDMI/ VGA video output at the same time (VGA/HDMI of the same video source) Loop Output Matrix Output VGA/HDMI optional 4-ch，RCA port, Audio Port External Audio Input Coaxial Audio Input Audio Output 1-ch RCA port Bidirectional Support（Reuse the audio port of the 1...
Page 18: Hdvr8/161080-Q2
-10℃－＋55℃ Working Temperature Working 10%~90% Humidity Dimension 1U case，375mm（W）×280mm（D）×50mm（H） Weight ≤1.5KG ≤1.65KG ≤1.8KG No HDD Installation Desk installation Mode 1.3.3 HDVR8/161080-Q2 Model Parameters 4-Ch 8-Ch 16-Ch System Main Processor High-performance industrial embedded micro controller Embedded LINUX Video Video Encode H.264 Standard Encode 1080P/720P/960H/D1/HD1/2CIF/CIF...
Page 19    Network Video There is no IP There is no IP There is no IP Input channel channel channel default. default. default. channel channel channel connections. connections connections    Analog Analog Analog /digital channel /digital channel /digital channel switch.
Page 20 4-ch，RCA port, Audio Port External Audio Input Coaxial Audio Input Audio Output 1-ch RCA port Bidirectional Support（Reuse the audio port of the 1 channel） Talk Input Record Record Mode Auto record, manual record, motion detect record, alarm record Playback Mode Instant playback, normal playback, event playback, mark playback, smart playback Record...
Page 21: Hdvr32-Q4
1.3.4 HDVR32-Q4 Model Parameters 8-Ch 16-Ch 32-Ch System Main Processor High-performance industrial embedded micro controller Embedded LINUX Video Video Encode H.264H, H.264, H.264B Standard Encode 1080P@15fps/1080N/720P/960H/D1/HD1/2CIF/CIF Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate Video Bit Rate 32Kbps～6144Kbps ( For 720P:default value is 2Mbps，max value is 4Mbps. For 1080P:default value is 2Mbps，max value is 6Mbps) Stream Video stream/composite stream Type...
Page 22: Hdvr161080-Q4
source) source) source) Loop Output Matrix Output HDMI2 port support matrix output Audio Port External 4-channel BNC port, Audio Input Coaxial Audio 8-channel 16-channel 32-channel Input Audio Output 1-ch BNC port Support（Independent bidirectional talk port） Bidirectional Talk Input Record Record Mode Card number record, mark record, alarm record, motion detection record, regular record, manual record, intelligent record.
Page 23 System Main Processor High-performance industrial embedded micro controller Embedded LINUX Video Video Encode H.264H, H.264, H.264B Standard Encode 1080P/720P/960H/D1/HD1/2CIF/CIF/ Resolution Video Frame PAL:1~25f/s；NTSC：1~30f/s Rate 32Kbps～6144Kbps Video Bit Rate ( For 720P:default value is 2Mbps，max value is 4Mbps. For 1080P:default value is 4Mbps，max value is 6Mbps) Stream Video stream/composite stream Type...
Page 24: Hdvr32-Q8
Support（Independent bidirectional talk port） Bidirectional Talk Input Record Record Mode Card number record, mark record, alarm record, motion detection record, regular record, manual record, intelligent record. Playback Mode Instant playback, normal playback, event playback, mark playback, intelligent playback(human face, motion detection) Record Max 8-ch playback Max 16-ch playback...
Page 25 32Kbps～6144Kbps Video Bit Rate ( For 720P:default value is 2Mbps，max value is 4Mbps. For 1080P:default value is 2Mbps，max value is 6Mbps) Stream Video stream/composite stream Type Dual-Stream Support G.711A, G.711U, PCM Audio Encode Standard 8KHz，16Bit Audio Sampling Rate Audio Bit Rate 64Kbps Video Port Analog...
Page 26: Hdvr161080-Q8
Support（Independent bidirectional talk port） Bidirectional Talk Input Record Record Mode Card number record, mark record, alarm record, motion detection record, regular record, manual record, intelligent record. Playback Mode Instant playback, normal playback, event playback, mark playback, intelligent playback(human face, motion detection) Record Max 8-ch playback Max 16-ch playback...
Page 27 PAL:1~25f/s；NTSC：1~30f/s Video Frame Rate Video Bit Rate 32Kbps～6144Kbps ( For 720P:default value is 2Mbps，max value is 4Mbps. For 1080P:default value is 4Mbps，max value is 6Mbps) Stream Video stream/composite stream Type Support Dual-Stream Audio Encode G.711A, G.711U, PCM Standard 8KHz，16Bit Audio Sampling Rate Audio Bit Rate 64Kbps...
Page 28 Playback Mode Instant playback, normal playback, event playback, mark playback, intelligent playback(human face, motion detection) Record Max 8-ch playback Max 16-ch playback Playback Backup Mode HDD, burner, flash disk, network backup. Alarm Alarm Input 16-channel Alarm Output 6-channel 8 SATA ports. Support eSATA port. HDD Port Space/HDD 2 RJ45 ports, 1000Mbps Ethernet port...
Page 29: Overview And Controls
2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel 2.1.1 1U Series The front panel is shown as below. See Figure 2-6. Figure 2-6 Please refer to the following sheet for front panel button information.
Page 30: U Series
Shift Shift In textbox, click this button to switch between numeral, English(Small/Capitalized),donation and etc. 、 Up/1 Activate current control, modify setup, and then move up and Down/4 down. Increase/decrease numeral. Assistant function such as PTZ menu. In text mode, input number 1/4 (English character G/H/I) ...
Page 31 ►│ Play Next/9 In playback mode, playback the next video In menu setup, go to down ward of the dropdown list. In text mode, input number 9 (English character W/X/Y/Z) ►|| Play/Pause /5 In normal playback click this button to pause playback In pause mode, click this button to resume playback.
Page 32 2.2 Rear Panel 2.2.1 General 4MP 1U Series The rear panel is shown as in Figure 2-83. The following figure is based on the 8-channel series product. Figure 2-83 Please refer to the following sheet for detailed information. Icon Name Function VIDEO IN Video...
Page 33: U Series
Icon Name Function Power switch Power on/off button. Power switch Power on/off button. AUDIO OUT Audio output Connect to sound box and etc to output audio signal. port RS485 RS485_A port. It is the cable A. You can connect to the control devices such as speed dome PTZ.
Page 34 Icon Name Note MIC OUT Audio output port. It is to output the Audio output port analog audio signal to the devices such as the sound box. MIC IN Audio input port Bidirectional talk input port. It is to receive the analog audio signal output from the devices such as microphone, pickup.
Page 35 Icon Name Note Four-wire full-duplex 485 port. T+， T+、T-、R+、R- Four-wire full-duplex 485 port T- is the output wire. R+，R- is the input wire. CTRL 12V Control power output Controller 12V power output. It is to control the on-off alarm relay output.
Page 36 Figure 2-85 Please refer to the following sheet for detailed information. Icon Name Note It is to receive the analog audio Audio input port AUDIO IN signal output from the devices such as microphone. Audio output port. It is to output the Audio output port MIC OUT analog audio signal to the devices...
Page 37 Icon Name Note NO3～C3, Group 4：port NO4～C4, Group 5: port NO5, C5, NC5).Output alarm signal to the alarm device. Please make sure there is power to the external alarm device.  NO: Normal open alarm output port.  C: Alarm output public end. ...
Page 38: Series
Icon Name Note High definition audio and video signal output port. It outputs the High Definition HDMI1 same video source as VGA/TV. Media Interface 1 Support mouse operation control. High definition audio and video signal output port. Support multiple- High Definition HDMI2 Media Interface 2...
Page 39 Icon Name Note Audio input port Bidirectional talk input port. It is to receive the analog audio signal MIC IN output from the devices such as microphone, pickup. Video output port Connect to video output devices VIDEO OUT such as TV. Audio output port.
Page 40 Icon Name Note Four-wire full-duplex 485 port. T+， Four-wire full-duplex T+、T-、R+、R- T- is the output wire. 485 port R+，R- is the input wire. Control power output Controller 12V power output. It is to CTRL 12V control the on-off alarm relay output.
Page 41: Series
Icon Name Note RS232 debug COM. It is for general COM debug to RS-232 configure IP address or transfer transparent COM data. Network port 1000Mbps Ethernet port Video input port Connect to analog camera, video VIDEO IN input signal. 2.2.3 2U Series The 8-channel 5-Way720P 2U rear panel is shown as below.
Page 42 Icon Name Note Power switch Power on/off button. Power socket Power socket AUDIO IN It is to receive the analog audio Audio input port signal output from the devices such as microphone. MIC IN Audio input port Bidirectional talk input port. It is to receive the analog audio signal output from the devices such as microphone, pickup.
Page 43: Connection Sample
Icon Name Note C5, NC5).Output alarm signal to the alarm device. Please make sure there is power to the external alarm device.  NO: Normal open alarm output port.  C: Alarm output public end.  NC: Normal close alarm output port.
Page 44 Icon Name Note VGA video output VGA video output port. Output port analog video signal. Can connect to the monitor to view ananlog video output. Network port 1000Mbps Ethernet port VIDEO IN Video input port Connect to analog camera, video input signal.
Page 45 Icon Name Note It is to receive the analog audio Audio input port signal output from the devices such AUDIO IN as microphone. Alarm input port 1～  There are four groups. The first group is from port 1 to port 4, the second group is from port 5 to port 8, the third group is from 9 to 12, and the fourth group is...
Page 46 Icon Name Note note the supplying power shall be below 1A. Ground Ground RS232 debug COM. It is for general COM debug to RS-232 configure IP address or transfer transparent COM data. VGA video output VGA video output port. Output port analog video signal.
Page 47: Series
2.3 Connection Sample 2.3.1 1U Series Please refer to the following figure for detailed information. See Figure 2-94. Figure 2-94...
Page 48: U Series
2.3.2 1.5U Series The connection sample is shown as below. See Figure 2-95. The following interface is based on the 32-channel series product.
Page 49: Series
Figure 2-95 2.3.3 2U Series Please refer to the following figure for detailed information. See Figure 2-96. The following interface is based on the 16-channel general 720P (V2) 2U series product.
Page 50: Remote Control
2.4 Remote Control The remote control interface is shown as in Figure 2-97. Please note remote control is not our standard accessory and it is not included in the accessory bag. Figure 2-97 Serial Number Name Function Power button Click it to boot up or shut down the device.
Page 51 Forward Various forward speeds normal speed playback. Slow play Multiple slow play speeds or normal playback. Next record In playback mode, playback the next video. Previous record In playback mode, playback the previous video. Play/Pause In pause mode, click this button to realize normal playback.
Page 52: Mouse Control
In motion detection interface, working with direction keys to complete setup. In text mode, click it to delete character. 0-9 number key Input password, channel switch channel. Shift is the button to switch the input method. 2.5 Mouse Control Left click System pops up password input dialogue box if you have not logged in.
Page 53 In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character.
Page 54: Virtual Keyboard & Front Panel
Right click In real-time monitor mode, pops up shortcut menu: one-window, four- mouse window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.
Page 55: Installation And Connections
3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
Page 56: Smart 1U Series
○ ○ ○ Put the HDD into the Draw out the HDD bracket Make sure the HDD metal device. surface is facing up and then put into bracket horizontally . After the HDD is in the proper position, the columns on the two sides can lock the screw holes of the HDD to secure When you remove the HDD, please refer to the following figure to pull the spring up and...
Page 57: Compact 1U And Mini 1U Series
○ ○ ○ Turn the device upside down and Fix the HDD firmly. Connect the HDD cable and then turn the screws in firmly. power cable. ○ ○ Secure the screws in the rear panel and the side panel. Put the cover in accordance with the clip and then place the upper cover back.
Page 58: Series
④ ⑤ ⑥ Turn the device upside down and Fix the HDD firmly. Connect the HDD cable and then turn the screws in firmly. power cable. ⑦ ⑧ Put the cover in accordance with the Secure the screws in the rear panel clip and then place the upper cover and the side panel.
Page 59: U Series
Turn the device upside down and Connect the HDD cable and Put the cover in accordance then turn the screws in firmly. power cable. with the clip and then place the upper cover back. Secure the screws in the rear panel and the side panel.
Page 60: Rack Installation
HDD to the bottom bracket. ⑤ ⑥ Connect the power cable to the Put the cover back and fix the ○ 4 Connect the other end of the HDD. screws to secure firmly. HDD cable to the mainboard. Important: If the HDD amount is less than four, you do not need to install the HDD bracket. When there is a bracket, please make sure the installation direction of HDDs is the same.
Page 61: Connecting Video Output
explosive substances and etc. The camera and the DVR should have the same grounding to ensure the normal operation of the camera. Guarantee stability and reliability of the transmission line B T T T B Please use high quality, sound shielded BNC. Please select suitable BNC model according to the transmission distance.
Page 62: Alarm Input And Output Connection
3.7 Alarm Input and Output Connection Please read the followings before connecting. 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c. Alarm input needs the low level voltage signal. d.
Page 63: Alarm Input Port
Figure 3-1 1，2，3，4，5，6， ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 7，8，9，10，11， 12，13，14，15，16 In the second line, There are six groups of normal open activation output (on/off button) from the left to the right: NO1 C1， NO2 C2，...
Page 64: Alarm Output Port
 Please connect the NC port of the alarm sensor to the DVR alarm input(ALARM)  Use the same ground with that of DVR if you use external power to the alarm device. Figure 3-2 3.7.3 Alarm Output Port Provide external power to external alarm device. To avoid overloading, please read the following relay parameters sheet carefully....
Page 65: Other Interfaces
Model HFD23/005-1ZS HRB1-S-DC5V -30℃～+70℃ -40℃～+70℃ Working Temperature 3.8 RS485 When the DVR receives a camera control command, it transmits that command up the coaxial cable to the PTZ device. RS485 is a single-direction protocol; the PTZ device can’t return any data to the unit.
Page 66: Overview Of Navigation And Controls
4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure: The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. Always use the stable current, if necessary UPS is a best alternative measure.
Page 67: Set Password
4.2.1 Set Password For your own safety, please set your administrator default password after you first boot up the device. After system booted up, you can see the following interface if it is your first time to use or you have restored default setup. See Figure 4-1. Please input a password and then input again to set a password.
Page 68: Reset Password
4.2.2 Reset Password Once you forgot password, you can answer the security questions you set in chapter 4.2.1 to reset the password. In login interface, . See Figure 4-3. Figure 4-3 System pops up the following dialogue box, please answer the security questions and then input the new password twice.
Page 69 Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time. Cancel the Startup button, system goes to the login interface directly when it boots up the next time.
Page 70 Caution For security reason, please modify password after you first login. Continuous three times login failure will result in system alarm and five times login failure will result in account lock! Please reboot the device or wait for 30 minutes to try again if your account has been locked....
Page 71 For detailed information, please refer to chapter 4.10.3. Figure 4-8 Click Next button, you can set P2P function. Scan the QR code, download the App to the cellphone, you can use the smart phone to add the device. See Figure 4-9. For detailed information, please refer to chapter4.11.2.15.
Page 72 Now you can go to the remote device interface to add the camera to the corresponding channel. See Figure 4-10. For detailed information, please refer to chapter4.11.1.1. Please note you can not see the following interface if there is no digital channel. You can go to Main menu->Setting->Camera->Channel type to set IP channel first.
Page 73 Figure 4-11 Click Next button, you can go to Schedule interface. See Figure 4-12. For detailed information, please refer to chapter 4.11.4.1. Figure 4-12...
Page 74: Live Viewing
Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete. See Figure 4-13. Figure 4-13 4.4 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No.
Page 75  Right now, system does not support slow playback and backward playback function. Support digital zoom function. Support real-time backup function. You can follow the contents listed below for the operation instruction. Preview control interface Move you mouse to the top center of the video of current channel, you can see system pops up the preview control interface.
Page 76: Right-Click Menu
Put the middle button at the center of the zone you want to zoom in, and move the mouse, you can view an interface shown as in Figure 4-17. Figure 4-17 Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device.
Page 77: Window Switch
After you go to the corresponding interface, right click mouse to go back to the upper- level. Window split mode: You can select window amount and then select channels. PTZ: Click it to go to PTZ interface. Auto focus: Please make sure you connected network camera supports this function. Color setting: Set video corresponding information....
Page 78: Previous Screen/Next Screen
Figure 4-19 4.5.2 Previous Screen/Next Screen Click it to go to the previous screen/next screen. For example, if you are using 4-split mode, the first screen is displaying the channel 1-4, click Next screen, you can view channel 5-8. 4.5.3 PTZ Control The PTZ setup is shown as in See Figure 4-20.
Page 79 Figure 4-20 In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See Figure 4-21. Please make sure your protocol supports this function and you need to use mouse to control. Click this key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size.
Page 80 Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4- Icon Function Icon...
Page 81 Figure 4-24 Tour Setup In Figure 4-23, click tour button. Input tour value and preset No. Click Add preset button to add current preset to the tour. See Figure 4-25. Tips Repeat the above steps to add more presets to the tour. Click Del preset button to remove it from the tour.
Page 82 Figure 4-26 Scan Setup In Figure 4-23, click Scan button. Use direction buttons to set camera left limit and then click Left button. Use direction buttons to set camera right limit and then click Right button. Now the scan setup process is complete. Figure 4-27 4.5.3.2 Call PTZ Function Call Preset...
Page 83: Auto Focus
In Figure 4-22, input tour value and then click to call a tour. Click again to stop call. Call Scan In Figure 4-22, input Scan value and then click to call a tour. Click again to stop call. Rotate In Figure 4-22, click to enable the camera to rotate.
Page 84 Figure 4-29 Please refer to the following sheet for detailed information. Item Note Period There are two periods in one day. You can set different sharpness, brightness, and contrast setup for different periods. Effective Time Check the box here to enable this function and then set period time.
Page 85: Display
Item Note from 0 to 100. The default value is 50. The larger the number, the higher the contrast is. You can use this function when the whole video bright is OK but the contrast is not proper. Please note the video may become hazy if the value is too low.
Page 86: Face Search
Figure 4-30 4.5.7 Face Search It is to display human face record list, and view human face recognition record file. 4.5.8 Search Please refer to chapter 4.9.1 for detailed information. 4.5.9 Record Control Please refer to chapter 4.11.4.3 for detailed information. 4.5.10 Alarm Output Please refer to chapter 4.11.3.6 for detailed information.
Page 87: Main Menu
Figure 4-31 4.6.1 Main Menu Click button to go to the main menu interface. 4.6.2 Output Screen Select corresponding window-split mode and output channels. 4.6.3 Previous/Next Screen Click to go to the previous screen, click to go to the next screen. For example, if you are using 4-split mode, the first screen is displaying the channel 1-4, click , you can view channel 5-8.
Page 88: Channel Info
Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 4.11.3. 4.6.11 Channel Info Click , system goes to the channel information setup interface. It is to view information of the corresponding channel.
Page 89: Usb Device Auto Pop-Up
， system goes to the USB Manager interface. It is to view USB information, Click backup and update. Please refer to chapter 4.9.3, chapter 4.10.4, chapter 4.11.5.10, and chapter 4.11.5.12 for detailed information. 4.7 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.
Page 90: Operation
Figure 4-35 4.9 Operation 4.9.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4- Usually there are four file types: R: Regular recording file. A: External alarm recording file. M: Motion detection recording file Orange: Intelligent recording file....
Page 91 Figure 4-36 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
Page 92 corresponding record file trace in the time bar.  Playback mode：1/4/9/16/customized. (It may vary due to different series.)  In 1-window playback mode: you can select 1-16 channels.  In 4-window playback mode: you can select 4 channels according to your Playback requirement.
Page 93 Click it again to pause current play. In backward play mode, click ►/ to restore normal play. In playback mode, click it to play the next or the previous section. You can click continuously when you are watching the files from the same channel. │/ In normal play mode, when you pause current play, you can click │...
Page 94  Select the file(s) you want to backup from the file list. You can check from the list. Then click the backup button, now you can see the backup menu. System supports customized path setup. After select or create new folder, click the Start button to begin the backup operation.
Page 95 when playback In pane 13 of Figure 4-36, click Sync button, you can playback the files of different Sync channels occurred at the same time. Digital When the system is in full-screen playback mode, left click the mouse in the zoom screen.
Page 96 During the multiple-channel playback, system stops playback of rest channels if you implement one-channel smart search. 4.9.1.2 Accurate playback by time Select records from one day, click the list, you can go to the file list interface. You can input time at the top right corner to search records by time. See image on the left side of the Figure 4-38 For example, input time 11:00.00 and then click Search you can view all the record files after 11:00.00 (The records includes current time.).
Page 97 Figure 4-39 Playback Mark During 1-window playback mode, click mark file list button in Figure 4-36, you can go to mark file list interface. Double click one mark file, you can begin playback from the mark time. Play before mark time Here you can set to begin playback from previous N seconds of the mark time.
Page 98 Double click one mark information item, you can see system pops up a dialogue box for you to change mark information. You can only change mark name here. Delete Here you can check the mark information item you want to delete and then click Delete button, you can remove one mark item.
Page 99: Human Face Search
On the right pane, check the box to enable splice playback function, and then set channel, date, split mode. The splice playback interface is shown as below. Each section has a small triangle; adjust time. Figure 4-42. Figure 4-42 Note Select split mode, so that the record can be spliced in several sections.
Page 100: Backup
Figure 4-43 Please refer to the following sheet for detailed information. Name Function Display It is to display human face detection file list. The latest file is at the  top. \ Click Export, you can export the selected file to the USB device. ...
Page 101 You can view backup device name and its total space and free space. The device includes CD-RW, DVD burner, USB device, flash disk, eSATA backup. Figure 4-44 Select backup device and then set channel, file start time and end time. Click add button, system begins search.
Page 102: Shut Down
button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button. You can view the remaining time and process bar at the left bottom. See Figure 4-46. Figure 4-46 When the system completes backup, you can see a dialogue box prompting successful backup.
Page 103: Information
Figure 4-47 4.10 Information 4.10.1 System Info Here is for you to view system information. There are total four items: HDD (hard disk information), record, BPS (data stream statistics), version. See Figure 4-48. Figure 4-48 4.10.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-49.
Page 104 normal. X means there is error. - means there is no HDD. If disk is damaged, system shows as “?”. Please remove the broken hard disk before you add a new one. SN: You can view the HDD amount the device connected to. ﹡ means the second HDD is current working HDD....
Page 105 Figure 4-50 4.10.1.2 Record Info It is to view record start time and end time. See Figure 4-51. Figure 4-51 4.10.1.3 Record Estimate System can calculate the record time based on the HDD space, or you can input the record time you want to calculate the HDD space you need. See Figure 4-52.
Page 106 Figure 4-52 Click after the channel name, system pops up Edit dialogue box. See Figure 4-53. You can input resolution, frame rate, bit stream, record time of the corresponding channel, system can calculate the record time based on the channel setup and HDD space. Figure 4-53...
Page 107 Calculate the record period based on the HDD space Check the channel you want to record file. Click Known Space and then click the button to set HDD. Click OK button. Now you can see the record period (such as 5 days). See Figure 4-54. Figure 4-54 Calculate the HDD space based on the record period...
Page 108 Figure 4-55 4.10.1.4 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-56. Figure 4-56...
Page 109 4.10.1.5 Device Status It is to view device status information. See Figure 4-57. Please note this function is for some series only. Figure 4-57 4.10.1.6 Version Here is for you to view some version information such as version number, built date, serial number and etc.
Page 110: Event
Figure 4-58 4.10.2 Event It is to display device status and channel status. See Figure 4-59. Figure 4-59 4.10.3 Network 4.10.3.1 Online Users...
Page 111 Here is for you to manage online users. See Figure 4-60. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
Page 112 Figure 4-61 4.10.3.3 Network Test Network test interface is shown as in Figure 4-62. Destination IP: Please input valid IPV4 address or domain name. Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc....
Page 113: Log
Figure 4-62 4.10.4 Log 4.10.4.1 Local Log Here is for you to view system log file. System lists the following information. See Figure 4-63. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.
Page 114 Figure 4-63 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-64. Figure 4-64...
Page 115: Setting
Note If there is no HDD, system max supports 1024 logs. If you have connected to the unformatted HDD, system max supports 5000 logs. If you have connected to the formatted HDD, system max supports 500,000 logs. System operation logs are saved in system memory. Other types of logs are saved in the HDD.
Page 116 Please note: This series product supports the IPC from many popular manufactures such as Sony, Hitachi, Axis, Samsung, Dynacolor, Arecont, Onvif and Optiview. System default IP address is 192.168.0.0 if you do not input IP address. System will not add current IP address....
Page 117 Show filer: It is to filter the searched device.  None: it is to display all searched devices.  IPC: It is to display all cameras.  DVR: It is to display all storage devices such as NVR, DVR. Change IP: ...
Page 118 Figure 4-68 IP Export System can export the Added device list to your local USB device. Please insert the USB device and then click the Export button; you can see the following interface. See Figure 4-69. Figure 4-69 Select the directory and then click the OK button. System pops up a dialogue box to remind you successfully exported.
Page 119 Note The exported file extension name is .CVS. The file information includes IP address, port, remote channel number, manufacturer, user name and password. IP Import Click Import button, you can see the following interface. See Figure 4-70. Figure 4-70 Select the import file and then click the OK button. System pops up a dialogue box to remind you successfully exported.
Page 120 Connection status: : Connection succeeded. : Connection failed. Refresh: Click it to get latest front-end channel status. Figure 4-71 4.11.1.1.3 Firmware It is to view channel, IP address, manufacturer, type, system version, SN, video input, audio input, and etc. See Figure 4-72. Figure 4-72...
Page 121 4.11.1.2 Image For analog channel, the camera interface is shown as in Figure 4-73. For digital channel, the camera interface is shown as in Figure 4-74. Channel: Select a channel from the dropdown list. Cable type: It is to set the cable type of the corresponding analog channel. When the setup here matches the actual cable you are using, you can get the best image effect.
Page 122  HLC: After you enabled HLC function, the device can lower the brightness of the brightest section according to the HLC control level. It can reduce the area of the halo and lower the brightness of the whole video.  OFF: It is to disable the BLC function.
Page 123 Figure 4-73 Figure 4-74...
Page 124 4.11.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.11.1.3.1 Video Video setting includes the following items. See Figure 4-75. Channel: Select the channel you want. SVC: SVC is so called scaled video coding. Check the box to enable this function. During the network transmission process, system discards unimportant frames when the bandwidth is not sufficient or the decode capability is low.
Page 125 Figure 4-75 4.11.1.3.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-76. Snapshot mode: There are two modes: regular and trigger. If you set timing mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation....
Page 126 Figure 4-76 4.11.1.3.3 Overlay Overlay interface is shown as in Figure 4-77. Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. Preview/monitor: privacy mask has two types.
Page 127 Figure 4-77 Figure 4-78 4.11.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-79. Please note for digital channel, you can only modify the channel name of the connected network camera.
Page 128 Figure 4-79 4.11.1.3.5 Channel Type It is to set channel type. For analog channel (CVBS signal or 5-WAY HD signal), you can select coaxial cable or UTP cable. Please check first and then save setup. There is no need to reboot....
Page 129 Figure 4-80 Figure 4-81 Important notice about 5-Wayseries product: Nowadays, there are mainly two analog signal types on today market: analog...
Page 130 standard definition (CVBS) and analog HD (CVI, AHD or Other). For 5-Wayseries product, each channel supports all types of signal connection (analog signal/IP signal). For analog signal connection, the default setup is AUTO, that is to say, no matter what analog signal (CVBS, CVI, AHD or other analog HD signal) connected; the 5-Waycan automatically recognize the signal and display the proper image.
Page 131 Figure 4-83 Figure 4-84 For example, there is a 4-channel analog device, after the A/D switch, it can max supports 4 analog channels and 4 IP channels. Once it has become the 3+1 mode (3 analog channels+1 IP channel), you button, system becomes 3+5 mode (3 analog channels+5 IP channel).
Page 132 restore original status. Figure 4-85 Figure 4-86 4.11.1.3.6 Upgrade Important...
Page 133: Network
5-Wayseries product does not support upgrade function via coaxial cable. That is to say, you cannot use this interface to upgrade the connected CVI camera if you are using 5-Wayseries product. It is to update the online camera. From main menu->setting->camera->remote upgrade, the interface is shown as below. See Figure 4-87.
Page 134 you need to set one master card. Usually there is only one running card (master card).System can enable alternate card when the master card is malfunction. The system is shown as offline once these two cards are both offline. Please note these two cards shall be in the same LAN.
Page 135  1492: Recommend value for PPPoE.  1468: Recommend value for DHCP. Preferred DNS server: DNS server IP address. Alternate DNS server: DNS server alternate address. Transfer mode: Here you can select the priority between fluency/video qualities. LAN download: System can process the downloaded data first if you enable this function.
Page 136 Figure 4-89 4.11.2.2 Connection The connection setup interface is shown as in Figure 4-90. Max connection: system support maximal 128 users. 0 means there is no connection limit. TCP port: Default value is 37777. UDP port: Default value is 37778. HTTP port: Default value is 80....
Page 137 Figure 4-90 4.11.2.3 WIFI The WIFI interface is shown as below. See Figure 4-91. Auto connect WIFI: Check the box here, system automatically connects to the previous WIFI hotspot. Refresh: You can click it to search the hotspot list again. It can automatically add the information such as the password if you have set it before....
Page 138 Figure 4-91 WIFI working status: Here you can view current connection status. Please note: After successful connection, you can see WIFI connection icon at the top right corner of the preview interface. When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type....
Page 139 APN: It is the wireless connection server. It is to set you access the wireless network via which method. AUTH: It is the authentication mode. It supports PAP/CHAP. Dial number: Please input 3G network dialup number you got from your ISP. User name: It is the user name for you to login the 3G network....
Page 140 Figure 4-93 4.11.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-94. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
Page 141 Figure 4-94 Please note DDNS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
Page 142 Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. User name: It is optional.
Page 143 Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note: If you enabled trusted sites, only the IP in the trusted sites list can access the device. If you enabled blocked sites, the IP in the blocked sites can not access the device. System supports add MAC address....
Page 144 Title: Please input email subject here. System support English character and Arabic number. Max 32-digit. Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly. SSL enable: System supports SSL encryption box. Interval: The send interval ranges from 0 to 3600 seconds.
Page 145 Please install Ser-U FTP SERVER first. From “start” -> “program” -> Serv-U FTP Server -> Serv-U Administrator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-98. Figure 4-98 You can use a PC or FTP login tool to test setup is right or not.
Page 146 uploads all corresponding files. After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. Figure 4-100 4.11.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN.
Page 147 Add to the list: Click it to add the mapping relationship. Delete: Click it to remove one mapping item. Double click one item; you can change the corresponding mapping information. See Figure 4-102. Important: When you are setting the router external port, please use 1024~5000 port. Do not use well-known port 1~255 and the system port 256~1023 to avoid conflict.
Page 148 SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments. It is used in many network device, software and system. You can set in the following interface. See Figure 4-103. Figure 4-103 Please enable the SNMP function.
Page 149 Multicast setup interface is shown as in Figure 4-104. Figure 4-104 Here you can set a multiple cast group. Please refer to the following sheet for detailed information. IP multiple cast group address  -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110” Reserved local multiple cast group address...
Page 150 example: Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only.
Page 151 Figure 4-105. Click Add button to complete the setup. 4) Now you can boot up the proxy server. When you see the network status is Y, it means your registration is OK. You can view the proxy server when the device is online. Important The server IP address can also be domain.
Page 152 Figure 4-107 Android: Open Google Play app in your smart phone. Search gDMSS Lite or gDMSS Plus, download it and install. iOS: Open App Store app in your smart phone. Search iDMSS Lite or iDMSS Plus, download it and install. Please follow the steps listed below.
Page 153: Event
Figure 4-108 4.11.3 Event 4.11.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-109.There is three detection types: motion detection, video loss, tampering. The video loss has no detection region and sensitivity setup and tampering has no detection region setup....
Page 154 Region: Click select button, the interface is shown as in Figure 4-110. Here you can set motion detection zone. There are four zones for you to set. Please select a zone first and then left drag the mouse to select a zone. The corresponding color zone displays different detection zone.
Page 155 Record channel: System auto activates motion detection channel(s) to record once an alarm occurs. Please make sure you have set MD record in Schedule interface(Main Menu->Setting->Schedule) and schedule record in manual record interface(Main Menu- >Advanced->Manual Record)  PTZ activation: Here you can set PTZ movement when an alarm occurs. Such as go to preset, tour &pattern when there is an alarm.
Page 156 Figure 4-109 Figure 4-110...
Page 157 Figure 4-111 Figure 4-112...
Page 158 Figure 4-113 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.11.3.1.2 Video Loss In Figure 4-109, select video loss from the type list. You can see the interface is shown as in Figure 4-114.This function allows you to be informed when video...
Page 159 Figure 4-114 4.11.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-115. You can enable “Alarm output “or “Show message”...
Page 160 Figure 4-115 4.11.3.1.4 Diagnosis Note This function is for some series only. System can trigger an alarm when the stripe, noise, color cast, out of focus, over exposure event occurred. See Figure 4-116. Please refer to chapter 4.11.3.1.1 motion detection for detailed information.
Page 161 Figure 4-116 This function allows you to be informed when video is blurry, over exposure or color cast occurs. You can enable alarm output channel and then enable show message function. Click the Rule Set button, or move the cursor to Set button and then click the Enter button on the front panel, the interface is shown as below.
Page 162 Figure 4-117 Note Video analysis alarm can trigger PTZ preset, tour, and pattern. Please refer to chapter 4.11.3.1.1 motion detection for detailed information. 4.11.3.2 Intelligence (Optional) Important The intelligence function is optional. The different series products support different IVS functions. Please refer to your purchased product actual interface for detailed information....
Page 163 Figure 4-118 Select a channel from the dropdown list. Click Add button to add a rule and then select a rule type from the dropdown list. Click to draw the rule. For detailed information, please refer to chapter 4.11.3.2.1 Tripwire, 4.11.3.2.2 Intrusion, chapter 4.11.3.2.3 Abandoned. Click to set corresponding parameters.
Page 164 Figure 4-119 Check the Enable box to enable tripwire function. Click Rule setup to draw the tripwire. See Figure 4-120. Figure 4-120 Select SN (Line1/2/3/4) and direction, and then input customized rule name.
Page 165 Line1/2/3/4: System supports four tripwires. Each SN stands for one tripwire. Direction ( ): System can generate an alarm once there is any object crossing in the specified direction. Now you can draw a rule. Left click mouse to draw a tripwire. The tripwire can be a direct line, curve or polygon.
Page 166  In Figure 4-112, Select icon of several dates, all checked items can be edited together. Now the icon is shown as . Click to delete a record type from one period.  In Figure 4-112. Click button after one date or a holiday, you can see an interface shown as in Figure 4-113.
Page 167 Figure 4-123 Figure 4-124 4.11.3.2.2 Intrusion (Cross warning zone) Note: The intrusion function is valid once your network camera or your DVR supports this function. If your purchased DVR supports the intrusion function, it supports one analog channel. It is not for the digital channel. System generates an alarm once there is any object entering or exiting the zone in the specified direction.
Page 168 Figure 4-125 Check the enable box to enable intrusion function. Click Rule setup to draw the zone. See Figure 4-126. Figure 4-126 Select SN (Area1/2/3/4) and direction, and then input customized rule name. Area1/2/3/4: System supports four zones. Each SN stands for one zone. Direction ( ): System can generate an alarm once there is...
Page 169 Tips Click to delete the corresponding rule. You can refer to the chapter 4.11.3.2 to set parameters. 4.11.3.2.3 Object protection (Optional) Note: The object protection function is valid once your network camera or your DVR supports this function. If your purchased DVR supports the object protection function, it supports one analog channel.
Page 170 Figure 4-128 Select SN (object1/2/3/4) and direction, and then input customized rule name. Object1/2/3/4: System supports four zones. Each SN stands for one zone. Direction ( ): For icon , system can generate an alarm once the object left in the one for the specified time. For icon , system can generate an alarm once the object is out of the zone for the specified time.
Page 171 Figure 4-129 Click draw button to draw the zone. See Figure 4-130. Figure 4-130 Name: Input customized rule name....
Page 172 Period: System can generate an alarm once the object is in the zone for the specified period. Target filter: , you can set filter object size. Each rule can set two sizes (min size/max size). Once the object is smaller than the min size or larger than the max size, there is no alarm.
Page 173 Figure 4-132 Name: Input customized rule name. Period: System can generate an alarm once the object in the zone is missing for the specified period. Target filter: , you can set filter object size. Each rule can set two sizes (min size/max size).
Page 174 Note The face detection function is valid once your network camera or your DVR supports this function. If your purchased DVR supports the face detection function, it supports one analog channel. It is not for the digital channel. System can detect and filter the human face via analyzing the video. When it detects the human face in the specified zone, it can draw the rectangle around the human face and trigger record, snapshot, alarm operation and etc.
Page 175 5-Wayseries product does not support 5-WAY alarm function (Figure 4-136). Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. For analog channel, the interface is shown as in Figure 4-134 and Figure 4-135 For 5-WAY channel, there are three alarm types.
Page 176 activation, snapshot, channel record. The stay time here does not include the latch time. During the alarm process, the alarm signal can begin an anti-dither time if system detects the local alarm again. The screen prompt, alarm upload, email and etc will not be activated.
Page 177 Please highlight icon to select the corresponding function. After setting all the setups please click save button, system goes back to the previous menu. Figure 4-134 Figure 4-135...
Page 178 Figure 4-136 Figure 4-137...
Page 179 Figure 4-138 Figure 4-139...
Page 180 Figure 4-140 Figure 4-141 4.11.3.5 Abnormality There are four types: HDD/Network/User/Device. Please note device interface is for some series only.  HDD: HDD error, no disk, no space. See Figure 4-142 and Figure 4-143.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-144. ...
Page 181 Less than: System can alarm you when the HDD space is less than the threshold you set here (For HDD no space type only). Latch: Here you can set corresponding delaying time. The value ranges from 0s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.
Page 182 Figure 4-142 Figure 4-143...
Page 183 Figure 4-144 Figure 4-145...
Page 184 Figure 4-146 4.11.3.6 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-147.
Page 185: Storage
4.11.4 Storage 4.11.4.1 Schedule 4.11.4.1.1 Record Note: You need to have proper rights to implement the following operations. Please make sure the HDDs have been properly installed. After the system booted up, it is in default 24-hour regular mode. You can set record type and time in schedule interface.
Page 186 Figure 4-149  Please draw manually to set record period. There are six periods in one day. See Figure 4-150. Figure 4-150 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference.
Page 187 Figure 4-151 Figure 4-152 4.11.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-153. You can see current channel name is grey such as channel 1. Now you can select the channel you want to paste such as channel 5/6/7.
Page 188 Figure 4-153 4.11.4.1.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety. In the main menu, from Setting->Storage->...
Page 189 In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-155. In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See interface on the right of Figure 4-156. Please refer to the following figure for detailed information. Figure 4-154...
Page 190 Figure 4-155 Figure 4-156 4.11.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred. In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
Page 191 Figure 4-157 Figure 4-158...
Page 192 Figure 4-159 4.11.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when an alarm occurs, and otherwise system just operates the schedule snapshot.
Page 193 Please input corresponding information here, if you just upload the image FTP. Figure 4-160 4.11.4.2 HDD Manager Here is for you to view and implement hard disk management. See Figure 4-161. You can see current HDD type, status, capacity and etc. The operation includes format HDD, and change HDD property (read and write/read-only/redundancy).
Page 194 Figure 4-161 4.11.4.3 Record 4.11.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. Right click mouse and then select Manual->Record....
Page 195 Figure 4-162 4.11.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-163. Figure 4-163 Tips You can check All button after the corresponding status to enable/disable all-channel...
Page 196 snapshot function. 4.11.4.4 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD. There are two detect types: Quick detect is to detect via the universal system files. System can quickly complete the HDD scan.
Page 197 Figure 4-165 4.11.4.4.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-166. Figure 4-166...
Page 198: System
Click the item you can see the detailed information such as detect result. See Figure 4- 167. Figure 4-167 4.11.5 System 4.11.5.1 General 4.11.5.1.1 Device General setting includes the following items. See Figure 4-168. Device ID: Please input a corresponding device name here. Device No: Here you can set device number....
Page 199 Auto logout: Here is for you to set auto logout interval once login user remains inactive for a specified time. Value ranges from 0 to 60 minutes. IPC Time Sync: You can input an interval here to synchronize the DVR time and IPC time....
Page 200 Figure 4-169 4.11.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-170. Click Add new holiday button, you can input new holiday information. See Figure 4-171. Here you can set holiday name, repeat mode and start/end time. Note When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
Page 201 Figure 4-170 Figure 4-171 4.11.5.2 Display 4.11.5.2.1 Display Display setup interface is shown as below. See Figure 4-172. Time display: You can select to display time or not when system is playback. Channel display: You can select to channel name or not when system is playback....
Page 202 Image original rate: Check the box here, the video can be displayed at its actual size. Transparency: Here is for you to adjust menu transparency. The higher the value is, the more transparent the menu is.  Resolution: There are four options: 1920×1080, 1280×1024(default),1280× 720,1024×768.
Page 203 Figure 4-173 4.11.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-174 Enable tour: Highlight box here to enable this function. Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
Page 204  On the navigation bar, click to enable/disable tour function.   Figure 4-174 4.11.5.2.4 Zero-channel Encoding Click zero-channel encoding button, you can go to the following interface. See Figure 4-175. Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel.
Page 205 the Web and you can select zero-channel encoding mode at the right corner of the interface . Select a mode; you can view the local preview video. Figure 4-175 4.11.5.3 Video Matrix Here you can set matrix output channel and its interval. You can set HDMI2 port tour and its interval See Figure 4-176.
Page 206 Move down: Click it to move current selected channel down. Default: Click it to restore default setup. Figure 4-176 Figure 4-177...
Page 207 Figure 4-178 4.11.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-179. Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboard is for you to control the device via the special keyboard.
Page 208 Figure 4-179 4.11.5.5 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-180. PTZ type: There are two options: local/remote. Please select remote if you are connecting to the network PTZ. Control mode: You can select control mode from the dropdown list. There are two options: Serial/5-WAY .
Page 209 Figure 4-180 For digital channel, the interface is shown as below. See Figure 4-181. Figure 4-181 4.11.5.6 ATM/POS...
Page 210 The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.11.5.6.1 COM Type The COM interface is shown as below. See Figure 4-182. Protocol: Please select from the dropdown list. Setting: Click COM setting button, the interface is shown as in RS232 interface.
Page 211 Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file. You can view the corresponding information when playback. Overlay Position: Here you can select the proper overlay position from the dropdown list....
Page 212 Figure 4-184 4.11.5.7 Voice The audio function is to manage audio files and set schedule play function. It is to realize audio broadcast activation function. 4.11.5.7.1 File List Here you can add audio file, listen to the audio file, or rename/delete audio file. Here you can also set audio volume.
Page 213 Figure 4-186 The audio file can be saved on the HDD or on the USB device. In Figure 4-185, when it is HDD mode, the newly added audio file can be saved on the HDD automatically. You do not need to connect to the USB device if you want to use it the next time....
Page 214 The default user amount is 64 and the default group amount is 20. System account adopts two-level management: group and user. For group or user management, there are two levels: admin and user.  The user name and group name can consist of eight bytes. One name can only be used once.
Page 215 Click modify user button in Figure 4-187 , the interface is shown as in Figure 4-188. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
Page 216 Figure 4-189 Click Set button, you can set six periods in one day. See Figure 4-190. Check the box after the period, you can enable current setup. Figure 4-190...
Page 217 4.11.5.8.2 Modify user Click , you can go to the following interface to change user information. See Figure 4-191. For admin, 888888, and default (hidden user), you can not change period setup. Figure 4-191 4.11.5.8.3 Change Password In Figure 4-191, check the Modify password box, you can change password. Please input old password, and then input new password twice to confirm.
Page 218 Figure 4-192 Click add group button in Figure 4-192 , the interface is shown as below. See Figure 4- 193. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
Page 219 Figure 4-193 4.11.5.8.5 Security Question The security question is shown as below. See Figure 4-194. Here you can change security questions. Figure 4-194...
Page 220 4.11.5.9 Auto Maintain Here you can set auto-reboot time and auto-delete old files setup. You can set to delete the files for the specified days. See Figure 4-195. You can select proper setup from dropdown list. After all the setups please click save button, system goes back to the previous menu. Figure 4-195 4.11.5.10 Config Backup The configuration file backup interface is shown as below.
Page 221 System can not open config backup interface again if there is backup operation in the process. System refreshes device when you go to the config backup every time and set current directory as the root directory of the peripheral device. If you go to the configuration backup interface first and then insert the peripheral device, please click Refresh button to view the newly added device....
Page 222 Figure 4-197 4.11.5.12 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-198. Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update....
Page 223 Figure 4-198...
Page 224: Web Operation
5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items: Network connection is right DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network)...
Page 225 Figure 5-2 System pops up the following dialogue box for you to change default administrator password. See Figure 5-3. Figure 5-3 For you own safety, please change the default password after you first login. Click Cancel button, system pops up the following dialogue box to confirm the exit. See Figure 5-4.
Page 226: Lan Mode
Figure 5-4 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-5. Figure 5-5 This main window can be divided into the following sections. Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11),face search (chapter 5.11) and logout (chapter 0)....
Page 227 Figure 5-6 Please refer to Figure 5-7 for main stream and extra stream switch information. Figure 5-7 Section 3: Start dialogue button. You can click this button to enable audio talk. Click 【▼】to select bidirectional talk mode. There are four options: DEFAULT，G711a，G711u and PCM. After you enable the bidirectional talk, the Start talk button becomes End Talk button and it becomes yellow.
Page 228: Real-Time Monitor
Figure 5-10 Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority. Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. Section 8: Image setup and alarm setup.
Page 229: Fisheye De-Warp
1 2 3 4 Figure 5-12 1: Fisheye: Click to adjust fisheye installation mode and display mode. See Figure 5-13. Please note this function is for some series only. 2: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status....
Page 230 1 de-warp window+1 panorama stretching （Ground mount） 2 panorama stretching view 360° panorama view+3 de-warp windows 360°panorama view+4 de-warp windows de-warp windows+1 panorama stretching 360° panorama view+8 de-warp windows 360°panorama original view （Wall mount） Panorama stretching 1 panorama unfolding view+3 de-warp windows 1 panorama unfolding view +4 de warp windows...
Page 231: Ptz
5.5 PTZ Before PTZ operation, please make sure you have properly set PTZ protocol. (Please refer to chapter 5.8.5.5). There are eight direction keys. In the middle of the eight direction keys, there is a 3D intelligent positioning key. Click 3D intelligent positioning key, system goes back to the single screen mode. Drag the mouse in the screen to adjust section size.
Page 232: Image/Relay-Out
3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-15 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-16. 5.6.1 Image Here you can adjust its brightness, contrast, hue and saturation.
Page 233: Wan Login
5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-18. Figure 5-18 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.
Page 234: Setup
For bandwidth consideration, system can not support monitor and playback at the same time. System auto closes monitor or playback interface when you are searching setup in the configuration interface. It is to enhance search speed. 5.8 Setup 5.8.1 Camera 5.8.1.1 Remote Device (For digital channel only) Remote device interface is shown as below.
Page 235 Note:  System supports manufactures such as Panasonic, Sony, Dynacolor, Samsung, AXIS, Arecont, Optiview and Onvif standard protocol.  If you do not input IP address here. System uses default IP 192.168.0.0 and system does not connect to this IP.
Page 236 Figure 5-21 The digital channel is shown as in Figure 5-22. Figure 5-22 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. It is to set the cable type of the corresponding analog channel. Cable type When the setup here matches the actual cable you are using, you can get the best image effect.
Page 237 Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level. The default value is 50. The bigger the value is, the large the contrast between the bright and dark section is and vice versa.
Page 238 Figure 5-23 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. SVC is so called scaled video coding. Check the box to enable this function. During the network transmission process, system discards unimportant frames when the bandwidth is sufficient or the decode capability is low.
Page 239 non-important surveillance object to save the storage space. Compression: System supports H.264H, H.264, H.264B, and Compression MJPEG.  H.264H: It is the High Profile compression algorithm. It has the high encode compression rate. It can achieve high quality encode at low bit stream. Usually we recommend this type.
Page 240 Figure 5-24 Please refer to the following sheet for detailed information. Parameter Function There are two modes: Regular (schedule) and Trigger. Snapshot type  Regular snapshot is valid during the specified period you set.  Trigger snapshot only is valid when motion detect alarm, alarm or local activation alarm occurs.
Page 241 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video. System max supports 4 privacy mask zones. Time Title You can enable this function so that system overlays time information in video window.
Page 242 Figure 5-27 5.8.1.5 Channel Type It is to set channel type. For analog channel (CVBS signal or 5-WAY HD signal), you can select coaxial cable or UTP cable. Please check first and then save setup. There is no need to reboot....
Page 243 Figure 5-28 Figure 5-29 Important Add/cancel IP CAM function is for some series product only. Add IP CAM: Click it; you can add corresponding X IP channels. Here X refers to the product channel amount. Please refer to chapter 1.3 Specifications for IP channel amount information.
Page 244: Network
For example, there is a 4-channel analog device, after the A/D switch, it can max supports 4 analog channels and 4 IP channels. Once it has become the 3+1 mode (3 analog channels+1 IP channel), you click button, system becomes 3+5 mode (3 analog channels+5 IP channel).
Page 245 Figure 5-31 Please refer to the following sheet for detailed information. Parameter Function Mode There are two modes: static mode and the DHCP mode.  The IP/submask/gateway are null when you select the DHCP mode to auto search the IP. ...
Page 246 Figure 5-32 Please refer to the following sheet for detailed information. Parameter Function Max connection It is the max Web connection for the same device. The value ranges from 1 to 120. The default setup is 120. TCP port The default value is 37777. You can input the actual port number if necessary.
Page 247 Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list. Double click a name to connect to it. Click Refresh button, you can view latest connection status. 5.8.2.4 3G 5.8.2.4.1 CDMA/GPRS The CDMA/GPRS interface is shown as in Figure 5-34.
Page 248 Figure 5-35 5.8.2.5 PPPoE The PPPoE interface is shown as in Figure 5-36. Input the PPPoE user name and password you get from the IPS (internet service provider) and enable PPPoE function. Please save current setup and then reboot the device to get the setup activated.
Page 249 Figure 5-37 Please refer to the following sheet for detailed information. Parameter Function Server Type You can select DDNS protocol from the dropdown list and then enable DDNS function. Server IP DDNS server IP address Server Port DDNS server port. Domain Name Your self-defined domain name.
Page 250 Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. User name: It is optional. You can input your commonly used email address. Important Do not register frequently.
Page 251 Figure 5-39 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function.
Page 252 Parameter Function Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not. (interval) Please check the box to enable this function and then set the corresponding interval.
Page 253 Figure 5-41 5.8.2.11 SNMP The SNMP interface is shown as in Figure 5-42. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-42 Please refer to the following sheet for detailed information.
Page 254 Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
Page 255 5.8.2.14 Alarm Centre The alarm center interface is shown as below. See Figure 5-45. This interface is reserved for you to develop. System can upload alarm signal to the alarm center when local alarm occurs. Before you use alarm center, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
Page 256 You need to download root certificate if it is your first time to use HTTPS on current PC. Figure 5-47 5.8.2.16.1 Create Server Certificate If it is your first time to use this function, please follow the steps listed below. In Figure 5-47, button, input country name, state name and etc.
Page 257 Figure 5-50 Click Open button, you can go to the following interface. See Figure 5-51. Figure 5-51 Click Install certificate button, you can go to certificate wizard. See Figure 5-52.
Page 258 Figure 5-52 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-53. Figure 5-53 Click Next button, you can see the certificate import process is complete. See Figure 5-54.
Page 259 Figure 5-54 Click Finish button, you can see system pops up a security warning dialogue box. Figure 5-55. Figure 5-55 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-56. Figure 5-56 5.8.2.16.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface.
Page 260: Event
You can see HTTPS default value is 443. Figure 5-57 5.8.2.16.4 Login Open the browser and then input https://xx.xx.xx.xx:port. xx.xx.xx.xx: is your device IP or domain mane. Port is your HTTPS port. If you are using default HTTPS value 443, you do not need to add port information here.
Page 261 Figure 5-58 Figure 5-59...
Page 262 Figure 5-60 Figure 5-61 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list. Motion detection function becomes activated in the specified Period periods.
Page 263 Parameter Function System only memorizes one event during the anti-dither period. Anti-dither The value ranges from 5s to 600s. There are six levels. The sixth level has the highest sensitivity. Sensitivity Region If you select motion detection type, you can click this button to set motion detection zone.
Page 264 Tour You need to check the box here to enable this function. System begins 1-wiindow or multiple-window tour display among the channel(s) you set to record when an alarm occurs. Here you can set PTZ movement when an alarm occurs. Such as go to preset X.
Page 265 Figure 5-63 5.8.3.1.4 Diagnosis System can trigger an alarm when the stripe, noise, color cast, out of focus, o ver exposure event occurred. See Figure 5-64. Figure 5-64 Click Set button, you can check the corresponding box to select diagnosis type. See Figure 5-65.
Page 266 Figure 5-65 Note Video diagnosis alarm can trigger PTZ preset, tour, and pattern. For detailed setups, please refer to chapter 5.8.3.1.1 motion detect for detailed information. 5.8.3.2 Intelligence (Optional) Important The intelligence function is optional. The different series products support different IVS functions. Please refer to your purchased product actual interface for detailed information....
Page 267 Figure 5-66 5.8.3.2.1 Tripwire Note: The tripwire function is valid once your network camera or your DVR supports this function. If your purchased DVR supports the tripwire function, it supports one analog channel. It is not for the digital channel. From main menu->Setup->Event->IVS->Tripwire, you can see the following interface.
Page 268 Figure 5-67 Check the Tripwire box to enable tripwire function. Select SN (Line1/2/3/4) and direction, and then input customized rule name. No. and Line1/2/3/4: System supports four tripwires. Each SN stands for one tripwire. Direction: There are three options: A->B, B->A, both. System can generate an alarm once there is any object crossing in the specified direction....
Page 269 Click to draw filter object. See Figure 5-69. Figure 5-69 Select the blue line and then use mouse to adjust zone size. Note Each rule can set two sizes (min size/max size). Once the object is smaller than the min size or larger than the max size, there is no alarm.
Page 270 Figure 5-70 Check the Intrusion box to enable intrusion function. Select SN (Area1/2/3/4) and direction, and then input customized rule name. No. and Area1/2/3/4: System supports four zones. Each SN stands for one zone. Direction: There are three options: A->B, B->A, both. System can generate an alarm once there is any object enter/exit (Or both) the zone....
Page 271 Figure 5-71 For detailed setups, please refer to chapter 5.8.3.1.1 motion detect for detailed information. 5.8.3.2.3 Object Detect Note: The object detection function is valid once your network camera or your DVR supports this function. If your purchased DVR supports the object detection function, it supports one analog channel.
Page 272 Figure 5-72 Check the Object box to enable object detect function. Select SN (object1/2/3/4) and rule type, and then input customized rule name. No. and Object1/2/3/4: System supports four zones. Each SN stands for one zone. Rule type: Please select from the dropdown list. There are two types: Missing object detect/abandoned object detect....
Page 273 Figure 5-73 Now you can draw a rule. Left click mouse to draw a line, until you draw a rectangle, you can right click mouse. Click Ok to complete the rule setup. For detailed setups, please refer to chapter 5.8.3.1.1 motion detect for detailed information.
Page 274 Figure 5-74 5.8.3.4 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.4.1 Local Alarm The local alarm interface is shown as in Figure 5-75. It refers to alarm from the local device.
Page 275 Figure 5-75 Figure 5-76...
Page 276 Figure 5-77 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
Page 277 Parameter Function Buzzer Check the box here to enable this function. The buzzer beeps when an alarm occurs. System can upload the alarm signal to the center Alarm upload (Including alarm center). Send Email If you enabled this function, System can send out an email to alert you when an alarm occurs.
Page 278 please refer to chapter 5.8.3.4.1. Figure 5-79 5.8.3.4.4 IPC Offline Alarm IPC offline alarm is shown as in Figure 5-80. For setup information, please refer to chapter 5.8.3.4.1. Figure 5-80...
Page 279 5.8.3.5 Abnormality It includes four types: HDD/Network/User/Device. See Figure 5-81 through Figure 5-84. HDD includes: No disk, disk error, disk no space. Network includes net disconnection, IP conflict, and MAC conflict. User: It includes illegal login. Device: It includes device temperature alarm, fan alarm and etc. Figure 5-81 Figure 5-82...
Page 280 Figure 5-83 Figure 5-84 Please refer to the following sheet for detailed information.
Page 281 Parameter Function Event Type The abnormal events include: No disk, disk error, disk no space, net disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
Page 282: Storage
Figure 5-85 5.8.4 Storage 5.8.4.1 Schedule 5.8.4.1.1 Schedule Record In this interfaces, you can add or remove the schedule record setup. See Figure 5-86. There are three record modes: general (auto), motion detect and alarm. There are six periods in one day. You can view the current time period setup from the color bar.
Page 283 Figure 5-86 Figure 5-87 Figure 5-88 Please refer to the following sheet for detailed information.
Page 284 Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD. Snapshot Check the box here to enable snapshot function.
Page 285 The interface is shown as in Figure 5-90. Here you can see HDD information. You can also operate the read-only, read-write, redundancy (if there are more than on HDD) and format operation. Figure 5-90 5.8.4.3 Manual Record The interface is shown as in Figure 5-91. Figure 5-91 Please refer to the following sheet for detailed information.
Page 286: Setting
It has the highest priority. Manual Enable corresponding channel to record no matter what period applied in the record setup. Stop current channel record no matter what period applied in the Stop record setup. Check the corresponding All button, you can enable or disable all Start all/ stop all channels record.
Page 287 Here is for you to select working mode when hard disk is full. There HDD full are two options: stop recording or rewrite. If current working HDD is overwritten or the current HDD is full while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files.
Page 288 Here you can set day night save time begin time and end time. You can set according to the date format or according to the week format. You can check the box to enable NTP function. You can set the time server address. NTP server It is to set the time server port.
Page 289 Please refer to the following sheet for detailed information. Parameter Function There are four options: 1920×1080,1280 × 1024(default),1280 × Resolution 720,1024×768. Please note the system needs to reboot to activate current setup. Transparency Here is for you to adjust transparency. The value ranges from 128 to 255.
Page 290 Figure 5-97 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function. Enable tour Here is for you to adjust transparency. The value ranges from 5 to Interval 120s. The default setup is 5s. Here you can set window mode and channel group.
Page 291 Figure 5-98 Please refer to the following sheet for detailed information. Parameter Function This function is disabled by default. Check the box here to enable Enable this function so that you can control the zero-channel encoding function at the WEB. Compression System default setup is H.264.
Page 292 Figure 5-99 Please refer to the following sheet for detailed information. Parameter Function Enable Check the box here to enable this function. Interval It is to set the interval from current channel group to the next channel group. Window split Support 1-window split only.
Page 293 Select a channel group and then click ,you can delete it. Modify channel group Select a channel group and then double click, you can see the following interface. See Figure 5-101. You can change the setup and then click OK button. Figure 5-101 Adjust channel group sequence.
Page 294 Parameter Function Default setup is none. 5.8.5.5 PTZ The PTZ interface is shown as in Figure 5-103 and Figure 5-104. Before setup, please check the following connections are right: PTZ and decoder connection is right. Decoder address setup is right. Decoder A (B) line connects with DVR A (B) line....
Page 295 Parameter Function You can select control mode from the dropdown list. There are two Control mode options: Serial/5-WAY . For 5-WAY series product, please select 5- WAY . The control signal is sent to the PTZ via the coaxial cable. For the serial mode, the control signal is sent to the PTZ via the RS485 port.
Page 296 Figure 5-105 5.8.5.6.2 Network Type The network type interface is shown as below. See Figure 5-106. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
Page 297 For the ATM/POS without the protocol, the interface is shown as in Figure 5-107. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 298 Figure 5-109 5.8.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. From main menu->Setup->System->Voice->.Schedule, you can see the following interface. See Figure 5-110. Figure 5-110 Please refer to the following sheet for detailed information. Parameter Function There are six periods.
Page 299 Parameter Function There are two options: MIC (default)/audio. When reuse the MIC port Output port and bidirectional talk port, the bidirectional port has the higher priority. Please note some series product does not support audio function. Note The audio file end time depends on the audio file size and the interval setup. Priority: Bidirectional talk>Event trigger alarm>Trial listening>Audio schedule broadcast....
Page 300 Here you can input the user name and password and then select one group for current user. Please note the user rights shall not exceed the group right setup. For convenient setup, please make sure the general user has the lower rights setup than the admin.
Page 301 Figure 5-113 5.8.5.8.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-114. Figure 5-114 Add group: It is to add group and set its corresponding rights. See Figure 5-115. Please input the group name and then check the box to select the corresponding rights.
Page 302 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-115 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-116. Here you can modify group information such as remarks and rights. Figure 5-116...
Page 303 5.8.5.9 Auto maintain The auto maintain interface is shown as in Figure 5-117. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.
Page 304: Information
Figure 5-119 5.8.5.12 Upgrade The upgrade interface is shown as in Figure 5-120. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.
Page 305: Log
5.9.2 Log Here you can view system log. See Figure 5-122. Figure 5-122 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear.
Page 306: Online User
5.9.3 Online User The online user interface is shown as in Figure 5-123. Figure 5-123 5.9.4 HDD The HDD interface is shown as in Figure 5-124. Here you can view HDD information. Figure 5-124 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-125.
Page 307: Search Record
Figure 5-125 5.10.1 Search Record Please set record type, record date, window display mode and channel name. Select Date You can click the date on the right pane to select the date. The green highlighted date is system current date and the blue highlighted date means it has record files. Window Split...
Page 308: File List
Figure 5-127 Now you can select one or more channel(s) and then click to search record(s). System supports one or more channels. The window split mode can auto adjust according to the channel amount. System max supports 16-split. Click button to select all channels at the same time.
Page 309: Playback
Figure 5-129 5.10.4 Playback Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not playback and download at the same time. You can use the playback control bar to implement various operations such as play, pause, stop, slow play, fast play and etc.
Page 310: Load More
Figure 5-130 5.10.6 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. Or you can use watermark function to verify file. 5.10.6.1 Download By File Select channel, record type, bit stream type and then input start time and end time. Click Search button, the download by file interface is shown as in Figure 5-131.
Page 311 Check the file(s) you want to download and there are two options for you to save the file(s). Download to local Click Download to local, system pops up the following interface for you to set record format and saved path. See Figure 5-132. Figure 5-132 You can click OK to download and view the download process.
Page 312: Face Search
Figure 5-134 Set record format and saved path, you can click OK to download and view the download process. After the download operation, you can see corresponding dialog box. 5.10.6.3 Watermark Watermark interface is shown as In Figure 5-135. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-135 5.11 Face Search...
Page 313: Alarm
Figure 5-136 Please refer to the following sheet for detailed information. Name Function Display It is to display human face detection file list. The latest file is at the  top. \ Click Export, you can export the selected file to the USB device. ...
Page 314: Log Out
Figure 5-137 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.
Page 315: Un-Install Web Control
Figure 5-138 5.14 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.
Page 316: Professional Surveillance System
6 Professional Surveillance System Besides Web, you can use our Smart PSS to login the device. For detailed information, please refer to Smart PSS user’s manual.
Page 317: Faq
7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
Page 318  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
Page 319  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
Page 320  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
Page 321  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
Page 322 There are following possibilities:  Check the camera is online or not.  Check IP channel setup is right or not (such as IP address, user name, password, connection protocol, port number.).  The camera has set the whitelist (Only the specified devices can connect to the camera).
Page 323  Check DNS setup is right or not. Default Google DNS server is 8.8.8.8, 8.8.5.5. You can use different DNS provided by your ISP. 34. I can not use the P2P function on my cell phone or the WEB. There are following possibilities: ...
Page 324 Please use the brush to clean the board, socket connector and the chassis regularly. The device shall be soundly earthed in case there is audio/video disturbance. Keep the device away from the static voltage or induced voltage. Please unplug the power cable before you remove the audio/video signal cable, RS232 or RS485 cable....
Page 325: Appendix A Hdd Capacity Calculation
Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
Page 326 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...
Page 327: Appendix B Compatible Backup Devices
Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...
Page 328: Appendix B-2 Compatible Sd Card List
Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...
Page 329 Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
Page 330 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
Page 331 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
Page 332 HitachiCinemaStar™ Hitachi HCP725050GLA380 500G SATA 5K500 HitachiCinemaStar™ Hitachi HCT721050SLA360 500G SATA 7K1000.B HitachiCinemaStar™ Hitachi HCT721075SLA360 750G SATA 7K1000.B HitachiCinemaStar™ Hitachi HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
Page 333 Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...
Page 334: Appendix D Compatible Displayer List
Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...
Page 335: Appendix E Compatible Switcher
Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...
Page 336: Appendix F Compatible Wireless Mouse List
Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...
Page 337: Appendix G Earthing
Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
Page 338 Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
Page 339 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
Page 340 The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2. The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable....
Page 341 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.
Page 342 Note: This manual is for reference only. Slight difference may be found in the user interface. All the designs and software here are subject to change without prior written notice. All trademarks and registered trademarks mentioned are the properties of their respective owners....

This manual is also suitable for:

Hdvr8/161080-q2 Hdvr32-q4 Hdvr32-q8 Hdvr161080-q8 Hdvr161080-q4

Optiview HDVR4/8/16-Q2 User Manual

1 Features and Specifications

2 Overview and Controls

3 Installation and Connections

4 Overview of Navigation and Controls

5 Web Operation

6 Professional Surveillance System

7 Faq

Appendix A Hdd Capacity Calculation

Appendix

Appendix B Compatible Backup Devices

Appendix B-2 Compatible SD Card List

Appendix D Compatible Displayer List

Appendix E Compatible Switcher

Appendix F Compatible Wireless Mouse List

Appendix G Earthing

Quick Links

Need help?

Questions and answers

Related Manuals for Optiview HDVR4/8/16-Q2

Summary of Contents for Optiview HDVR4/8/16-Q2

This manual is also suitable for:

Table of Contents
