Optiview VR4HT User Manual page 42

Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
9
10
11
12
2.2.2.3 8-ch 2CIF Real-time Series
This series DVR rear panel is shown as below. See Figure 2-13.
Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
9
10
11
12
Video input
Audio input
Audio output
Video output
USB port
HDMI port
Network port
Power socket
Alarm input/alarm output/RS485 port
Video VGA output
RS232 port
GND port
Video input
Audio input
Audio output
Video output
Video VGA output
HDMI port
RS232 port
USB port
Network port
Alarm input/alarm output/RS485 port
Power socket
On/off button
Figure 2-12
Figure 2-13
32
