Optiview DVRJ4 User Manual

4-ch standalone network dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DVRJ4
4-ch Standalone Network DVR
User's Manual
Rel.061207

Advertisement

Table of Contents
loading

Related Manuals for Optiview DVRJ4

Summary of Contents for Optiview DVRJ4

  • Page 1 DVRJ4 4-ch Standalone Network DVR User’s Manual Rel.061207...

  • Page 2: Table Of Contents

    2.8. Remote controller 3. Various display mode 3.1. QUAD mode 3.2. PIP mode 3.3. FULL screen mode 3.4. AUTO rotation mode 3.5. TRIPLEX mode 4. DVR installation and operation 4.1. Recording 4.2. Playback 4.3. Searching 4.4. Zooming 4.5. Freezing 4.6. USB backup 4.7.
  • Page 3 User’s manual Before operating This User‟s manual is explanation of DVRJ4 installation and operation. If you are not familiar with DVR, please contact professional technicians for installation and operation. Please read thoroughly before you operate the unit for your safety.

  • Page 4: Product Introduction

    DVRJ4 1. Product Introduction DVRJ4 supports full triplex (recording / playback / backup) and GUI for setup. 1.1. System Specification Storage Compression M-JPEG (Modified JPEG) Video input 4 (NTSC/PAL) channel Recording resolution 704 x 240(288), 352 x 240(288) Recording speed...
  • Page 5 DVRJ4 Backup Firmware update Network viewer Backup through network AVI file backup Watermark USB memory stick, USB 2.0 Can be viewed by WINDOWS via USB stick Setup, Search, Backup User’s manual...

  • Page 6: Product Operation

    When you try to update the system through USB stick, save the firmware after you change the name to „update.bin‟. And put it in the DVR USB port, and get in „USB SETUP MENU‟ of the DVR menu to select “FIRMWARE UPDATE‟.

  • Page 7: Front Panel And Buttons

    - REC : It gets on when images are recorded. ① - PLAY BACK : It lights when recorded data are played back. - NETWORK : DVR is accessed by client program, then it gets on. - BACKUP : If backup is being done, it gets on. QUAD - You can use this when you want to view 4 cameras at the same time.
  • Page 8 - EVENT search - TIME search PLAY-BACK - You can view the recorded data from the hard drive of the DVR. If you press this button ⑩ without any other action, the latest recorded data will be played back. - You can record images manually with this button. If you press it one more time, recording ⑪...

  • Page 9: Back Panel Connection

    DVRJ4 2.7. Back panel connection ① Items VIDEO INPUT ① (1~4 CHANNEL) MONITOR ② AUDIO INPUT / ③ OUTPUT ETHERNET ④ AUDIO IN ETHERNET AUDIO OUT ② ③ ④ Details 4 composite video inputs with BNC jack. For monitor, CCTV monitor Supports line level audio in/out which uses RCA mono type connector.
  • Page 10 DVRJ4 Items ALARM/PTZ ⑤ POWER ⑥ Details - Alarm input (AL IN) Supports 4 alarm inputs. - Alarm output (AL OUT) Supports 1 output and out internal buzzer. If alarm goes off, you can press „ENTER‟ on the front panel to reset the alarm status. Maximum volt is +5V.

  • Page 11: Remote Controller

    DVRJ4 2.8. Remote controller Backup button Full screen button 4channel split button Zoom button Menu button Auto rotation button Setting button Button lock key LOCK Recording button QUAD FULL PIP button FREEZE ZOOM Pause button SEARCH Search button Triplex mode button...
  • Page 12 DVRJ4 3. Various display mod 3.1. QUAD mode 2006/1/1 12:12:23 MON CAMERA 1 CAMERA 2 CAMERA 3 CAMERA 4 3.2. PIP mode 2006/1/1 12:12:23 MON CAMERA 1 CAMERA 2 PIP mode 1 Current time Camera names 2006/1/1 12:12:23 MON CAMERA 2...

  • Page 13: Auto Mode

    DVRJ4 3.3. FULL mode 2006/1/1 12:12:23 MON CAMERA 1 3.4. AUTO mode 2006/1/1 12:12:23 MON 2006/1/1 12:12:23 MON 2006/1/1 12:12:23 MON 2006/1/1 12:12:23 MON CAMERA 1 CAMERA 1 CAMERA 1 CAMERA 4 If you press FULL mode for the proper channel, you can view it on a full screen.

  • Page 14: Triplex Mode

    Connect the supplied DC 12V power adapter (※ Make sure to use the supplied power adapter.) Power is automatically provided, and DVR system gets defaulted and it turns into live mode in a couple of seconds. Live and playback images are displayed together on a screen.
  • Page 15 System beginning Images are being displayed and the system is being defaulted. During this process graph is being displayed. During default process, DVR checks the system and the hard drive, and gets defaulted. System default takes about 10 seconds. You can change the setting if you want even during system operation or recording.
  • Page 16 DVRJ4 4.2. Playback ▶ 2006/1/1 12:12:23 PB CAMERA 1 PB CAMERA 2 PB CAMERA 3 PB CAMERA 4 During playback, you can view various modes of FULL/QUAD/PIP etc. 4.3. Searching Manual recording searching SEARCH MODE RECORD START/STOP SEARCH EVENT LIST SEARCH...
  • Page 17 DVRJ4 Event recording Search by motion/alarm/network searching SEARCH MODE RECORD START/STOP SEARCH EVENT LIST SEARCH TIME/DATE SEARCH Time/date searching SEARCH MODE RECORD START/STOP SEARCH EVENT LIST SEARCH TIME/DATE SEARCH EVENT SEARCH MASTER START TIME MOTION 2006/1/1 06:32:12 MOTION 2006/1/11 13:31:00...
  • Page 18 DVRJ4 4.4. Zooming 2006/1/1 12:12:23 CAMERA 1 CAMERA 2 CAMERA 3 CAMERA 4 4.5. Freezing 2006/1/1 12:12:23 CAMERA 1 CAMERA 2 CAMERA 4 CAMERA 3 It means the current status is “zoom”. This is zoom window. You can press top/bottom/left/right to move to where you want to zoom.

  • Page 19: Usb Backup

    BACKUP button. Then DVR saves that data to USB devices. In addition, if you press the button very quickly, DVR will save that frame. If you press the button for 3 seconds, DVR will save the images. You can press the button one more time to quit. During this process, USB icon is shown on the screen.

  • Page 20: Setup Menu

    DVRJ4 5. Menu 5.1. Setup menu On live monitoring mode, if you press MENU/EXIT button, you can see the main menu on the left. For motion and alarm ※ Under the main menu, if you press MENU/EXIT button, you can get out to SETUP menu.

  • Page 21: System Menu

    DVRJ4 5.2. System menu Time/date, hard drive formatting, auto rotation, system default, video signal selection, buzzer setting, password setting, language setting. Time/date SYSTEM SETUP O TIME/DATE SET O HDD FORMAT SET O FACTORY RESET O AUTO SEQUENCE SET O PLAY REPEAT...
  • Page 22 DVRJ4 Hard drive format SYSTEM SETUP O TIME/DATE SET O HDD FORMAT SET O FACTORY RESET O AUTO SEQUENCE SET O PLAY REPEAT : YES O VIDEO SOURCE : NTSC O BUZZER SOUND : OFF O PASSWORD ENA : ON...
  • Page 23 DVRJ4 Auto rotation SYSTEM SETUP O TIME/DATE SET O HDD FORMAT SET O FACTORY RESET O AUTO SEQUENCE SET O PLAY REPEAT : YES O VIDEO SOURCE : NTSC O BUZZER SOUND : OFF O PASSWORD ENA : ON O SELECT LANG...
  • Page 24 DVRJ4 Password setting SYSTEM SETUP O TIME/DATE SET O HDD FORMAT SET O FACTORY RESET O AUTO SEQUENCE SET O PLAY REPEAT : YES O VIDEO SOURCE : NTSC O BUZZER SOUND : OFF O PASSWORD ENA : ON O SELECT LANG...

  • Page 25: Video Menu

    DVRJ4 5.3. Video menu This is to set the basic environmental of live monitoring mode such as channel names, brightness, contrast etc. In addition, boarder lines of channels, color of no video channel is set. If you select VIDEO SETUP, you can see the menu on the right side.
  • Page 26 DVRJ4 Brightness/Contrast VIDEO SETUP O NAME SET O BRI/CON SET O BOUNDARY : WHITE O BACK GROUND : BLUE Color of boarder lines (boundary) and back ground VIDEO SETUP O NAME SET O BRI/CON SET O BOUNDARY : WHITE O BACK GROUND : BLUE BRIGHTNESS &...

  • Page 27: Recording Menu

    „MULTIPLEX‟. In other words, if you want to record 120ips, then set as „CIF „. If you press yes, DVR will over write the data on hard drive. The oldest data will be erased first. Normally „15Fld/1SEC‟ lasts about one week with 80GB.

  • Page 28: Network Menu

    DVRJ4 5.5. Network menu This is menu to set network environmental. You need to set the network environment. first if you need to control various function of the DVR and do remote monitoring and remote management. Network setting You can use arrow buttons to adjust.

  • Page 29: Sensor / Motion Menu

    DVRJ4 5.6. Sensor / Motion menu This is to set sensor input, alarm, and motion setting. This DVR supports 4channel sensor inputs, 1 channel alarm output (relay output). And it can set motion recording on each channel. You can record the images as it is set.

  • Page 30: Backup Menu

    DVRJ4 5.7. Backup menu This is for USB backup. This DVR supports a variety of USB thumb drives. You can also use USB drive for firmware upgrade. USB backup setting You can use arrow buttons to adjust. USB BACKUP SETUP...

  • Page 31: Schedule Recording Menu

    DVRJ4 5.8. Schedule recording menu You can schedule the recording for a week. Schedule recording setting You can use arrow buttons to select day / time and press „ENTER‟ to finish. After that, you can do other days. SCHEDULE SETUP...

  • Page 32: Network Client Software

    DVRJ4 6. Network client software 6.1. How to install and use 1> You can save the software provided on the enveloped CD on your computer or just execute it. Live remote monitoring Display mode button You can save the currently displayed images into M-JPEG stream.
  • Page 33 DVRJ4 System setting This is the route where you save M-JPEG stream or AVI file. ④ DVR‟s unique MAC address. It‟s shown on the manual. User’s manual ① Press this button. ② Insert the IP when you use static IP.
  • Page 34 DVRJ4 Access Insert the password to try to access. Default is 0000. You can start recording of the DVR or stop with using this button. User’s manual...
  • Page 35 Remote search / playback Remote search / playback is the function that search and playback the data recorded on the DVR remotely via client software. ① Select the hard drive. ② Press „REC‟ or „EVENT‟ button to find the list you want and double-click it to play back.
  • Page 36 DVRJ4 HDD scan playback You can connect the hard drive out of the DVR system to your computer directly to play back the recorded data. Hard disk selection Playback button Stop Audio ON/OFF Move to end. Move to beginning User’s manual...
  • Page 37 DVRJ4 Backup playback Backup playback is the function that plays back on your PC the backup data on USB device and other storage device. You can connect the backup device to the PC to play back. Playback Stop Move to end...

  • Page 38: Virtual Server

    Router may be various from one to one by various manufacturers. On this manual, the target model is Linksys WRT54G. On router‟s virtual server item, assign TCP 5000 and TCP 5001 as DVR IP. ( ※ Some routers use the terms of „Port Forwarding‟ instead of Virtual server.)

  • Page 39: Router Ip Check

    7.2. Router IP check Router‟s IP address is the internet IP. The above example shows it 192.168.1.1 Note: The vendor of this DVR can only provide guidance on how to configure your router. Always call your ISP or the router‟s technical support for complete information how to setup your local network or Internet service.
  • Page 40 DVRJ4 User’s manual 7.3. Access In case of DDNS use, insert the DVR set‟s address secure address. then you can use that IP address. Insert the router‟s IP address and press OK.
  • Page 41 DVRJ4 App. A. Troubleshooting Symptom The system does not get on. Can not view the live images. Live images are too bright. DVR stops working during recording. App. B. Product specification Video signal Video input Video output Resolution Playback / recording speed - Please check the external power adapter status.
  • Page 42 DVRJ4 Audio input / output Audio input 1 Line Input Audio output 1 Line Output Video input Composite : 4 BNC Video output Composite : 2 BNC Audio input 1 RCA connector Audio output 1 RCA connector Main storage Hard drives x 2pcs(Master & slave)
  • Page 43 DVRJ4 Unit dimension (W x D x H) Unit weight Packing weight Packing dimension (W x D x H) Operation temperature Operation humidity Power The specification may be changed without any prior notice for better quality. Generals 280mm x 250mm x 45mm 2.5Kg...

  • Page 44: Product Warranty

    DVR vendor during the warranty period. 3. You need to get a RMA number from Optiview Technical Support Group for free warranty repair works. 4. Some charges will be applied for the cases below even though it‟s within warranty period.
