Parameter Function
Matrix Please note this function is valid in motion detect mode.
Enable Check the box here to enable video matrix function. Right now system
supports one-channel tour function. System takes ―first come and first
serve‖ principle to deal with the activated tour. System will process the
new tour when a new alarm occurs after previous alarm ended.
Otherwise it restores the previous output status before the alarm
activation.
Copy It is a shortcut menu button. You can copy current channel setup to
one or more (all) channels.
Save You can click save button after you complete setup for one channel,
or you can complete the whole setups and then click save button.
Refresh Click this button to get device latest configuration information.
7.5.2.8 PTZ
PTZ interface is shown as in Figure 7-47.
Please note, before operation please make sure you have set speed dome address. And DVR
and speed dome connection is OK.
Please refer to the following sheet for detailed information.
Parameter Function
You can select monitor channel from the dropdown list. .
Channel
Select the corresponding dome protocol.(such as PELCOD)
Protocol
Set corresponding dome address. Default value is 1. Please note your
Address
setup here shall comply with your dome address; otherwise you can
not control the speed dome.
Figure 7-47
