Optiview VR4HT User Manual page 146

Parameter Function
Setup In Figure 7-32, click set button, you can go to the corresponding
setup interface. See Figure 7-33.
Please set schedule period and then select corresponding record or
snapshot type: schedule/snapshot, motion detection/snapshot, and
alarm/snapshot.
Please select date (Current setup applies to current day by default.
You can draw a circle before the week to apply the setup to the
whole week.)
After complete setup, please go back to
save to save current time period setup.
Copy It is a shortcut menu button. You can copy current channel setup to
one or more (all) channels. The interface is shown as in Figure
7-31
Save You can click save button after you complete setup for one channel,
or you can complete the whole setups and then click save button.
Refresh Click this button to get device latest configuration information.
7.5.2.4 RS232
The RS232 interface is shown as in
Please refer to the following sheet for detailed information.
Parameter
RS232
Function
.
X
Figure 7-34.
X461H461H4 61H
Figure 7-34
Function
There are two options: COM 01 and keyboard.
Console is to upgrade the program or debug via COM or
mini terminal software.
Figure 7-29 and then click
X459H459 H459 H X
136
