Record REC
Slow play
Assistant Fn
Fast play
Play previous
Reverse/Pause
Play Next
Play/Pause
Window switch Mult
Shuttle(outer
ring)
Jog(inner dial)
USB port
Remote control
ACT
indication light
Manually stop/start recording, working with direction keys
or numeral keys to select the recording channel.
Multiple slow play speeds or normal playback.
One-window monitor mode, click this button to display assistant
function: PTZ control and image color.
Backspace function: in numeral control or text control, press it
for 1.5seconds to delete the previous character before the
cursor.
In motion detection setup, working with Fn and direction keys to
realize setup.
In text mode, click it to switch between numeral, English
character(small/capitalized) and etc.
In HDD management interface, you can click it to switch HDD
record information and other information (Menu prompt)
Realize other special functions.
Various fast speeds and normal playback.
In playback mode, playback the previous video
In normal playback or pause mode, click this button to reverse
⊳
playback
In reverse playback, click this button to pause playback.
In playback mode, playback the next video
In menu setup, go to down ward of the dropdown list.
In normal playback click this button to pause playback
In pause mode, click this button to resume playback.
Click it to switch one-window/multiple-window.
In real-time monitor mode it works as left/right direction key.
Playback mode, counter clockwise to forward and clock wise to
backward.
Up/down direction key.
Playback mode, turn the inner dial to realized frame by frame
playback. (Only applies to some special versions.)
To connect USB storage device, USB mouse.
Remote control indication light
