Optiview VR4HT User Manual page 148

Parameter
DHCP
MAC address
IP address
Subnet prefix
TCP Port
HTTP Port
UDP Port
Max Connection
Remote Multiple
Host cast
group
PPPOE Input the PPPoE user name and password you get from the
Email
The email interface is shown as in Figure 7-36.
Function
It is to auto search IP. When enable DHCP function, you can
not modify IP/Subnet mask /Gateway. These values are from
DHCP function. If you have not enabled DHCP function,
IP/Subnet mask/Gateway display as zero. You need to
disable DHCP function to view current IP information.
Besides, when PPPoE is operating, you can not modify
IP/Subnet mask /Gateway.
The host in the LAN can get a unique MAC address. It is for yo
to access in the LAN. It is read-only.
Please input the corresponding number to set the IP address.
Then you can set the corresponding subnet mask and
gateway.
The value ranges from 0 to 128. It is to mark a specified
network MAC. Usually it includes a structure of multiple-
layers.
Please note system needs to check the validity of all IPv6
addresses. The IP address and the default gateway shall be in
the same IP section. That is to say, the specified length of the
subnet prefix shall have the same string.
Default value is 37777. You can change if necessary.
Default value is 554.
Default value is 37778. You can change if necessary.
Network user max amount. The value ranges from 0 to 20.
O means there is no user can access current device.
Set MULCAST address and port.
Enable MULCAST function.
IPS (internet service provider) and enable PPPoE function.
Please save current setup and then reboot the device to get
the setup activated.
Device connects to the internet via PPPoE after reboot. You
can get the IP address in the WAN from the IP address
column.
Please note if you want to reboot the device please make
sure you have proper reboot right and there is no login user
in current device.
138
