2.2.2 1U Series
2.2.2.1 Full-D1 Series
The rear panel is shown as in Figure 2-11.
Please refer to the following sheet for detailed information.
1
2
3
4
5
6
7
8
9
10
11
12
13
2.2.2.2 4-ch 2CIF Real-time Series
This series DVR rear panel is shown as below. See Figure 2-12.
Audio input
Alarm input/alarm output
On/off button
Video VGA output
HDMI port
USB port
Network port
RS-485 port
Power socket
GND port
Video input
Audio input
Audio output
Video output
USB port
HDMI port
Network port
Power socket
Alarm input/alarm output/RS485 port
Video VGA output
RS232 port
On/off button
GND port
Figure 2-11
