  • Page 1 H.264 DVR System User’s Manual H.264 DVR system...
  • Page 2 DVR User’s Manual...
  • Page 3 DVR User’s Manual Caution and Preventive Tips Handle with care, do not drop the unit. Mount the unit in an equipment rack or place it on a solid, stable surface. Indoor use only. Do not place the unit in a humid, dusty, oily, or smoky site. Do not place it in an area with poor ventilation or in an area close to fire or other sources of heat.
  • Page 4 DVR User’s Manual Important Information Before proceeding, please read and observe all instructions and warnings in this manual. Retain this manual with the original bill of sale for future reference and, if necessary, warranty service. When unpacking your unit, check for missing or damaged items. If any item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT.

  • Page 5: Table Of Contents

    DVR User’s Manual Table of Content 1. Overview ........................4 2. System Setup ........................ 8 Position the Unit ....................8 Selecting Video Format..................8 Connecting Devices to the Unit ................9 Rear Panel Connections ..................9 3. General System Setup ....................11 Front Panel Introduction ..................
  • Page 6 DVR User’s Manual Sequence Setup ....................30 4.2.1 Sequence with Main Monitor ..............30 4.2.2 Sequence with Call Monitor ..............32 Searching Recorded Video ................32 4.3.1 Searching by Time ................33 4.3.2 Searching by Event ................33 Video Export ...................... 34 4.4.1 ezBurn Introduction ................
  • Page 7 DVR User’s Manual Appendix C: Connect Analog Camera via UTP Converter ........... 60 Appendix D: Recommended HDDs ................61 Appendix E: IP Camera Installation ........Error! Bookmark not defined. Appendix F: Remote Controller ..................62 Appendix G: Setting up a DVR behind a Router ............65...

  • Page 8: Overview

    Web-browser plug-in allowing users to view live or recorded video images, and enables remote configuration. The remote software is stored in the Optiview H.264 DVR and deployed over a LAN, WAN or Internet connection to remote Windows-based computers. This simplifies the installation and maintenance of the software components so all remote users are using the same software coming from the unit.

  • Page 9: System Setup

    DVR User’s Manual Supports Pre-Alarm Recording Motion Detection Marker Remote software for remote monitoring Central Management System (CMS) for large-scale video management Human Technology: ezBurn™ for quick video export ezRecord™ for quick recording setting ezDDNS™ for automatic DDNS configuration GUI interface IR Remote Control (Optional) Compact Control Keyboard (Optional) System Setup...

  • Page 10: Connecting Devices To The Unit

    DVR User’s Manual Connecting Devices to the Unit This section lists some important notices that should be read before making any connection to the DVR. Connecting Required Devices Before powering up the unit, cameras and a main monitor should be connected to the unit for basic operation.
  • Page 11 DVR User’s Manual Alarm I/O & RS485 & Audio In Terminal block connectors are provided to offer users the flexibility to connect the DVR to Alarm I/O, RS-485, and Audio In devices. The definition of pins varies for different models. Refer to Setup Guide for detailed pin definitions. LAN Connector (RJ-45) The DVR is capable of networking.

  • Page 12: General System Setup

    DVR User’s Manual General System Setup Before operating the DVR, some general configuration should be setup first. The following subsections will introduce function keys on the front panel and general configuration of the DVR. The regular displayed OSD information and its displayed positions are shown as following figure.

  • Page 13: Function Keys

    DVR User’s Manual 3.1.2 Function Keys This section describes the functional keys, which are for normal operation, on the front panel of the DVR. Please refer to the Setup Guide for the graphical illustration of functional keys. CHANNEL In both Live and Playback modes, press the CHANNEL key to view the corresponding video in full screen.
  • Page 14 DVR User’s Manual DOME Press the key to enter dome control mode. Please refer to Section Dome Control for detailed controlling operation. Press to cancel or exit from certain mode or OSD setup menu without changing the settings made previously. MODE Press repeatedly to select for wanted main monitor display format.
  • Page 15 DVR User’s Manual...

  • Page 16: Power Up / Down The Unit

    DVR User’s Manual Power Up / Down the Unit If the DVR must be shutdown for any reason, please use the proper shut down and power up procedures to avoid damaging the DVR. To Power Up the Unit Simply plug in the power adapter that came with the package and the DVR will start to boot.

  • Page 17: System Date / Time Setting

    DVR User’s Manual The default passwords are shown in the following table. The same passwords are used for entering the remote viewing software. Administrator Password User Password 1 2 3 4 4 3 2 1 NOTE: It is strongly suggested to change the passwords to prevent unauthorized access to the unit.

  • Page 18: Daylight Saving Time

    DVR User’s Manual Date Display Mode This function allows users to set the OSD display type of the date. There are three options to select from: <Y/M/D>, <M/D/Y> or <D/M/Y>. “Y” represents “Year”, “M” represents “Month” and “D” represents “Day”. Move to the item and press ENTER, the option starts blinking.

  • Page 19: Ip Camera Setting

    DVR User’s Manual IP Camera Setting The distinctive hybrid solution of the DVR enables users to connect IP camera(s) while others are analog cameras. First enter the OSD setup menu with the administrator password and access <System Setup>  <IP Camera Support>...

  • Page 20: Connection Setup

    DVR User’s Manual 3.5.2 Connection Setup Enter <Connection Setup> to configure the connection and data transmission setting of the connected IP Camera. The menu will be shown as below. Connection Setup 1. Account **** 2. Password **** 3. Management Port 4.

  • Page 21: Device Setup

    DVR User’s Manual 3.5.3 Device Setup Enter <Device Setup> to configure the basic settings of the IP camera. The basic settings include the IP camera’s product name, image quality, image adjustment, etc. Set the item <Apply> to <Yes> to apply the changes. NOTE: The administrator account and password of the IP camera should be entered in order to change the basic settings.

  • Page 22: Record Schedule / Quality Setting

    DVR User’s Manual Record Schedule / Quality Setting The Record Setup menu allows users to set recording quality, recording schedules, and other recording parameters. Administrator's password is required to access Record Setup menu. In the Main menu, move the cursor to <Record Setup>...

  • Page 23: Preset Record Configuration

    DVR User’s Manual 3.6.2 Preset Record Configuration The <Preset Config> is used to select the preset recording quality and frame rate. In normal circumstances, it is strongly recommended to set the preset configuration as <Best Quality>. Below table shows the PPS and picture size under <Best Quality>...

  • Page 24: Ezrecord Setup

    DVR User’s Manual First select a Camera for setting its record configuration. The image and recording settings from the selected camera will be displayed on the screen. Move the cursor using Direction keys and press ENTER to select an item. Change the value using UP / DOWN keys.

  • Page 25: Circular Recording

    DVR User’s Manual Follow these steps to Setup ezRecord: Select <How Many Days To Record> and press ENTER, then press UP/DOWN to choose an option. The average normal PPS & Quality will be adjusted automatically. The maximum of days depends of the size of the installed HDD(s).

  • Page 26: Purge Data

    DVR User’s Manual 3.6.7 Purge Data This item is used to delete the Normal or Event recording video. In Record Setup menu, move the cursor to <Purge Data> and press ENTER; the Purge Data menu is displayed. Purge Data 1. Purge All Data 2.

  • Page 27: Basic Operation

    The general functions in live and playback mode are described in the following sections. 4.1.1 Viewing Modes The DVR provides users Optiview ways of viewing both live and recorded video. Following presents these view formats. Viewing in Full Screen Press any CHANNEL key directly to view the corresponding camera image in full screen format.

  • Page 28: Digital Zoom

    Either press ENTER again or ESC to leave the Zoom mode. 4.1.3 Viewing Live Cameras Users are allowed to view live camera in Optiview viewing modes, including full-screen, 2×2, 3x3 and 4×4. The general operation under live mode is described as follows.
  • Page 29 DVR User’s Manual The Forward or Reverse speed indicator will be shown on the bottom-left of the screen in the playback mode.

  • Page 30: Key Usage In Playback

    DVR User’s Manual The general operations in playback mode are described as follows. Key Usage in Playback The key usage is slightly different in playback mode. Following is the key usage found in playback mode.  LEFT (Reverse Playback) The key is used to reverse the recorded video while the unit is playing back.

  • Page 31: Sequence Setup

    DVR User’s Manual Viewing Live Image in Playback Mode Press the MODE key repeatedly in playback mode, a 16-window viewing mode contains both live and playback image appears. This viewing mode is illustrated as the following figure. The eight windows on the upper half of the screen playback the Live video from channel 1 to channel 8 respectively, and the other windows allow users to view Playback image from channel 1 to channel 8.
  • Page 32 DVR User’s Manual Formatted: Font: (Default) Arial Formatted: Normal, Centered, Indent: Left 6 ch Formatted: Bullets and Numbering...

  • Page 33: Sequence With Call Monitor

    DVR User’s Manual 4.2.2 Sequence with Call Monitor Users are allowed to use the DVR front panel to control a call monitor display without having to access the Main menu. Two viewing modes can be displayed on call monitor: Sequence display and Single camera display. To program the call monitor sequence, see OSD Menu Setup Guide, Section Sequence Setup.

  • Page 34: Searching By Time

    DVR User’s Manual 4.3.1 Searching by Time Follow the steps to search video by date and time. Press SEARCH key to enter the Search menu. Move the cursor to “From Time” and press ENTER will start playing recorded video from the specified “From Time”. Move the cursor to “End Time”...

  • Page 35: Video Export

    DVR User’s Manual The list displays events by date, time, triggered camera and alarm type. As some events are deleted, others are displayed. The latest recorded event video will be listed on the top. Follow these steps to search event video through Event List: Press SEARCH to enter the Search menu.

  • Page 36: Ezburn Introduction

    DVR User’s Manual 4.4.1 ezBurn Introduction Built with the ezBurn technology, ezBurn function provides users the easier way to export desired video with built-in DVD+RW or to an external device, ® such as an USB ThumbDrive TWO keys (SEARCH and COPY) and THREE touches are all what’s needed for completing the export.

  • Page 37: To Export Event Video

    DVR User’s Manual Press ENTER to start the export; or, press ESC to abort. If there is no any exportable device connected to the DVR unit, then a warning message will be shown on the screen, as below figure: No exportable device detected. Please install the target device/media to the DVR.
  • Page 38 DVR User’s Manual Formatted: Font: (Default) Arial, Font color: Black Formatted: Normal, Justified, Indent: Left 6 ch, No bullets or numbering, Tab stops: Not at 1.5" Formatted: Font color: Black...

  • Page 39: Dome Connection

    DVR User’s Manual 4.5.1 Dome Connection Follow the steps to install dome camera. See Setup Guide for RS-485 port pin definition. Connect the R+, R- terminals on the dome camera to the D+, D- terminals on the RS-485 port by RS-485 cable respectively. Refer to the connection figure illustrated in Setup Guide.

  • Page 40: Dome Controlling Keys

    DVR User’s Manual 1 Unit ID 2 Baud Rate 9600 3 Bits 4 Stop 5 Parity None The ID number must match the ID address set by the dome. The Unit ID is in the range of 1 to 255. Note that there cannot be any two devices on the same bus given the same ID address, or a conflict may occur.

  • Page 41: Setting Preset Points

    DVR User’s Manual Auto / Enter In OSD setup menu interface, the key is used to make selection. In dome control mode, this key is used to activate automatic focus and iris function. Iris Close Use to close the Iris on the dome camera. Focus Far Use to focus the selected dome camera far.

  • Page 42: Calling Preset Points

    DVR User’s Manual Press 1 to access the Set/Go Preset function. The Dome Preset menu is displayed. Dome Preset First Page Index Set Preset Go Preset Use UP / DOWN keys to select the desired preset number from the menu. Set the <Set Preset>...

  • Page 43: Remote Monitoring Software

    DVR User’s Manual Remote Monitoring Software The remote monitoring software is a remote browser-based software application designed to operate with the DVR products. Using the software, users are allowed to view live and recorded video, and configure the DVRs remotely via a LAN, WAN or Internet on a personal computer. connected PC will automatically download the remote monitoring software plug-ins from the DVR when the DVR is connected by entering its IP address in the address bar on the browser.

  • Page 44: Getting Start Of Installation

    DVR User’s Manual Getting Start of Installation Refer to the following description to install the Central monitoring software. 5.2.1 Changing Internet Settings The PC operating with the remote monitoring software should be set to accept ActiveX plug-ins. Please follow the steps to set the Internet security settings appropriately.
  • Page 45 DVR User’s Manual Uncheck “Require server verification (https:) for all sites in this zone”. Type the IP address of the unit in field and click <Add> to add this web site to the zone. Formatted: Indent: Left: 6 ch, Bulleted + Click <OK>...

  • Page 46: Installing Remote Monitoring Software

    DVR User’s Manual 5.2.2 Installing Remote Monitoring Software Start the browser to initiate the installation of the remote monitoring software on the PC. The IP address of the DVR can be saved as a Favorites item in the web browser to enable easy access in the future. Formatted: Indent: Left: 6 ch, Bulleted + Start the IE;...

  • Page 47: Login / Logout

    DVR User’s Manual 5.2.2.1 Login / Logout Login using either <Admin> or <User> account. <Admin> account can modify configuration without restraint, while <User> account is limited to general remote access of the unit. One “Admin” and up to two “Users” can access a DVR at the same time. Nevertheless, if the “Admin”...

  • Page 48: Software Upgrades

    DVR User’s Manual 5.2.2.2 Software Upgrades If a new version of the remote monitoring software is available on the DVR, upgrade will be prompted while accessing the unit. Follow the steps to upgrade the software. Formatted: Indent: Left: 6 ch, Bulleted + The message as the above figure will be prompted.

  • Page 49: To View Live Video

    DVR User’s Manual Refer to the following table for brief description of functional items: Item Description Item Description Instant Recording Capture Snapshot Audio On/Off 10 4:3 Viewing Aspect Select Camera 11 HDD Status Display Mode 12 Playback Control View Live Camera 13 Select Picture Size Playback Video 14 Select Bandwidth Speed...

  • Page 50: Operating Cameras With Dome Control

    DVR User’s Manual 5.3.1.2 Operating Cameras with Dome Control The remote monitoring software allows users to control and configure a dome camera remotely. Click on any CAMERA button displayed with a dome icon to view the camera in full screen. The Dome Control Panel will be displayed on the main window.

  • Page 51: Instant Recording

    DVR User’s Manual This item is used to open and close the iris to let more or less light into the camera. Click on <Iris +> to open iris or <Iris −> to close iris. Zoom +/− Users are allowed to zoom-in or zoom-out using the adjusting buttons. Zoom-in to enlarge a certain area and zoom-out to view more area.

  • Page 52: To Playback Video

    DVR User’s Manual Click <Open> to choose a recorded file. Click <OK> to start playing the recorded video. 5.3.3 To Playback Video The remote monitoring software allows users to view recorded video either from the DVR, or from the hard disk drive of the PC To access the Playback screen, click <Play>...

  • Page 53: To Playback Local *.Drv Files

    DVR User’s Manual desired numbers directly or using the arrow buttons. To type directly: Click on day, month and year of date field respectively, and type the desired numbers directly. Follow above steps to adjust the hour, minute and second of time field. To use the arrow buttons: Click on the arrow button next to the date field to display the calendar;...

  • Page 54: Playback Controls

    DVR User’s Manual Follow below steps to play back a downloaded *.drv file with the remote monitoring software. Formatted: Indent: Left: 6 ch, Bulleted + Click <Open> and the file selection screen is displayed. Level: 1 + Aligned at: 0" + Tab after: Select the *.drv video file to playback and click <OK>.

  • Page 55: Search From Event List

    DVR User’s Manual 5.3.4 Search from Event List Click SEARCH, the Event List appears. The List contains information about the alarm events that the unit recorded and saved. Up to 1024 events can be listed in the Event List. The Event List displays each event by its number, the date and time of the event, the type of the event (including Alarm In, Motion Detection, Video Loss, and Over Speed), and the camera channel where the event occurred.

  • Page 56: Take A Snapshot

    DVR User’s Manual 5.3.5 Take a Snapshot Snapshot is a simple screen capture tool. When users click on the SNAPSHOT button, it will capture the screenshot of the window that is currently showing on the screen. Each click captures one screenshot to be saved as a JPEG file on the desktop.

  • Page 57: Remote Monitoring Software Trouble Shooting Guide

    DVR User’s Manual 5.3.7 Remote Monitoring Software Trouble Shooting Guide What happened if the server requests to upgrade the software every time the DVR is connected? If the following screen displays repeatedly, please follow the steps to delete the temporary internet files. ...

  • Page 58: Appendix A: Technical Specifications

    DVR User’s Manual Appendix A: Technical Specifications All specifications are subject to change without notice. Formatted: Justified Specifications 4ch Model 8ch Model 16ch Model Video Formatted Table Operation System Embedded ( Linux ) BNC×16, 1.0Vp-p, 75 Input BNC×4, 1.0Vp-p, 75 ohm BNC×8, 1.0Vp-p, 75 ohm UTP (Optional) 4ch UTP 8ch UTP...

  • Page 59: Appendix B: Connect Utp Camera

    Cost Down on Camera Power Adapter – There is no need to buy adapter for each 2. UTP Color Box Camera because the power is directly supplied from the DVR unit. The Optiview H.264 DVR provides the option to connect UTP cameras. Follow the steps below to complete the UTP camera installation. Step 1: Connect the DVR and the UTP Camera via the UTP cable (CAT5).
  • Page 60 DVR User’s Manual Video Source Selection Follow the same procedure if more UTP Cameras to CH2, CH3, or CH4 will be installed. NOTE: Do NOT insert both BNC and UTP video sources to the same channel simultaneously, or the video will not function correctly and it may cause the video to look like the figure below.

  • Page 61: Appendix C: Connect Analog Camera Via Utp Converter

    DVR User’s Manual Appendix C: Connect Analog Camera via UTP Converter Introduction: The UTP converter is made especially for users who want to build a connection between an UTP DVR and a traditional analog camera, which allows the transmission of power and video signal through one CAT5 cable.

  • Page 62: Appendix D: Recommended Hdds

    DVR User’s Manual Appendix D: Recommended HDDs Refer to the following list for some recommended HDDs to be used in the DVR. Brand Model Name Model Number Size Barracuda ES.2 ST3500320NS 500G Barracuda 7200.11 ST3500320AS 500G Seagate Barracuda 7200.11 ST3750330AS 750G Barracuda 7200.11 ST31000340AS...

  • Page 63: Appendix F: Remote Controller

    DVR User’s Manual Appendix E: Remote Controller The operational function keys (on the left) and dome camera control keys (on the right) on the remote control are listed as below figure: Formatted: Font: (Default) Arial...
  • Page 64 DVR User’s Manual...
  • Page 65 DVR User’s Manual The keys of the remote control function as the keys of the front panel of the DVR. The only difference between the remote control and the front panel keys is the “DVR SEL” key. The DVR Selection key is used to switch control between each DVR. The remote control can be used to control up to 16 DVRs.

  • Page 66: Appendix G: Setting Up A Dvr Behind A Router

    DVR User’s Manual Appendix F: Setting up a DVR behind a Router This appendix describes how to set up a router if the DVR connects to the internet via a router. To properly operate a web server, e.g. a DVR, users have to set up both the IP and port of the DVR, which are essential for data and command transmission.
  • Page 67 DVR User’s Manual Following is an example of how the router should be set. Router DVR 1 DVR 2 (D-Link DI-724P+) IP: 192.168.0.100 IP: 192.168.0.167 IP: 192.168.0.200 WAN IP: 218.160.54.13 Trigger port: 80 Trigger port: 81 LAN IP: 192.168.0.1 To change the setting of the router, a PC with web browser is required. Connect to D-Link DI-724P+ from PC via IE.
  • Page 68 DVR User’s Manual Select <Enabled> to set up the service. Enter the name of the setting in the Name field: DVR 1. Enter Private IP: 167 Choose <TCP> as the Protocol Type. Enter Private Port: 80. Enter Public Port: 80. Click <Always>...
